Vespa would like to thank you
for choosing one of its products. We have prepared this booklet to help you to get the very best from your scooter. Please read it carefully before riding
the scooter for the first time. It contains information, tips and precautions for using your scooter. It also describes features, details and devices to assure
you that you have made the right choice. We believe that if you follow our suggestions, you will soon get to know your new vehicle and it will serve you
well for a long time to come. This booklet forms an integral part of the scooter; should the scooter be sold, it must be transferred to the new owner.
Vespa GTS Super 300
Ed. 2

Advertisement

Table of Contents
loading

Related Manuals for VESPA GTS Super 300

Summary of Contents for VESPA GTS Super 300

  • Page 1 Vespa would like to thank you for choosing one of its products. We have prepared this booklet to help you to get the very best from your scooter. Please read it carefully before riding the scooter for the first time. It contains information, tips and precautions for using your scooter. It also describes features, details and devices to assure you that you have made the right choice.
  • Page 2 The instructions given in this booklet are intended to provide a clear, simple guide to using your scooter; details are also given of routine maintenance procedures and regular checks that should be carried out on the vehicle at an Authorised PIAGGIO Dealer or Service Centre. The booklet also contains instructions for simple repairs.
  • Page 3 Personal safety Failure to completely observe these instructions will result in serious risk of personal injury. Safeguarding the environment Sections marked with this symbol indicate the correct use of the vehicle to prevent dam- aging the environment. Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious damage to the vehicle and sometimes even the invalidity of the guarantee.

  • Page 5: Table Of Contents

    INDEX VEHICLE..................Automatic transmission............. 33 Dashboard................Safe driving................34 Analogue instrument panel............10 MAINTENANCE................37 Clock..................11 Engine oil level................38 Key switch................. 12 Engine oil level check............38 Locking the steering wheel............ 12 Engine oil top-up..............38 Releasing the steering wheel..........12 Warning light (insufficient oil pressure).........
  • Page 6 Scheduled maintenance table........... 78...

  • Page 7: Vehicle

    Vespa GTS Super 300 Chap. 01 Vehicle...
  • Page 8 01_01...

  • Page 9: Dashboard

    Dashboard (01_01) A = Ignition key-switch B = Bag hook C = Saddle electric opening switch D = Horn button E = Turn indicator switch F = Rear brake lever G = Light switch H = Instrument panel I = Emergency cut-off switch RUN/OFF L = Front brake lever M = Throttle grip N = Starter button...

  • Page 10: Analogue Instrument Panel

    01_02 Analogue instrument panel (01_02) A = Digital clock B = Odometer C = Speedometer D = Injection telltale light E = Engine oil pressure warning light F = Turn indicators G = High-beam warning light...

  • Page 11: Clock

    H = Headlight warning light I = Fuel gauge L = Low fuel warning light M = Coolant temperature gauge N = Immobilizer LED Clock (01_03) Located in the instrument panel, it displays hours and minutes with 1 to 12-hour time, AM or PM.

  • Page 12: Key Switch

    Key switch (01_04) Key switch «A» is located on the front knee-guard panel near the bag hook. SWITCH POSITIONS ON«1»: Ready to start position, non-extractable key, mechanical anti-theft device disabled. OFF «2»: Ignition disabled, extractable key, mechanical anti-theft device disabled. LOCK «3»: Ignition disabled, extractable key, mechanical anti-theft device enabled.

  • Page 13: Switch Direction Indicators

    CAUTION DO NOT TURN THE KEY TO «LOCK» OR «OFF» WHILE RIDING. Switch direction indicators (01_05) Move switch «E» to the left to indicate a left turn; move switch «E» to the right to indicate a right turn. Push the central part of switch «E» to deactivate the turn indica- tors.

  • Page 14: Light Switch

    Light switch (01_07) When the light switch «H» is set to «0», the low-beam light is on. When set to «1», the high-beam light is activated. 01_07 Start-up button (01_08) Starter button «E» 01_08...

