WHIRLPOOL CONSUMER SERVICES
WHIRLPOOL AUSTRALASIA
CONSUMER SERVICES
Model
6AKM157/IX/2
6AKM157/IX/3
6AKM157/WH/2
6AKM157/WH/3
Copyright © 2001 Whirlpool (Australia) Pty. Limited
All rights strictly reserved. Reproduction or issue to third parties in any form whatsoever
is not permitted without written authority of Whirlpool (Australia) Pty. Limited
Whirlpool is a registered trademark of Whirlpool U.S.A.
This documentation is intended only for qualified technicians who possess the required qualifications
and are aware of the regulatory requirements applicable to servicing electrical appliances.
Whirlpool (Australia) Pty Limited
A. B. N.28 003 578 023
SERVICE MANUAL
GAS COOKTOP
Version
8571 157 53040
8571 157 53060
8571 157 53050
8571 157 53070
Models 6AKM157/IX/2
6AKM157/IX/3
6AKM157/WH/2
6AKM157/WH/3
Part No. SM5022
July 2001
Advertisement
Table of Contents
Related Manuals for Whirlpool 6AKM157/IX/2
Summary of Contents for Whirlpool 6AKM157/IX/2
-
Page 1: Consumer Services
Copyright © 2001 Whirlpool (Australia) Pty. Limited All rights strictly reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority of Whirlpool (Australia) Pty. Limited Whirlpool is a registered trademark of Whirlpool U.S.A. - Page 2 WHIRLPOOL CONSUMER SERVICES Models 6AKM157/IX/2 6AKM157/IX/3 6AKM157/WH/2 6AKM157/WH/3 Page 2 of 9 BLANK PAGE...
- Page 3 WHIRLPOOL CONSUMER SERVICES Models 6AKM157/IX/2 6AKM157/IX/3 6AKM157/WH/2 6AKM157/WH/3 Page 3 of 9 CONTENTS Page TECHNICAL DATA GAS LEAKS GAS JET REPLACEMENT FLAME ADJUSTMENT MAINTENANCE HOB REMOVAL REPLACEMENT OF GAS VALVES GREASING THE GAS VALVES IGNITION COMPONENT REPLACEMENT BURNER BASE REMOVAL...
-
Page 4: Technical Data
WHIRLPOOL CONSUMER SERVICES Models 6AKM157/IX/2 6AKM157/IX/3 6AKM157/WH/2 6AKM157/WH/3 Page 4 of 9 TECHNICAL DATA Burner Operating Rating Gas Jet (Nozzle) Output Power Type Pressure Diameter 1/100mm MJ/h Small Propane 2.75 0.92 N.G. 1.00 1.00 Medium Propane 2.75 1.58 N.G. 1.00 1.67... -
Page 5: Maintenance
WHIRLPOOL CONSUMER SERVICES Models 6AKM157/IX/2 6AKM157/IX/3 6AKM157/WH/2 6AKM157/WH/3 Page 5 of 9 FLAME ADJUSTMENT GAS VALVES The gas valves fitted to this cooktop are suitable for both propane gas and natural gas. Adjust the minimum flame for use with natural gas as follows: Operate the burner and set the control knob to minimum flame. - Page 6 WHIRLPOOL CONSUMER SERVICES Models 6AKM157/IX/2 6AKM157/IX/3 6AKM157/WH/2 6AKM157/WH/3 Page 6 of 9 REPLACEMENT OF GAS VALVES To replace gas valves, remove the hob, remove the two screws securing the manifold to the base and release the compression joints on the output side of the gas valves.
-
Page 7: Burner Base Removal
WHIRLPOOL CONSUMER SERVICES Models 6AKM157/IX/2 6AKM157/IX/3 6AKM157/WH/2 6AKM157/WH/3 Page 7 of 9 IGNITION COMPONENT REPLACEMENT During disassembly, take note of the order of assembly of the components. Remove the hob. (See Figures 1 and 4) The ignition pack can be replaced by freeing the two tabs securing it to the base. All electrical connections are push on. - Page 8 WHIRLPOOL CONSUMER SERVICES Models 6AKM157/IX/2 6AKM157/IX/3 6AKM157/WH/2 6AKM157/WH/3 Page 8 of 9 EXPLODED VIEW - COOKTOP...
-
Page 9: Spare Parts List
WHIRLPOOL CONSUMER SERVICES Models 6AKM157/IX/2 6AKM157/IX/3 6AKM157/WH/2 6AKM157/WH/3 Page 9 of 9 SPARE PARTS LIST Item Part No Description 6AKM157/IX/2 AKM157/IX/3 6AKM157/WH/2 AKM157/WH/3 031 0 4812 442 69097 4812 442 69097 Hob, stainless steel 031 0 4812 442 69098 4812 442 69098 Hob, white...
