JBL N26 Technical Manual

Technical Manual
N26/26AW
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency

SYSTEM COMPONENTS:

• Enclosure
• Grille
• Low Frequency Transducer N26 – 6" Polyplas
DC Resistance
• High Frequency
Transducer
DC Resistance
PACKAGING
Upper /Lower Foam
WP0370
Rubber feet
(8 pc. Set)
WI0742-B
Outer Carton
N26 – WB1978
N26AW – WB2029
Optional Wall Brackets
WBN26BLK (Black)
WBN26WHT (White)
JBL Consumer Products, Inc. 250 Crossways Park Dr., Woodbury, New York 11797
8 ohms
125 watts
55Hz – 20kHz
88dB (1 watt @ 1 meter)
3000 Hz
N26/26W (Not for Sale)
N26 Gray X06576
N26AW White X06579
™ , shielded
(NS-W6.25SS)
N26AW – 6" WeatherPlas ™
(NS-W6.25SS-03-1)
4.8 ohms ±10%
N26 – ³⁄₄" Titanium-laminate
Dome, shielded A12B20DM-01DT
N26AW – ³⁄₄" Titanium-laminate Dome
A12B20DM-02DT
3.0 ohms ±10%
Owner's Manual
AI0399
Warranty Card
AT0341
Survey Card
OWNER'S
AI0193-01
MANUAL
Instructions for feet
AI0407
Plastic Bag (2pcs.)
• Crossover Network
AURAL SWEEP TEST SPECIFICATIONS:
• A. System Aural Sweep Test 6.0V Input 50 Hz to 20 kHz
• B. L.F. Aural Sweep Test
• D. H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Enclosure dimensions:
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.

WIRING DIAGRAM

Driver High
Frequency
N26 – A12B20DM-01DT
N26AW – A12B20DM-02DT
Driver Low
Frequency
N26 – NS-W6.25SS
N26AW – NS-W6.25SS-03-1
N26/26AW SCHEMATIC
L1
1.0mH
+IN
INPUT
–IN
R1
1.2 ohm
10W
XR0182
6.0V Input 50 Hz to 4 kHz
2.83V Input 2 kHz to 20 kHz
14¹⁄₂ x 10³⁄₄ x 7³⁄₄" (H x W x D)
368 x 273 x 197mm
16.6 lbs/7.5kg – Sold in Pairs
– +
Network
XR0182
BLUE
WHITE
– +
GREEN
WHITE
GREEN
C1
9.0 µF/
100V
WHITE
C2
4.0µF/100V
BLUE
L3
0.12
mH
WHITE
+
250
L.F.
205 –
+
205
H.F.
–
110
Rev1 11/02