  • Page 15: Engine Stop Button

    Engine stop button (01_09) The engine can be started when the emergency cut-off switch «I» is set to «1» RUN; if the emergency cut-off switch «I» is set to «0» OFF , the engine cannot be started, or it shuts off if already running. 01_09 The immobilizer system In order to enhance theft protection, the scooter is equipped with a «PIAGGIO IM-...

  • Page 16: Immobilizerdevice Enabled Indicator Led

    WARNING LOSING THE MASTER KEY PREVENTS ANY FURTHER REPAIR OF THE "PIAG- GIO IMMOBILIZER" SYSTEM AND OF THE ENGINE CONTROL UNIT. WARNING 01_11 KEEP THE "CODE CARD" AND THE MASTER KEY IN A SAFE PLACE (NOT IN THE VEHICLE). 01_12 Immobilizerdevice enabled indicator led (01_13) The activation of the «PIAGGIO IMMOBILIZER»...

  • Page 17: Operation

    Operation Each time the starter key «B» is removed while in the «OFF» or «LOCK» positions, the protection system activates the engine lock. Turning the starter key «B» to «ON» disables the engine lock, provided that the safety system recognises the code trans- mitted by the key.

  • Page 18: Programming The Immobilizer System

    Programming the immobilizer system (01_14) Below is described the procedure to follow for programming the PIAGGIO IMMOBIL- IZER system and/or for storing other key codes. The programming procedure should be carried out with the engine stop switch set to «RUN». START PROCEDURE Insert the «MASTER»...

  • Page 19: Accessing The Fuel Tank

    CORRECT PROGRAMMING CHECK PHASE Insert the «MASTER» key «A» disabling the transponder «C» (i.e., by tilting the key cap by 90°), and turn the key to «ON». Perform the engine start-up operation. Ensure that the engine does not start. Insert the programmed key «B» and repeat the start- up operation.

  • Page 20: Opening The Saddle

    01_16 Opening the saddle (01_17, 01_18) With the key set to «OFF» or «ON», or with engine on, it is possible to electrically open the saddle by pressing button «C». If the electric opening does not work, use the emergency lever "A". When the key is set to «LOCK» the saddle cannot be opened. 01_17...

  • Page 21: Identification

    01_18 Identification (01_19, 01_20, 01_21) The identification registration numbers consist of a prefix followed by a number stam- ped on both the chassis «A» and the engine «B». These numbers must always be indicated on spare parts requests. To read the chassis number, lift the saddle and remove the helmet compartment «C».

  • Page 22: Rear Top Box Opening

    01_21 Rear top box opening (01_22) Insert the key into the switch and press down until the glove compartment opens. If the switch is set to "LOCK", turn the key to "OFF" or "ON" before pressing it down. 01_22...

  • Page 23: Bag Clip

    Bag clip (01_23) To use the retractile bag hook «B» mounted on the knee-guard panel, pull it slightly towards the back part of the vehicle. 01_23...

  • Page 25: Use

    Vespa GTS Super 300 Chap. 02...

  • Page 26: Checks

    Checks Before using the vehicle, check: 1. There is enough fuel in the fuel tank. 2. The correct fluid level for front and rear brakes. 3. That tyres are properly inflated. 4. The correct functioning of tail lights, headlamp, turn indicators, stop light and license plate light.
  • Page 27 DO NOT ALLOW PETROL TO COME INTO CONTACT WITH HOT ENGINE OR ANY PLASTIC PARTS. CAUTION PETROL DAMAGES THE PLASTIC PARTS OF THE BODYWORK. CAUTION 02_02 USING OILS OTHER THAN THOSE RECOMMENDED CAN SHORTEN THE LIFE OF THE ENGINE. CAUTION DO NOT USE THE VEHICLE TO THE COMPLETE EXHAUSTION OF THE FUEL;...

  • Page 28: Tyre Pressure

    Tyre pressure (02_03) Check the tyre pressure and wear periodically (roughly every 500 km). Tyres feature wear indicators; replace tyres as soon as these indicators become visible on the tyre tread. Also check that the tyres do not show signs of splitting at the side or irregular tread wear;...

