Related Manuals for Hoover Upright Bagless Vacuum Cleane
Summary of Contents for Hoover Upright Bagless Vacuum Cleane
- Page 1 HOOVER Bagless Upright Thank you for your purchase! ® Owner’s Manual ENGLISH pp. 1-14 ESPAÑOL pág. 15-22 FRANÇAIS p. 23-30 This product was designed for easy assembly (see page 3) ®...
-
Page 2: Table Of Contents
• Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, take it to a Hoover Factory Service Center or Authorized Hoover Warranty Service Dealer (Depot). -
Page 3: Assembling Cleaner
If you need any assistance: Visit our website at www.hoover.com. Click on the “Service” button to find the service outlet nearest you OR Call 1-800-944-9200 for an automated referral of service outlet locations (U.S. only) OR Call 1-330-499-9499 to speak with a representative in our Consumer Response Center. -
Page 4: Attach Hose
Place nuts in recessed areas on front of handle. Hold each nut in place while tightening each bolt securely with a Phillips screw driver. Attach hose Align end of hose with projections (A) over slots (B) in dirt duct. Position tools 1-11 Place smaller unridged end of wand into bottom of rack. -
Page 5: How To Use
2. How to use Cleaner description Polarized plug To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. -
Page 6: Transporting Cleaner
Handle positions The handle of your cleaner has three positions; upright for storage and when using cleaning tools; operating posi- tion for general operation on carpet and floors; low for reaching under low furniture. Step on handle release lever to lower handle. HIGH BARE FLOOR Carpet height... -
Page 7: Stair Cleaning
2-10 Cleaning lightweight flexible rugs Stand on one end of rug and move cleaner toward other end or edge. Before reaching edge, push down on handle. This will lift up the nozzle (front of cleaner) as shown and will prevent rug from clinging to cleaner. -
Page 8: Emptying Dirt Cup
2-15 Attach wand and tools Attach tool or wand to the hose (G) by pushing it firmly into hose. Attach second wand or tool to the wand in the same manner. Twist wand or tool slightly to tighten or loosen the connection. 3. -
Page 9: Cleaning Filters
Filter assembly How to clean filter assembly Remove dirt cup and dirt cup lid as described in “How to empty dirt cup”. Pivot pre-filter assembly toward center of cup. Bend filter to open pleats. Tap edges of filter until dust particles stop falling from filter. -
Page 10: Replacing Headlight
Headlight replacement What to buy This cleaner uses a 12 volt, wedge base type 912 bulb, HOOVER part No. 27313101. 3-15 Remove lens - Disconnect clean- er from electrical outlet. -
Page 11: Replacing Belt
Turn agitator making sure belt is not pinched between agitator and agitator shield. Belt replacement The belt on your Hoover cleaner causes the agitator to rotate and is important for the effective operation of the cleaner. The belt is located under the bottom... -
Page 12: Authorized Service
• calling 1-800-944-9200 for an automated referral of authorized service outlet locations (U.S. only). Do not send your cleaner to The Hoover Company in North Canton for service, this will only result in delay. If further assistance is needed, contact... -
Page 13: If You Have A Problem
4. If you have a problem If a minor problem occurs, it usually can be solved quite easily when the cause is found by using the check list below. Problem: Cleaner won’t run Possible cause Possible solution • Not firmly plugged in •... -
Page 14: Warranty
The Hoover Company on-line at www.hoover.com This warranty does not cover pick up, delivery, or house calls; however, if you mail your appliance to a Hoover Factory Service Center for warranty service, transportation will be paid one way. While this warranty gives you specific... - Page 15 HOOVER et sont des marques déposées HOOVER y son marcas registradas ® ® HOOVER and are registered trademarks ® R1 9-02 U5344-/47-/48-900, U5347-960 Printed in Mexico 56511-B49...
