xStack® DGS-3420 Series Layer 2+ Managed Stackable Gigabit Switch Hardware Installation Reference Guide

Password Protection

The DGS-3420 Series Switches do not have a default user name and password. One of the first tasks when settings up
the Switch is to create user accounts. Logging in using a predefined administrator-level user name will give the user
privileged access to the Switch's management software.
After the initial login, define new passwords for both default user names to prevent unauthorized access to the Switch,
and record the passwords for future reference.
To create an administrator-level account for the Switch, do the following:
1. At the CLI login prompt, enter create account admin followed by the <username> and press the Enter key.
2. The Switch will then prompt the user to provide a password. Type the administrator <password>and press the
Enter key.
3. Once entered, the Switch will again ask the user to insert the same password again to verify it. Type the same
password and press the Enter key.
4. A new administrative account is created once the "Success" prompt appears.
NOTE: Passwords are case sensitive. User names and passwords can be up to 15 characters in length.
The sample below illustrates a successful creation of a new administrator-level account with the user name
"newmanager".
DGS-3420-28SC:admin# create account admin newmanager
Command: create account admin newmanager
Enter a case-sensitive new password:*********
Enter the new password again for confirmation:*********
Success.
DGS-3420-28SC:admin#
NOTICE: CLI configuration commands only modify the running configuration file and are not saved
when the Switch is rebooted. To save all your configuration changes in nonvolatile storage, you must
use the save command to copy the running configuration file to the startup configuration.

Assigning IP Addresses

Each Switch must be assigned its own IP Address, which is used for communication with an SNMP network manager or
other TCP/IP application (for example BOOTP, TFTP). The Switch's default IP address is 10.90.90.90. You can change
the default Switch IP address to meet the specification of your networking address scheme.
The Switch is also assigned a unique MAC address by the factory. This MAC address cannot be changed, and can be
found by entering the command
Figure 4–3 Create account command
into the command line interface, as shown below.
show switch
32