  • Page 29: Shock Absorbers Adjustment

    Shock absorbers adjustment (02_04) The preloading of the springs can be adjusted to 4 positions using the ring nut located in the lower part of the shock absorbers and the specific spanner supplied. Position 1: minimum preload: driver only Position 2 medium preloading: driver only Position 3 medium preloading: rider and passenger Position 4: maximum preloading: driver, passenger, and luggage.

  • Page 30: Running In

    Running in WARNING DURING THE FIRST 1000 KM DO NOT RIDE THE VEHICLE OVER 80% OF ITS MAXIMUM SPEED. AVOID TWISTING THE THROTTLE GRIP FULLY OR KEEP- ING A CONSTANT SPEED ALONG LONG SECTIONS OF ROAD. AFTER THE FIRST 1000 KM, GRADUALLY INCREASE SPEED UNTIL REACHING THE MAX- IMUM PERFORMANCE.

  • Page 31: Precautions

    CAUTION DO NOT START-UP THE ENGINE IN CLOSED AREAS BECAUSE EXHAUST GASES ARE TOXIC. 02_06 Precautions CAUTION NEVER STRESS THE ENGINE AT LOW TEMPERATURES IN ORDER TO AVOID POSSIBLE DAMAGE. BE CAREFUL NEVER TO EXCEED THE MAXIMUM SPEED WHILE RUNNING DOWNHILL, IN ORDER TO AVOID DAMAGING THE ENGINE. IN ANY CASE, IN ORDER TO PRESERVE THE ENGINE FROM PROLONGED EX- CESSIVE REVOLUTIONS, THE REVOLUTION LIMITER WILL BE ACTIVATED IF THE ENGINE SPEED EXCEEDS THE ESTABLISHED THRESHOLD.

  • Page 32: Difficult Start Up

    Difficult start up In the rare case of flooding the engine, to facilitate start-up, it is possible to try to put the vehicle into action with the gas hand grip partially or completely open. It is however necessary, once the engine is started, to take your vehicle to an Authorised Service Centre to determine the cause of this problem and to re-establish the vehicle proper functioning.

  • Page 33: Stand

    Stand (02_09) CENTRE STAND Push with your foot on the centre stand's fork «F» while lifting the vehicle backward, holding onto the handlebar. SIDE STAND With your foot push the projection of the stand «L » in order to open it and at the same time lean the vehicle on you.

  • Page 34: Safe Driving

    1. Do not continue riding in such conditions. 2. Let the clutch cool down with the engine at idle speed for a few minutes. Safe driving (02_10) WARNING SOME SIMPLE TIPS ARE PROVIDED BELOW THAT WILL ENABLE YOU TO USE YOUR SCOOTER ON A DAILY BASIS IN GREATER SAFETY AND WITH MORE PEACE OF MIND.
  • Page 35 6. Avoid starting off by mounting the scooter while it is still resting on its stand. In any case, the rear wheel should not be turning when in comes into contact with the ground, in order to avoid abrupt departures. 7.

  • Page 37: Maintenance

    Vespa GTS Super 300 Chap. 03 Maintenance...

  • Page 38: Engine Oil Level

    Engine oil level In 4T engines, engine oil is used to lubricate the distribution elements, main bearings and thermal group. An insufficient quantity of oil can cause serious damage to the engine itself. In all four-stroke engines, a loss of efficiency in oil performance and consumption should be considered normal.

  • Page 39: Warning Light (Insufficient Oil Pressure)

    Warning light (insufficient oil pressure) The vehicle is equipped with a warning light that lights up when the key is turned to the «ON». However, this light should switch off once the engine has been started. If the light comes on while braking, at idle speed or while turning a corner, it is necessary to check the oil level and top it up if required.

