Summary of Contents for Intel Express 9545
- Page 1 ® Intel Express 9545 Router Quick Start...
- Page 2 Copyright © 2000, Intel® Corporation. All rights reserved. Intel Corporation, 5200 NE Elam Young Parkway, Hillsboro OR 97124-6497 Intel Corporation assumes no responsibility for errors or omissions in this manual. Nor does Intel make any commitment to update the information contained herein.
-
Page 3: Table Of Contents
Quick Start Install the Router Hardware ....® Install Intel Device View ....... 3 Install the Router in Intel Device View ... 4 Configure the Router ......5 Configuration Worksheets .........6 LED Indicators ..........10 Local Management ..........12 Viewing Online Manuals ........13... -
Page 4: Quick Start
This port provides HDSL2 access to a T1 Figure 1. Connecting the Express 9545 Router. See the user guide for details on connecting the LAN2 port. service and supports Frame Relay, X.25, or a PPP leased line. -
Page 5: Install Intel Device View
LANDesk® Network Manager. 3 Follow the screen instructions to complete the installation. Figure 4. Access Intel Device View for Web from any PC on the network. Start Internet Explorer Select Launch Intel Device View on the and type the following in the Address field: final installation screen, then continue http:// servername /deviceview/main.htm... -
Page 6: Install The Router In Intel Device View
Install the Router in Intel Device View The Device Install Wizard sets up the router for management in Intel Device View by performing basic configuration, such as assigning an IP address. 1 If it is not already running, start the Device Install Wizard by selecting Install Figure 5. -
Page 7: Configure The Router
Quick Start Configure the Router Intel Device View supports the Connection Setup program for configuring the router. Wizards guide you through setting up the ports, then adding connections to the ports. Configuration Tips • Your service subscription (the informa- tion you get from your service provider) Figure 8. -
Page 8: Configuration Worksheets
Configuration Worksheet These pages help you gather needed information before using a Connection Setup wizard. The information you’ll need varies depending on the router model, your type of service, and the type of connection you want to establish. Consult your telephone company, ISP, and system administrator to determine which parts of this worksheet you should fill in. - Page 9 Configuration Worksheet Get information from your telephone company for your type of connection For HDSL2 General for all connection types Framing format m ESF m D4 Terminal unit m remote end m central end Line Speed: _______kbps Channel Usage m Continuous m Custom m Alternate (Odd) m Alternate (Even) For Frame Relay connections only...
- Page 10 Configuration Worksheet Get this information from your network system administrator General for all connection types LAN IP Address of router IP address: ___________________ Subnet mask: ___________________ Select one, both, or none for your network: m Enable firewall filtering (you’ll need to set up filters to allow certain traffic, such as Web, FTP, and Telnet, to pass over the network.) m Enable router management from the Internet For a direct connection to a remote site...
- Page 11 Configuration Worksheet Get this information from your Internet Service Provider (ISP) Remote ISDN Number (only if you are using ISDN to connect to your ISP) Remote ISDN number: ___________________ This is the ISDN number of your service provider . IP address assigned to you by the ISP m No IP address (it is dynamically assigned by the ISP each time the router makes a connection) m Single IP address: ___________________...
-
Page 12: Led Indicators
LED Indicators This section lists the meanings of the LEDs on the Intel Express 9545 router. Intel Express 9545 Router ® LAN 1 ISDN HDSL2 Status 100 Mbps LAN 2 Network Channel 1 Channel 2 Line Status Network Connection 4005... - Page 13 LED Indicators Color Meaning Channel 1 Green, steady ISDN B-channel established, no data activity. Green, blinking Data activity on the ISDN B-channel. Orange, steady No call connected, ISDN B-channel not established. Orange, blinking Trying to connect call and establish the ISDN B-channel. Red, steady Error establishing the ISDN B-channel Channel 2...
-
Page 14: Local Management
PC with terminal management interface that supports full monitoring emulation software and configuration capabilities. You can use Local Management as an alternative to Intel Device View. Router For more details on using Local Management, see the user guide. To Access Local Management through the... -
Page 15: Viewing Online Manuals
For the latest version of user manuals and other product literature, see the Intel Support Web site at: http://support.intel.com Search for the Express 9545 router and look for a link to manuals and literature. If you do not have an appropriate Web browser, see the instructions below for installing Internet Explorer version 5.01. -
Page 16: Regulatory Information
Important! The Intel Express Router must be installed by authorized technical personnel. It must be handled with great care at all times, and must not be exposed to violent shock or any other influences that may result in damage and possible functionality failures. Intel cannot be held responsible for any damage arising as a result of incorrect handling or installation. -
Page 17: Industry Canada Notice
Regulatory Information This equipment uses the following USOC jacks and codes: Interface Facility Interface Code Service Order Code Jack Type ISDN BRI ST 02IS5 6.0N ISDN BRI ST 02IS5 6.0N RJ49C Industry Canada Notice IC CS-03 NOTICE (Canada) The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s).
