COMPACT DISC STEREO
CASSETTE RECEIVER
•
BASIC TAPE MECHANISM
•
BASIC CD MECHANISM
SIMPLE MANUAL
SYSTEM
NSX-S707
NSX-S708
• Replace this Service Manual with "Revision Publishing" when it is issued.
• If requiring information about the CD mechanism, see Service Manual of
4ZG-1, S/M Code No. 09-983-249-3OT.
NSX-S707
NSX-S708
:
2ZM-3MK2 YPR4N
:
4ZG-1 Z4DSHNC
CD
CASSEIVER
CX-NS707
SX–ANS706
(TYPE : EZ,K)
CX-NS708
SX–ANS707
(TYPE : EZ)
.
S/M Code No
09–985–276–3FE
•
TYPE
REMOTE
SPEAKER
CONTROLLER
RC - 7AS06
:
EZ,K (707),
EZ (708)
Advertisement
Related Manuals for Aiwa NSX-S707
Summary of Contents for Aiwa NSX-S707
- Page 1 NSX-S707 NSX-S708 COMPACT DISC STEREO CASSETTE RECEIVER • BASIC TAPE MECHANISM 2ZM-3MK2 YPR4N • TYPE EZ,K (707), • BASIC CD MECHANISM 4ZG-1 Z4DSHNC EZ (708) SIMPLE MANUAL REMOTE SYSTEM SPEAKER CASSEIVER CONTROLLER CX-NS707 NSX-S707 SX–ANS706 (TYPE : EZ,K) RC - 7AS06...
- Page 2 ELECTRICAL MAIN PARTS LIST - 1 NOTE: The characters in the suffix column indicate the part usage. KSTE ....XX........B....EZSE ....XX........C....8EZE ....XX........D....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-NF5-210-010 GUIDE,LED A....88-NF6-203-010 GUIDE,LED JOG A....88-NF6-204-010 GUIDE,LED OPE A....88-NF6-204-110 GUIDE,LED OPE ....
- Page 3 ELECTRICAL MAIN PARTS LIST - 2 LED 419 87-070-281-080 LED,SLZ736A-25-S-T1 A....LED 425 87-070-281-080 LED,SLZ736A-25-S-T1 A....LED 421 87-070-281-080 LED,SLZ736A-25-S-T1 A....LED 423 87-070-281-080 LED,SLZ736A-25-S-T1 A....LED 427 87-070-281-080 LED,SLZ736A-25-S-T1 A....LED 429 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN A....LED 428 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN A....
- Page 4 ELECTRICAL MAIN PARTS LIST - 3 87-010-545-040 CAP,E 0.22-50 SME A....87-010-176-080 C-CAP,S 680P-50 SL ....87-010-177-080 C-CAP,S 820P-50 SL A....87-010-248-040 CAP,E 220-10 SME A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-196-080 CHIP CAPACITOR,0.1-25 A....87-010-401-040 CAP,E 1-50 SME A....87-017-931-080 ZENER,MTZJ5.6B A....
- Page 5 ELECTRICAL MAIN PARTS LIST - 4 87-A30-075-080 C-TR,2SA1235F ABCD....87-A30-075-080 C-TR,2SA1235F ABCD....87-A30-076-080 C-TR,2SC3052F ABCD....87-A30-076-080 C-TR,2SC3052F ABCD....87-A30-076-080 C-TR,2SC3052F ABCD....87-A30-196-080 TR,2SC4115SRS ABCD....89-213-702-010 TR,2SB1370 (1.8W) ABCD....89-213-702-010 TR,2SB1370 (1.8W) ABCD....87-026-609-080 TR,KTA1266GR ABCD....87-026-609-080 TR,KTA1266GR ABCD....87-A30-075-080 C-TR,2SA1235F ABCD....
- Page 6 ELECTRICAL MAIN PARTS LIST - 5 87-A30-162-010 FET,2SK2937 ABCD....87-026-232-080 TR,DTA144WK A....87-A30-073-080 C-TR,RT1N 141C ABCD....87-A30-074-080 C-TR,RT1P 141C .BCD....87-A30-107-070 C-TR,CMBT5401 ABCD....87-A30-221-040 C-TR,DTA114WK .BCD....87-A00-262-080 RES,M/F 0.15-2W J ABCD....87-A00-262-080 RES,M/F 0.15-2W J ABCD....87-A00-262-080 RES,M/F 0.15-2W J ABCD....
- Page 7 ELECTRICAL MAIN PARTS LIST - 6 87-010-193-080 CHIP CAPACITOR,0.033 ABCD....87-010-380-080 CAP, ELECT 47-16V ABCD....87-010-401-080 CAP, ELECT 1-50V .BCD....87-010-401-080 CAP, ELECT 1-50V .BCD....87-010-405-080 CAP, ELECT 10-50V ABCD....87-010-405-080 CAP, ELECT 10-50V ABCD....87-010-112-080 CAP, ELECT 100-16V ABCD....87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD....
- Page 8 ELECTRICAL MAIN PARTS LIST - 7 87-010-196-080 CHIP CAPACITOR,0.1-25 ..CD....87-010-197-080 CAP, CHIP 0.01 DM ..CD....87-010-314-080 C-CAP,S 22P-50V ..CD....87-010-316-080 C-CAP,S 33P-50 CH ..CD....87-010-405-080 CAP, ELECT 10-50V ..CD....87-010-405-080 CAP, ELECT 10-50V ..CD....87-012-140-080 CAP 470P ..CD....87-012-156-080 C-CAP,S 220P-50 CH ..CD....