  • Page 40: Hub Oil Level

    CAUTION USED OILS CONTAIN SUBSTANCES HARMFUL TO THE ENVIRONMENT. FOR OIL CHANGE, CONTACT AN AUTHORISED PIAGGIO SERVICE CENTRE, AS THEY ARE EQUIPPED TO DISPOSE OF USED OILS IN AN ENVIRONMENTALLY FRIENDLY AND LEGAL WAY. CAUTION USING OILS OTHER THAN THOSE RECOMMENDED CAN SHORTEN THE LIFE OF THE ENGINE.
  • Page 41 N.B. THE NOTCHES ON THE HUB OIL LEVEL DIPSTICK, EXCEPT THE ONE INDI- CATING THE MAX LEVEL, REFER TO OTHER MODELS BY THE MANUFACTUR- ER AND HAVE NO SPECIFIC FUNCTION FOR THIS MODEL. CAUTION 03_04 RIDING THE VEHICLE WITH INSUFFICIENT HUB LUBRICATION OR WITH CON- TAMINATED OR IMPROPER LUBRICANTS ACCELERATES THE WEAR AND TEAR OF THE MOVING PARTS AND CAN CAUSE SERIOUS DAMAGE.

  • Page 42: Tyres

    CAUTION FOR OIL REPLACEMENT, CONTACT ANY AUTHORISED SERVICE CENTRE AS THEY ARE EQUIPPED TO DISPOSE OF USED OILS IN AN ENVIRONMENTALLY FRIENDLY AND LEGAL WAY. Recommended products AGIP ROTRA 80W-90 Rear hub oil SAE 80W/90 Oil that exceeds the requirements of API GL3 specifications Characteristic Rear hub oil 250 cc...

  • Page 43: Spark Plug Dismantlement

    TYRES MUST BE REPLACED WHEN THE TREAD REACHES THE WEAR LIMITS SET FORTH BY LAW. TYRES Front tyre 120/70 - 12'' 51P Tubeless Rear tyre Tubeless 130/70 12'' 62P TYRE INFLATION PRESSURE Front tyre pressure (with 1.8 bar (-) passenger) Rear tyre pressure (with 2.2 bar (-) passenger)

  • Page 44: Removing The Air Filter

    6. Use the box-spanner supplied only for locking. 7. Place the cap fully over the spark plug. CAUTION SPARK PLUGS MUST BE REMOVED WHEN THE ENGINE IS COLD. SPARK PLUGS MAINTENANCE OPERATIONS ARE DESCRIBED IN THE SCHEDULED MAINTENANCE TABLE. USING NON-CONFORMING ELECTRONIC CENTRAL 03_07 UNITS AND ELECTRONIC IGNITIONS OR SPARK PLUGS OTHER THAN THOSE PRESCRIBED MAY SERIOUSLY DAMAGE THE ENGINE.

  • Page 45: Recommended Products

    5. unscrew the fixing screws «C» that can be reached once the helmet compartment has been removed; 6. Unscrew the screws «D» and remove the air filter cover. Remove the filtering element and clean it with water and shampoo; then dry it with a clean cloth and short blasts of compressed air.

  • Page 46: Cooling Fluid Level

    Cooling fluid level (03_12, 03_13) The engine is cooled by a forced-circulation coolant system. The cooling circuit holds coolant consisting of a mixture of 50% de-ionised water and 50% glycol ethylene- based antifreeze solution with corrosion inhibitors. The recommended coolant is supplied premixed and ready to use.

  • Page 47: Checking The Brake Oil Level

    WARNING IN ORDER TO AVOID HARMFUL FLUID LEAKS WHILE RIDING, IT IS IMPORTANT TO MAKE SURE THAT THE LEVEL NEVER EXCEEDS THE MAXIMUM VALUE. IN ORDER TO GUARANTEE THE PROPER FUNCTION OF THE ENGINE, IT IS NECESSARY TO KEEP THE RADIATOR GRILLE CLEAN. Recommended products AGIP PERMANENT SPEZIAL coolant...
  • Page 48 Under normal climatic conditions, the brake fluid should be changed every 2 years. This operation must be carried out by trained personnel; take your vehicle to an au- thorised Service centre or Dealer. WARNING ONLY USE DOT 4 CLASS BRAKE FLUIDS. COOLING SYSTEM FLUIDS ARE HIGHLY CORROSIVE.

