Advanced, Adaptable Video Wall Processor
Planar's Indisys Extensity Video Wall Processor is designed for the capture, management and display of high
resolution sources on a video wall. It is built on a simplified and modular graphics processing approach that utilizes
today's most advanced 4K-capable electronics. This allows the easy configuration of a system to meet specific wall
requirements and support a wide range of inputs. Indisys Extensity scales from small, simple walls to large, complex
walls of over 100 displays. It has the capability to share information across multiple walls and the full enterprise.
Indisys Extensity is the latest generation of the field-proven architecture deployed in hundreds of mission-critical
control rooms around the globe. Indisys Extensity is designed to integrate tightly with Planar's Clarity Matrix LCD Video
Wall System and Clarity LED Series rear projection display walls. The elegant approach allows for high system resiliency
and flexibility in building your wall control system. It is designed for 24/7 operation, keeping video wall downtime to
a minimum.
Indisys Extensity
VIDEO WALL PROCESSOR
Advertisement
Summary of Contents for Planar MultiCrop X
- Page 1 Indisys Extensity is the latest generation of the field-proven architecture deployed in hundreds of mission-critical control rooms around the globe. Indisys Extensity is designed to integrate tightly with Planar's Clarity Matrix LCD Video Wall System and Clarity LED Series rear projection display walls. The elegant approach allows for high system resiliency and flexibility in building your wall control system.
- Page 2 24/7 operation and exceptional visual performance, keeping video wall downtime to a minimum. Extensity Processors Image Master X-D MultiCrop X 1U rack processor for Clarity Matrix Video Walls and Planar UltraRes Series Internal processor in Planar rear projection displays (Front) 4x DisplayPort 1.1 Input and Image Master X Loopout pairs.
- Page 3 Complete control of any image on any size wall Control the wall Capture sources Share information Flexible Setup, Control, and Monitoring Software Indisys Management Suite (IMS) software provides a visual environment to control the system set up and the entire wall layout. Sources can be placed Video Wall Management throughout the wall from display-by-display, section-by-section, or layered Manage a wide variety of visual sources...
- Page 4 Desktop Collaboration The Indisys Desktop Service (IDS) capability provides network-based collaboration for the Indisys control room. IDS allows authorized PC users to more freely and directly share visual information with one another, improving collaborative decision making. Through its software KVM, desktop control can be delegated and via network capture, casual participants can share visual information –...
- Page 5 X, Image Master X or Image Hub X standard display. or Image Master X. Typical Uses One MultiCrop X processer per Clarity One IMX per 4 to 8 Clarity Matrix Varies on the number of source inputs, Varies on the number of source inputs,...
-
Page 6: Remote Monitoring
Rack Mounted *Contact a Planar representative regarding support for other operating systems www.planar.com Planar is a trademark of Planar Systems, Inc. All other trade and service marks are the property of their holders. sales@planar.com Copyright© 2014 Planar Systems, Inc. All rights reserved. This document may...
