HARDWARE & MISC:
1 Printed-circuit board
1 9-volt battery hold-down bracket
1 9-volt battery connector
2 RCA-style jack (antenna connector)
1 subminiature earphone jack
1 PC mount pushbutton switch
REQUIRED, NOT SUPPLIED:
9-volt battery (alkaline or "heavy duty" type required)
Earphone, or small speaker
Antenna (whip or wire style)
OPTIONAL:
Ramsey Case, knob and whip antenna set, Model CRR1 or,
Your own choice of enclosure and hardware.
For each part, our word "install" always means these steps:
1. Pick the correct part value to start with.
2. Insert it into the correct PC board location.
3. Orient it correctly, follow the PC board drawing and the written
directions for all parts- especially when there's a right way and a wrong
way to solder it in. (Diode bands, electrolytic capacitor polarity,
transistor shape, dotted or notched ends of IC's, and so forth.)
4. Solder all connections unless directed otherwise. Use enough heat
and solder for clean, shiny, completed connections. Don't be afraid of
any pen-style soldering iron having enough heat to damage a
component.
5. Trim or "nip" the excess component lead wire after soldering.