  • Page 49: Battery

    Battery (03_16, 03_17) To reach the battery «D », proceed as follows: 1. rest the scooter on its centre stand; 2. unscrew the 4 screws «A», remove the footrest «B». 3. remove the two battery fixing screws «C». WARNING 03_16 IN ORDER TO AVOID DAMAGING THE ELECTRICAL SYSTEM, NEVER DISCON- NECT THE WIRING WHILE THE ENGINE IS RUNNING.

  • Page 50: Use Of A New Battery

    12V - 12 Ah Use of a new battery Ensure that the terminals are connected correctly and check voltage. CAUTION DO NOT REVERSE THE POLARITY: RISK OF SHORT CIRCUIT AND DAMAGE TO THE ELECTRICAL SYSTEM. WARNING SPENT BATTERIES ARE HARMFUL FOR THE ENVIRONMENT. COLLECTION AND DISPOSAL SHOULD BE CARRIED OUT IN COMPLIANCE WITH CURRENT REGULATIONS.

  • Page 51: Fuses

    - Take your vehicle to a garage (as indicated in the "Vehicle not used for extended periods" section) to have the battery removed. Have the battery cleaned, charged fully and stored in a dry, ventilated place. Recharge at least once every two months. N.B.
  • Page 52 3. one fuse «C» located under the helmet compartment on the left fairing. The chart shows the position and characteristics of the fuses in the vehicle. CAUTION BEFORE REPLACING A BLOWN FUSE, FIND AND SOLVE THE FAILURE THAT CAUSED IT TO BLOW. NEVER TRY TO REPLACE THE FUSE WITH ANY OTHER MATERIAL (E.G., A PIECE OF ELECTRIC WIRE).
  • Page 53 remote control, immobilizer aerial, ECU. Fuse No. 3 Capacity: 15A Protected circuits: Injection load (via remote control), ECU. Fuse No. 4 Capacity: 10 A Protected circuits: Turn indicators, pre-installation for anti- theft device, instrument panel. Fuse No. 5 Capacity: 7.5 A Protected circuits: Horn,...
  • Page 54 Fuse No. 9 Capacity: 7.5 A Protected circuits: Tail lights, instrument panel lighting. 03_18 03_19...
  • Page 55 03_20 03_21 03_22...

  • Page 56: Front Light Group

    03_23 Front light group (03_24, 03_25, 03_26, 03_27) To remove the front headlight assembly, proceed as follows: 1. Remove the rear-view mirrors. 2. Remove the screw «A» of the legshield grille. 3. Remove the screw «B» fixing the front handlebar cover. 4.

  • Page 57: Headlight Adjustment

    N.B. IF MISTING IS NOTICED ON THE INSIDE OF THE HEADLAMP GLASS, THIS DOES NOT INDICATE A FAULT AND IS RELATED TO THE HUMIDITY AND/OR TO LOW TEMPERATURES. THE PHENOMENON SHOULD QUICKLY DISAPPEAR WHEN THE LIGHT IS SWITCHED ON. THE PRESENCE OF DROPS OF WATER, ON THE OTHER HAND, COULD INDI- CATE THAT WATER IS INFILTRATING.

  • Page 58: Front Direction Indicators

    N.B. THE ABOVE PROCEDURE COMPLIES WITH THE EUROPEAN STANDARDS RE- GARDING MAXIMUM AND MINIMUM HEIGHT OF LIGHT BEAMS. REFER TO THE STATUTORY REGULATIONS IN FORCE IN EVERY COUNTRY WHERE THE ve- hicle IS USED. 03_29 Front direction indicators (03_30) To replace the front turn indicator bulbs, remove the tail light taking out the retaining screw "A", remove the bulb holder from its fitting;...

  • Page 59: Rear Optical Unit

    Rear optical unit (03_31) Remove screw «A» to remove the rear headlight assembly. Access to taillight bulbs, stop light bulb and license plate bulb. To reassemble, repeat the operation in the reverse order. N.B. IF MISTING IS NOTICED ON THE INSIDE OF THE HEADLAMP GLASS, THIS DOES NOT INDICATE A FAULT AND IS RELATED TO THE HUMIDITY AND/OR TO LOW TEMPERATURES.

