Instructions for Installation and Use
Note: Timer must be set to 'Time of Day' and 'Manual'
Note: Ensure that the oven is securely fixed to the
Before installation fill in the product details on the back cover of this
booklet. The information can be found on the rating plate.
You must read the instructions prior to installing and using the appliance
before the oven can be used.
cabinet before use.
To the Installer
and then retain them for future reference.
BS42
BS52
To the User
Advertisement
Table of Contents
Related Manuals for Hotpoint BS42 BS52
Summary of Contents for Hotpoint BS42 BS52
- Page 1 Instructions for Installation and Use Note: Timer must be set to ‘Time of Day’ and ‘Manual’ Note: Ensure that the oven is securely fixed to the Before installation fill in the product details on the back cover of this booklet. The information can be found on the rating plate. You must read the instructions prior to installing and using the appliance and then retain them for future reference.
-
Page 2: Table Of Contents
CONTENTS Introduction For Your Safety – Always For Your Safety – Never Know Your Oven Control Panel Oven Timer Operation Know Your Timer Electronic Clock & Automatic Oven Timer Operation Grill Pan and Handle Grilling Procedure Using the Oven as a Fan Oven Using the Oven for Other Functions Temperature Conversion Scale Oven Temperature Charts... -
Page 3: Introduction
INTRODUCTION Your new cooker is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. The cooker is designed specifically for domestic use and responsibility will not be accepted for use in any other installation. -
Page 4: For Your Safety - Always
FOR YOUR SAFETY When used properly your appliance is completely safe but as with any electrical product there are certain precautions that must be observed. PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE. Always Always make sure you remove all packaging and literature from inside the oven/grill compartment before switching on for the first time. -
Page 5: For Your Safety - Never
FOR YOUR SAFETY Never Never leave children unsupervised where a cooking appliance is installed as all cooking surfaces will be hot during and after use. Never allow anyone to sit or stand on any part of the appliance. Never store items above the appliance that children may attempt to reach. Never remove the oven shelves whilst the oven is hot. -
Page 6: Know Your Oven
KNOW YOUR OVEN Oven Light Meat/Grill pan Oven Fan Rating plate Inner Door Glass Electronic Clock / Grill Timer Control Oven Control and Selector Grill Element Stayclean Liners 2 Oven Shelves Door Switch... -
Page 7: Control Panel
CONTROL PANEL To release any control knob simply press its centre. After use knobs can be returned to the storage/safety position by pressing in the knob centre. CONTROL MARKINGS Control Description Knob Oven & Grill Selector Oven & Grill Selector A &B &... -
Page 8: Oven Timer Operation
OVEN TIMER OPERATION Note: Timer must be set to ‘Time of Day’ and ‘Manual’ before the oven can be used. AUTOMATIC COOKING The Oven can be controlled by the Automatic Timer. HINTS ON AUTOMATIC COOKING 1. Select foods which will require the same cooking time and temperature. 2. -
Page 9: Know Your Timer
KNOW YOUR TIMER CLOCKFACE The timer incorporates a 24 hour clock. Ensure the correct time of day is always set, before using you cooker. PLEASE NOTE THAT THE DISPLAY WILL DIM BETWEEN 22.00 HOURS AND 06.00 HOURS TO PREVENT GLARE. However, should you operate the timer during these hours the display will return to normal brightness for a few seconds and then dim again. -
Page 10: Electronic Clock & Automatic Oven Timer Operation
ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION SETTING THE TIME OF DAY Step 1 Make sure all oven controls are turned Off. Step 2 Check the electricity supply to the cooker is turned on. Step 3 When switched on the display will show 0.00 and Auto symbol will be Step 4 Press &... - Page 11 ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION AUTO COOKING PROGRAMMES There are two Auto Cooking programmes that can be selected using your timer:– (a) To set the timer to switch the oven(s) On and Off Automatically (b) To set timer to switch on immediately and OFF automatically after a set cook period. a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY This allows you to cook at a specified time for a chosen period before the oven switches off Automatically.