- Page 9 ELECTRICAL MAIN PARTS LIST - 8 87-010-405-080 CAP, ELECT 10-50V ABCD....87-010-405-080 CAP, ELECT 10-50V ABCD....87-010-405-080 CAP, ELECT 10-50V ABCD....87-010-183-080 C-CAP,S 2700P-50 B ABCD....87-010-194-080 CAP, CHIP 0.047 ABCD....87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD....87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD....87-010-213-080 C-CAP,S 0.015-50 B ABCD....
- Page 10 ELECTRICAL MAIN PARTS LIST - 1 (FRONT ASSY 8ZZ-4) NOTE: The characters in the suffix column indicate the part usage. EZSM ....XX........A....KSTM ....XX........B....EZ1M ....XX........C....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-075-040 CAP,E 10-16 5L ABC....87-010-178-080 CHIP CAP 1000P ABC....
- Page 11 ELECTRICAL MAIN PARTS LIST - 2 (FRONT ASSY 8ZZ-4) LED 407 87-070-197-080 LED,SLP7118C-51-S-T1 ABC....LED 404 87-070-197-080 LED,SLP7118C-51-S-T1 ABC....LED 408 87-070-197-080 LED,SLP7118C-51-S-T1 ABC....LED 410 87-070-197-080 LED,SLP7118C-51-S-T1 ABC....LED 413 87-070-201-080 LED,SLP9118C-51-S-T1 ABC....LED 411 87-070-201-080 LED,SLP9118C-51-S-T1 ABC....LED 414 87-070-201-080 LED,SLP9118C-51-S-T1 ABC....
- Page 12 ELECTRICAL MAIN PARTS LIST - 3 (FRONT ASSY 8ZZ-4) 87-A90-095-080 SW,TACT EVQ11G04M ABC....87-A90-095-080 SW,TACT EVQ11G04M ABC....87-A90-095-080 SW,TACT EVQ11G04M ABC....87-A90-095-080 SW,TACT EVQ11G04M A.C....87-A90-095-080 SW,TACT EVQ11G04M ABC....87-A90-095-080 SW,TACT EVQ11G04M ABC....87-A90-095-080 SW,TACT EVQ11G04M ABC....87-A90-095-080 SW,TACT EVQ11G04M ABC....
- Page 13 MECHANICAL PARTS LIST - 1 NOTE: The characters in the suffix column indicate the part usage. KSTE ....XX........B....EZSE ....XX........C....8EZE ....XX........D....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 86-NF6-007-010 WINDOW,TOP ABCD....86-NF6-101-010 WINDOW TOP UL ....87-NB8-005-010 PANEL,LEFT ABCD....87-NB8-051-010 PANEL,LEFT U ....
- Page 14 MECHANICAL PARTS LIST - 2 87-035-367-010 FUSE, 3.15A 250V .B....87-035-368-010 FUSE, 4A 250V A.CD....87-035-368-010 FUSE, 4A 250V A.CD....87-035-491-010 FUSE,6A 125V D UL ....88-NF6-621-010 PT,8NF-6 U ....88-NF6-622-010 PT,8NF-6 HR ....88-NF6-623-010 PT,8NF-6 EZ ..CD....88-NF6-624-010 PT,8NF-6 LH A....
- Page 15 MECHANICAL PARTS LIST - 1 (FRONT ASSY 8ZZ-4) NOTE: The characters in the suffix column indicate the part usage. EZSM ....XX........A....KSTM ....XX........B....EZ1M ....XX........C....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 88-NF6-003-010 BOX,CASS 1 ABC....88-NF6-004-010 BOX,CASS 2 ABC....88-NF6-007-010 PANEL,CD ABC....
- Page 16 TAPE MECHANISM PART LIST - 1 REF. NO. PART NO. KANRI DESCRI P TI O N REF. NO. PART NO. KANRI DESCRI P TI O N 1 82-ZM3-301-519 CHAS ASSY,M2 36 82-ZM1-236-019 CAPSTAN N 2-41.5 2 82-ZM1-258-110 SPR-T,PINCH L 37 82-ZM1-239-019 CAPSTAN N 2.2-41.7 3 82-ZM1-341-110 LVR ASSY,PINCH L2...
- Page 17 ACCESSORIES / PACKAGE LIST - 1 NOTE: The characters in the suffix column indicate the part usage. KSTE ....XX........B....EZSE ....XX........C....8EZE ....XX........D....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 88-NF6-866-010 CTN,PRINTED 706HRSTNM ....88-NF6-867-010 CTN,PRINTED VJSTNM ....88-NF6-868-010 CTN,PRINTED 708HRJSTNM ....
- Page 18 SCHEMATIC DIAGRAM _ 1 (MAIN : EZ)
- Page 19 SCHEMATIC DIAGRAM _ 2 (MAIN : K)
- Page 20 SCHEMATIC DIAGRAM _ 3 (TUNER : EZ)
- Page 21 SCHEMATIC DIAGRAM _ 4 (TUNER : K)
- Page 22 SCHEMATIC DIAGRAM _ 5 (FRONT : EZ)
- Page 23 SCHEMATIC DIAGRAM _ 6 (FRONT : K)
- Page 24 SCHEMATIC DIAGRAM _ 7 (PT : EZ)
- Page 25 SCHEMATIC DIAGRAM _ 8 (PT : K)
- Page 26 9301978,750038 Tokyo Japan Printed in Singapore...