  • Page 60: Rear-View Mirrors

    Rear-view mirrors Adjust the mirrors by applying slight pressure to the side of the mirror to move it to the desired position. Front and rear disc brake (03_33, 03_34) The brake disc and pad wear is automatically compensated, therefore it has no effect on the functioning of the front and rear brakes.

  • Page 61: Puncture

    CAUTION THE PRESENCE OF SAND, MUD, SNOW MIXED WITH SALT, ETC. ON THE ROAD, CAN DRASTICALLY REDUCE THE DURATION OF THE BRAKE PADS. IN ORDER TO AVOID THIS, WE RECOMMEND WASHING THE VEHICLE FRE- QUENTLY WHEN RIDING IN THESE ROAD CONDITIONS. Puncture The vehicle is equipped with Tubeless tyres (without inner tube).

  • Page 62: Periods Of Inactivity

    Periods of inactivity (03_35) We recommend carrying out the following operations: 1. Clean the scooter thoroughly and then cover it with a canvas; 2. With the engine off and the piston in the bottom dead centre position, remove the spark plug, and pour into its hole 1 t0 2 cc of the recommended oil. Operate the starter button 1-2 times for roughly 1 second to turn the engine over slowly, then insert the spark plug again;...
  • Page 63 WARNING IF THE SCOOTER IS USED ON DUSTY ROADS IT IS NECESSARY TO SERVICE THE TRANSMISSION COVER FILTER SPONGE MORE FREQUENTLY. CAUTION DETERGENTS CAN POLLUTE WATER. THE VEHICLE MUST BE WASHED AT A WASH STATION EQUIPPED WITH A SPECIAL WATER PURIFICATION SYSTEM. WARNING THE USE OF A HIGH-PRESSURE WATER JET IS STRONGLY DISCOURAGED FOR ANY ENGINE CLEANING OPERATION;...
  • Page 64 CLOTHS SOAKED IN PETROL, DIESEL OIL OR KEROSENE FOR CLEANING THE PAINTED OR PLASTIC SURFACES SO AS NOT TO DAMAGE THE LUSTRE FINISH OR ALTER THE MECHANICAL PROPERTIES. STARTING FAILURE Emergency switch in «OFF» Set the switch back to «ON» Fuse blown Replace the blown fuse and have the vehicle checked by an...
  • Page 65 LACK OF COMPRESSION Loose spark plug. Screw in the spark plug tightly Cylinder head loose, piston gas Contact an Authorised Service rings worn. Centre. Valve stuck Contact an Authorised Service Centre. HIGH CONSUMPTION AND LOW PERFORMANCE Air filter blocked or dirty. Clean with water and shampoo and impregnate with petrol and specific oil (section «Removing the air...
  • Page 66 INEFFICIENT SUSPENSIONS Shock absorber fault, oil leak, end Contact an Authorised Service buffer damaged; shock absorber Centre. preloading incorrectly set IRREGULAR AUTOMATIC TRANSMISSION Variator rollers and/or driving belt Contact an Authorised Service damaged Centre.

  • Page 67: Technical Data

    Vespa GTS Super 300 Chap. 04 Technical data...
  • Page 68 04_01...
  • Page 69 ENGINE TECHNICAL DATA Type Single-cylinder, 4-stroke Cubic capacity 278 cm³ Bore x Stroke 75x63 mm Compression ratio 11 ± 0.5 : 1 Engine idle speed 1,700 ± 100 rpm Timing system 4 valves, single overhead camshaft, chain-driven. Valve clearance Inlet: 0.10 mm Outlet: 0.15 mm Max.
  • Page 70 Ignition Electronic inductive discharge ignition, high efficiency, with separate HV coil. α/N three-dimensional map Ignition advance managed by control unit Spark plug NGK CR8EKB Alternative spark plug Fuel supply Electronic injection with Ø 32-mm throttle body and electric fuel pump. Fuel Unleaded petrol (95 RON) Exhaust muffler...
  • Page 71 Rear brake disc brake, diameter 220 mm, with hydraulic servo operated from the handlebar with the left-hand lever. Wheel rim type Light alloy rims. Front rim 12'' x 3.00 Rear rim 12'' x 3.00 Front tyre 120/70 - 12'' 51P Tubeless Rear tyre Tubeless 130/70 12'' 62P Front tyre pressure (with...

