HP ProLiant DL385 Generation 2 (G2) Quickspecs

Hide thumbs

Advertisement

Quick Links

Download this manual
QuickSpecs
Overview
Front View:
Front View:
Front View:
Front View:
1. 1. 1. 1.
Eight sockets for PC2-5300 DIMMs (DDR2-667) with
Advanced ECC
2. 2. 2. 2.
Hot-plug fans, full redundancy
3. 3. 3. 3.
Systems Insight Display
4. 4. 4. 4.
Quick release lever for rapid server access
5. 5. 5. 5.
Support for eight Small Form Factor hot plug hard drives
bays
6. 6. 6. 6.
Front LEDs (show server status) and Unit Identification
button/LED (for easy in rack server identification)
7. 7. 7. 7.
Two front USB ports (+two rear, one internal USB port)
8. 8. 8. 8.
AMD Dual Core Rev. F Processor (Performance models
include two processors)
9. 9. 9. 9.
Hot plug power supply, redundancy option (High
performance models include redundant power supply)
10.
10.
10.
10.
Three PCI-E non-hot plug expansion slots (or optional
mixed PCI-X/E expansion cage or optional x16 PCI-E
expansion cage). Two additional PCI-E slots embedded on
system board. This provides Four available PCI-E non-hot
plug expansion slots for use; one consumed by Smart Array
Controller
11.
11.
Quick removal access panel
11.
11.
What's New
What's New
What's New
What's New
New speed for Rev F: AMD Opteron Processor 2218 HE (High Efficiency) (2.6 GHz / 68 Watts)
DA - 12565
North America — Version 22 — July 25, 2007
HP ProLiant DL385 Generation 2 (G2)
HP ProLiant DL385 Generation 2 (G2)
HP ProLiant DL385 Generation 2 (G2)
HP ProLiant DL385 Generation 2 (G2)
Rear View:
Rear View:
Rear View:
Rear View:
1. 1. 1. 1.
T-10/T-15 Torx screwdriver
2. 2. 2. 2.
External option blank
3. 3. 3. 3.
NIC 2 connector
4. 4. 4. 4.
NIC 1 connector
5. 5. 5. 5.
Power supply bay 2
6. 6. 6. 6.
Power cord connector
7. 7. 7. 7.
Power supply bay 1 (populated)
8. 8. 8. 8.
Integrated Lights-Out 2 (iLO 2) connector
9. 9. 9. 9.
Video connector
10.
10.
10.
10.
USB connectors (2)
11.
11.
11.
11.
Serial connector
12.
12.
12.
12.
Mouse connector
13.
13.
13.
13.
Keyboard connector
14.
14.
14.
14.
Expansion slot 1
15.
15.
15.
15.
Expansion slot 2
16.
16.
16.
16.
Expansion slot 3
17.
17.
17.
17.
Expansion slot 4
18.
18.
18.
18.
Expansion slot 5
Page 1
