SPECS KR-107
KEYBOARD
88 keys (Progressive Hammer-Action Keyboard
with escapement) • Touch Sensitivity: Yes •
Keyboard Mode: Whole, Split (adjustable split
point), Layer, Arranger, Piano Style Arranger,
Manual Drums/SFX
SOUND GENERATOR
Conforms to GM2/GS /XG Lite • Max. Polyphony:
128 voices • Tones: (Tone Search by terms and by
letters) 6 groups 736 variations (including 8 Tone
Wheel Organs, 18 drum sets, SFX set) •
Temperament: 8 types, selectable tonic •
Stretched Tuning: 2 types • Master Tuning: 415.3 Hz
-to 466.2 Hz (adjustable in increments of 0.1 Hz) •
Transpose: Key Transpose (-6 to +5 in units of
semitone), Playback Transpose (-24 to +24 in units
of semitone)
EFFECTS
Reverb (12 types, 127 levels) Chorus, Rotary, and
60 other types, Advanced 3D, Grand Space,
Dynamic Sound Emphasis (3 types), Equalizer (5
bands, Master level)
ARRANGER
Music Styles (Style Search by terms and by
letters): 6 groups 265 styles x 3 types (Style
Orchestrator) • Music Assistant (Search by terms
and by letters): Over 570 sets • Visual Music
Assistant, Programmable Music Styles: Style
Converter, Style Composer • Melody
Intelligence: 24 types
USER PROGRAMS
Internal: 36 • External Memory: Max. 99 sets
METRONOME
Tempo: Quarter note = 20 to 250, Beat: 2/2, 0/4, 2/4,
3/4, 4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8, 12/8 • Volume: 10
levels • Metronome Pattern: 11 patterns •
Metronome Sound: 8 types
COMPOSER
Tracks: 5 tracks / 16 tracks • Song: 1 song • Note
Storage: Approx. 30,000 notes • Resolution: 120
ticks per quarter note • Recording Method:
Realtime (Replace, Mix, Auto Punch In, Manual
Punch In, Loop, Tempo), Step (Chord Sequencer),
Beat Map • Edit: Copy, Quantize, Delete, Insert, Erase,
Transpose, Part Exchange, Note Edit, PC Edit
OTHER FUNCTIONS
Touch the Notes, Replay, Super Tones, Piano
Designer, Visual Lesson, Wonderland/Game,
Demo, Audition, Panel Lock, V-LINK, BMP export,
user image display
EXTERNAL FUNCTIONS
USB Flash Memory • Floppy Disk Drive (for song
data, not audio files) • Playable Software: [Song:]
Standard MIDI Files (Format 0/1), Roland Original
Format (i-Format) [Music Style:] MSA, MSD, MSE •
Save [Song:] Standard MIDI Files (Format 0),
Roland Original Format (i-Format) [Music Style:]
MSE • Audio File: WAV Format (44.1 kHz 16-bit
linear stereo)
INTERNAL MEMORY
Internal Songs (Song Search by terms and by
letters): Over 190 songs • User Memory: Max. 200
songs on Favorites, Max. 99 User Styles, Max. 99
User Program Sets
OTHER
Rated Power Output: 60 W x 2 • Speakers: 20 cm x
2, 10 cm x 2, 5 cm x 2 • Display: Bouncing Beat
Indicator, Graphical Color touchscreen 320 x
240 dot (backlit LCD) • Notation: Grand staff, G
Clef staff, F Clef staff, with note name, lyrics,
chords, fingering • Language: English, Japanese,
German, French, Spanish • Lyrics: Yes (built-in,
external display, MIDI output) • One Touch
Program: One Touch Piano, One Touch Arranger
• Pedals: Damper Pedal (half-pedal recognition),
Soft Pedal (half-pedal recognition, functions
assignable), Sostenuto Pedal (functions
assignable) • Vocal Effects: Echo, Voice