  • Page 72: Kit Equipment

    Kit equipment (04_02) One box-spanner for spark plugs; one twin screwdriver; one special spanner for ad- justing the rear shock absorber. The tools are arranged in the front case. 04_02...

  • Page 73: Spare Parts And Accessories

    Vespa GTS Super 300 Chap. 05 Spare parts and accessories...

  • Page 74: Warnings

    Warnings WARNING TO PREVENT ACCIDENTS AND TO GUARANTEE PROPER STABILITY, PER- FORMANCE AND SAFETY, RIDE THE VEHICLE VERY CAREFULLY WHEN IT IS FITTED WITH ACCESSORIES OR WITH UNUSUAL LOADS. WARNING IT IS ALSO RECOMMENDED THAT "ORIGINAL PIAGGIO SPARE PARTS" BE USED, AS THESE ARE THE ONLY ONES OFFERING YOU THE SAME QUALITY GUARANTEE AS THOSE INITIALLY FITTED ON THE SCOOTER.
  • Page 75 WARNING NEVER RIDE THE SCOOTER EQUIPPED WITH ACCESSORIES (TOP BOX AND/ OR WINDSHIELD) AT A SPEED HIGHER THAN 100 km/h. THE SCOOTER CAN BE RIDDEN AT A HIGHER SPEED WITHOUT THE ACCES- SORIES MENTIONED BEFORE WITHIN THE LIMITS ESTABLISHED BY LAW. IF THERE SHOULD BE NON-PIAGGIO ACCESSORIES INSTALLED, OR AN AB- NORMAL LOAD, OR IF THE SCOOTER IS NOT IN A GENERALLY GOOD CON- DITION, OR WHENEVER WEATHER CONDITIONS DEMAND IT, SPEED SHOULD...

  • Page 77: Programmed Maintenance

    Vespa GTS Super 300 Chap. 06 Programmed maintenance...
  • Page 78 Scheduled maintenance table (06_01) Adequate maintenance is fundamental to ensuring long-lasting, optimum operation and performance of your vehicle. To this end, a series of checks and maintenance operations (at the owner's expense) have been suggested, which are included in the summary table on the following page. Any minor faults should be reported without delay to an Authorised Service Centre or Dealer without waiting until the next scheduled service to solve it.
  • Page 79 km x 1,000 Coolant * Engine oil Hub oil Brake pads Sliding blocks / variable speed rollers Tyre pressure and wear Vehicle road test Suspensions Steering I: CHECK AND CLEAN, ADJUST, LUBRICATE OR REPLACE IF NECESSARY. C: CLEAN, R: REPLACE, A: ADJUST, L: LUBRICATE * Replace every 2 years RECOMMENDED PRODUCTS TABLE Product...
  • Page 80 Product Description Specifications AGIP GP 330 Grease for brake levers, throttle White calcium complex soap-based spray grease with NLGI 2; ISO-L-XBCIB2 AGIP CITY HI TEC 4T Engine oil SAE 5W-40, API SL, ACEA A3, JASO MA Synthetic oil AGIP BRAKE 4 Brake fluid FMVSS DOT 4 Synthetic fluid AGIP PERMANENT SPEZIAL...
  • Page 81 TABLE OF CONTENTS Turn indicators: 59 Tyre pressure: 28 Air filter: 44 Fuel: 19 Light switch: 14 Tyres: 42 Fuses: 51 Battery: 49, 50 Maintenance: 37, 77, 78 Brake: 47, 60 Headlight: 57 Mirrors: 60 Horn: 13 Hub oil: 40 Clock: 11 Saddle: 20 Scheduled maintenance: 78...
  • Page 82 The descriptions and illustrations given in this publication are not binding. While the basic specifications as described and illustrated in this manual remain unchanged, PIAGGIO-GILERA reserves the right, at any time and without being required to update this publication beforehand, to make any changes to components, parts or accessories, which it considers necessary to improve the product or which are required for manufacturing or con- struction reasons.
