Rear view

I L
TEM
AC IN
1.
COMPONENT
2.
COMPOSITE
3.
VGA
4.
HDMI – 1
5.
HDMI – 2
6.
DC 12V TRIGGER
7.
Security Lock
8.
Speaker
9.
IR receiver
10.
AUDIO IN (L and R)
11.
AUDIO IN
12.
RS-232C
13.
AUDIO OUT
14.
Note:
If your video equipment has various input sources, it is recommended to connect in priority of
HDMI, component, S-Video, Composite for better picture quality.
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.
1 2
ABEL
Connect the POWER CABLE.
Connect the COMPONENT CABLE from a display.
Connect the COMPOSITE CABLE from a video device.
Connect the RGB CABLE from a computer.
Connect the HDMI CABLE from an HDMI device.
Connect the HDMI CABLE from an HDMI device.
Connect a 12V screen trigger (200ma max).
Secure to permanent object with a security lock system.
Outputs the projector audio.
Receives the remote control IR signal.
Connect the AUDIO CABLE from an input device.
Connect an AUDIO CABLE from an input device.
Connect RS-232 serial port cable for command control.
Connect an AUDIO CABLE to external speaker system.
3 4 5
14 13 12 11
D
ESCRIPTION