- Page 12 ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing the Cook Period button. Note 2 When cooking automatically the End Time can be checked at any time by simply pressing the End Time button.
- Page 13 ELECTRONIC CLOCK & AUTOMATIC OVEN TIMER OPERATION TO CANCEL AN AUTO COOKING PROGRAMME BEFORE THE COOK PERIOD HAS FINISHED. Step 1 Turn the oven control(s) to the OFF position. Step 2 Press and hold in the Step 3 With the Step 4 Release the Step 5 Press the Note 1...
-
Page 14: Grill Pan And Handle
GRILL PAN & HANDLE The grill pan handle is detachable from the pan, to facilitate cleaning and storage. The grill pan handle can be fixed as follows: Step 1 Step 2 Step 1 Remove screw & washers from the grill pan bracket (a). Step 2 Tilt the handle over the recess (b). -
Page 15: Grilling Procedure
GRILLING PROCEDURE Note: DO NOT allow young children near to the appliance when the grill is in use as the Step 1 Ensure oven timer is set to manual. Ensure the oven shelf is in the correct position (see Guide to Grilling Successfully). -
Page 16: Using The Oven As A Fan Oven
USING THE OVEN FOR FAN COOKING Since a circulaire fan oven heats up more quickly, and generally cooks food at a lower temperature than a conventional oven, pre-heating is often unnecessary. For guides on “pre- heating” , “cooking temperatures” and “cooking times” , see “Oven Temperature Charts” later in book. - Page 17 USING THE OVEN FOR FAN COOKING FAN OVEN OPERATION Step 1 Ensure oven timer is set to manual. Ensure that the oven shelf is in the correct position. Place food centrally on the shelf ensuring the oven door is fully closed. Step 2 Turn knob (A) clockwise and select the required cooking temperature .
-
Page 18: Using The Oven For Other Functions
USING THE OVEN FOR OTHER FUNCTIONS ‘S’ SLOW COOK SETTING This is used for slow cooking, keeping food warm and warming plates for short periods. Extra care should be taken when warming bone china, as it may be damaged in a hot oven. DO NOT place food or plates directly on the oven floor as this could damage both the oven lining and the plates which are being warmed. -
Page 19: Temperature Conversion Scale
TEMPERATURE CONVERSION SCALE Mark Main Conventional Oven – – Main Oven... -
Page 20: Oven Temperature Charts
OVEN TEMPERATURE CHARTS – MEAT Food Meat Beef Lamb Pork Veal Chicken/Turkey up to 4kg (8lb) Turkey up to 5.5kg (12lb) Turkey over 5.5kg (12lb) Casserole / Stews IF USING ALUMINIUM FOIL 1. Never allow foil to touch sides of oven. 2. Never cover interior with foil. 3. -
Page 21: Oven Temperature Charts
OVEN TEMPERATURE CHARTS – BAKING Baking Note: Up to three shelves may be used in this oven. The position of these is not important providing they are evenly spaced. Pre- Food heat Scones Small Cakes Victoria Sandwich Sponge Sandwich (Fatless) Swiss Roll Semi-rich Fruit Cake... -
Page 22: Cooking Results Not Satisfactory
COOKING RESULTS NOT SATISFACTORY GRILL Uneven cooking front to back Fat splattering BAKING GENERAL Uneven rising of cakes Sinking of cakes Over/undercooking Ensure that the grill pan is positioned centrally below the grill element. Ensure that the grill pan is not lined with foil. Ensure that the grill setting is not too high. -
Page 23: Care & Cleaning
CARE AND CLEANING Warning: Before cleaning, please ensure that the electricity supply to the appliance is switched off and the appliance is fully cold. 1. “STAYCLEAN” OVEN LINERS MAIN OVEN SIDE LINERS AND REAR PANEL (a) How "Stayclean" works. The surfaces of the "Stayclean" oven liners are treated with a special vitreous enamel which absorbs cooking soils. -