Transformer, Vocal Keyboard, Harmonist •
Connectors: USB memory connector, FDD
connector, Output jacks (L/Mono, R), Input jacks
(L/Mono, R), Mic Input jack, Headphones jack
(Stereo) x 2, MIDI In connector x 2, MIDI Out
connector, USB connector, Ext Display
connector (15-pin D-Sub type), Video Out
connector, Expression Pedal Jack • Power
Supply: AC 115V, AC 117V, AC 220V, AC 230V, AC
240V (50/60Hz) • Power Consumption: 155W
DIMENSIONS
(including piano stand) 56 (W) x 21-11/16 (D) x 35-1/2
(H) inches • Weight (including piano stand): 228 lbs
ACCESSORIES
Quick Start, owner's manual, Roland 60 Classical
Piano Masterpieces, Remote Controller, dry-cell
batteries, USB Installation Guide CD-ROM
(Roland Digital Piano USB Driver), power cord,
headphones hook, anti-theft lock screws
OPTIONS
USB memory, floppy disk drive, expression pedal,
cf/cd recorder
w w w. r o l a n d u s . c o m
KR-105 KR-103
88 keys (Progressive Hammer-Action Keyboard ) 88 keys (Compact Progressive Hammer-Action
• Touch Sensitivity: Yes • Keyboard Mode: Whole, Keyboard), Touch Sensitivity • Keyboard Mode:
Split (adjustable split point), Layer, Arranger, Whole, Split (adjustable split point), Layer,
Piano Style Arranger, Manual Drums/SFX Arranger, Piano Style Arranger, Manual
Drums/SFX
Conforms to GM2/GS/XG Lite • Max. Polyphony: Conforms to GM2/GS/XG Lite • Max. Polyphony:
64 voices • Tones: 6 groups 646 tones (including 16 64 voices • Tones: 6 groups 400 tones, 20 drum
drum sets, 1 SFX set) • Temperament: 8 types, sets • Master Tuning: 427.4 Hz to 452.6 Hz
selectable tonic • Stretched Tuning: 2 types • (adjustable in increments of 0.1 Hz) • Transpose:
Master Tuning: 415.3 Hz to 466.2 Hz (adjustable in Key Transpose (-6 to +6), Data Transpose (-24 to
increments of 0.1 Hz) • Transpose: Key Transpose +24), All Transpose (-6 to +6)
(-6 to +5 in units of semitone), Playback Transpose
(-24 to +24 in units of semitone)
Reverb (8 types) Chorus, Rotary, and Reverb (8 types), Chorus, Rotary, and 46 Multi-FX
32 other types
Music Styles (Style Search by terms and by Music Styles: 6 groups 170 styles x 3 types
letters): 6 groups 230 styles (x 3 type Style (Style Orchestrator) • Music Assistant: 150 sets •
Orchestrator) • Music Assistant (Search by terms Melody Intelligence: 18 types
and by letters): Over 370 sets • Visual Music
Assistant • Programmable Music Styles: Style
Converter • Melody Intelligence: 24 types
Internal: 36 • External Memory: Max. 99 sets Internal: 32 • External Memory: Max. 99 sets
Tempo: Quarter note = 20 to 250 • Beat: 2/2, 0/4, 2/4, Tempo: Quarter note = 20 to 250 • Beat: 1/4, 2/4, 3/4,
3/4, 4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8, 12/8 • Volume: 10
4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8, 12/8 • Volume: 127 levels
levels • Metronome Pattern: 11 patterns • • Metronome Pattern: 1 pattern • Metronome
Metronome Sound: 8 types • Rhythm 59 pattern Sound: 1 type
Tracks: 5 tracks/16 tracks • Song: 1 song • Note Tracks: 5 tracks/16 tracks • Song: 1 Song •
Storage: Approx. 30,000 notes • Resolution: 120 Resolution: 120 ticks per quarter note •