Page 24: Cleaning The Oven
CARE AND CLEANING 2. CLEANING THE OVEN REMOVABLE GRILL ROOF PANEL (not all models or models fitted with high speed grill) OVEN SHELVES MAIN OVEN BASE (a) Base of Main Oven. Wipe out the oven with a damp soapy cloth. For more stubborn stains on the base of the oven use a well soaped fine steel wool soap pad. -
Page 25: Care And Cleaning
CARE AND CLEANING 3. CONTROL PANEL / TRIMS / INNER DOOR PANEL & GLASS OVEN DOOR TRIMS 4. REPLACEMENT OF THE OVEN LAMP MAIN OVEN LAMP 5. HOW TO CLEAN THE LAMP LENS MAIN OVEN LAMP (a) Control Panel Regularly wipe with a clean, damp cloth and polish with a clean, dry cloth. -
Page 26: Care & Cleaning
CARE AND CLEANING Take particular care not to damage the inner surface of the door inner glass that is coated with a heat reflective layer. Do not use scouring pads, or abrasive pow- der, which will scratch the glass. Ensure that the glass panel is not subjected to any sharp mechanical blows. - Page 27 INSTALLATION INSTRUCTIONS IMPORTANT This equipment is designed specifically for domestic purposes and Hotpoint LTD cannot accept responsibility if used in any other type of installation. This appliance must not be installed over any appliance that generates heat. For your own safety, we recommend that your appliance is installed by a competent person –...
-
Page 28: Electrical Installation
INSTALLATION INSTRUCTIONS 2. OVEN UNIT HOUSING CABINETS (a) The oven unit housing cabinet dimensions must comply with Fig. 3 and Fig. 4. (b) An air gap of 50mm minimum must be provided at the rear of any top or bottom cupboards or shelves for ventilation. -
Page 29: Final Installation
INSTALLATION INSTRUCTIONS Any spare cable must be coiled either behind the oven (not more than 30cm above the base of the oven recess) or pushed into the air gap below the oven after installation. Where a hob is fitted adjacent to or above an oven a 32 amp or 45 amp double pole switch with a minimum contact clearance of 3mm should be used to feed both units via separate suitably rated cables. -
Page 30: Installation Instructions
INSTALLATION INSTRUCTIONS Ventilation Slot if cabinet doesn't fit to ceiling 50mm Fig. 1 Oven 50mm Tall Cabinet When fitting a hob above an oven always use these installation instructions in conjunction with the hob instructions. Use 2.5mm High Temp Cable. Refer to Electrical Installation. -
Page 31: Installation
INSTALLATION INSTRUCTIONS Fig. 4 Double Pole Control Switch Cable if Hotplate fitted Conduit Box Cable if hob fitted adjacent to oven Cable to Oven Refer to Electrical Installation Fig. 5 Single Oven in tall Cabinet 585mm max 578mm if cooker trim is to overlap top edge... -
Page 32: Something Wrong
SOMETHING WRONG? Before calling a Service Engineer, please check through the following lists. Problem Slight odour or small amount of smoke when grill / oven used first time Nothing Works Main oven does not work, but the grill works Timer Display shows "0:00" with "Auto"... -
Page 33: Something Wrong
SOMETHING WRONG? Grilling is uneven Oven lamp does not work Condensation on the wall at the rear of the cooker. Steam / Condensation in the oven after use. If you have been through the above list and there is still a problem, contact Service (see KEY CONTACTS, back page) . -
Page 36: Key Contacts
Republic of Ireland: (01) 842 6836 08701 506070 For further product information All Hotpoint Services are offered as an extra benefit and do not affect your statutory rights. General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB PRINTED BY SIMLEX . FOUR ASHES, WOLVERHAMPTON.