ticks per quarter note • Recording Method: Recording Method: New Song/Single/Punch
Realtime (Replace, Mix, Auto Punch In, Manual In/Out
Punch In, Loop, Tempo), Step (Chord Sequencer),
Beat Map, Edit: Copy, Quantize, Delete, Insert, Erase,
Transpose, Part Exchange, Note Edit, PC Edit
Touch the Notes, Replay, Wonderland/Game, Demo, Panel Lock, V-LINK
Demo, Audition, Panel Lock, V-LINK, BMP export
Files: Max. 99 songs, Max. 99 User Styles, Max. 99 Disk: Max. 99 songs, Max. 99 User Styles, Max. 99
User Program Sets • Playable Software: [Song:] User Program Sets • Playable Software [Song:]
Standard MIDI Files (Format 0/1), Roland Original Standard MIDI Files (Format 0/1), Roland Original
Format (i-Format) [Music Style:] MSA, MSD, MSE • Format (i-Format), [Music Style:] MSA, MSD, MSE •
Save: [Song] Standard MIDI Files (Format 0), Roland Save [Song:] Standard MIDI Files (Format 0)
Original Format (i-Format) [Music Style:] MSE
Internal Songs (Song Search by terms and by Over 50 songs
letters): Over 184 songs • User Memory: Max. 200
songs on Favorites, Max. 99 User Styles, Max. 99
User Program Sets
Rated Power Output: 40 W x 2 • Speakers: 20 cm x Rated Power Output: 25 W x 2, Speakers: 20 cm x 2
2, 5 cm x 2 • Display: Bouncing Beat Indicator, • Display: Bouncing Beat Indicator, Custom LCD
Graphical mono LCD 320 x 240 dot (backlit LCD) • (backlit LCD) • Lyrics: No (only via MIDI output) •
Notation: Grand staff, G Clef staff, F Clef staff, One Touch Program: One Touch Piano, One
with note name, lyrics, chords, fingering • Touch Arranger • Pedals: Damper Pedal, Soft
Language: English, Japanese, German, French, Pedal (functions assignable), Sostenuto Pedal
Spanish • Lyrics: Yes (built-in, MIDI output) • One (functions assignable) • Connectors: Output
Touch Program: One Touch Piano, One Touch jacks (L/Mono, R), Input jacks (L/Mono, R),
Arranger • Pedals: Damper Pedal (half-pedal Headphones jack (Stereo) x 2, MIDI In connector,
recognition), Soft Pedal (half-pedal recognition, MIDI Out connector, USB connector, Expression
functions assignable), Sostenuto Pedal Pedal Jack • Power Supply: AC 115 V, AC 117 V, AC
(functions assignable) • Vocal Effects: Echo • 220 V, AC 230 V, AC 240 V (50/60 Hz) • Power
Connectors: Output jacks (L/Mono, R), Input Consumption: 70W
jacks (L/Mono, R), Mic Input jack, Headphones
jack (Stereo) x 2, MIDI In connector, MIDI Out
connector, USB connector, Expression Pedal
Jack • Power Supply: AC 115V, AC 117V, AC 220V, AC
230V, AC 240V (50/60Hz) • Power Consumption: 90W
(including piano stand and music rest) 56 (W) x (including piano stand), 55 1/4 (W) x 25-3/8 (D) x 35
21-11/16 (D) x 36-1/4 (H) inches • Weight (including (H) inches • Weight: (including the piano stand):
piano stand): 155 lbs , 7 oz 133 lbs, 7 oz
Roland 60 Classical Piano Masterpieces, USB USB Installation Guide CD-ROM (Roland Digital
Installation Guide CD-ROM (Roland Digital Piano USB Driver), power cord, headphones hook
Piano USB Driver), Power cord, Headphones
Hook
expression pedal, cf/cd recorder expression pedal, cf/cd recorder
KR SERIES
digital intelligent pianos
KR-103/105/107
