Sharp R-308KK Service Manual page 37

NO. PARTS CODE
[1] OVEN PARTS
1-1 QSW-MA147WRZZ
1-2 FFS-BA037WRKZ
1-3 FACCDA109WREZ
1-3 FACCDA098WREZ
1-3 FACCDA099WREZ
1-3 FACCDA110WREZ
1-4 FH-DZA109WRKZ
!
1-4 FH-DZA075WRK0
!
1-4 FH-DZA112WRKZ
!
1-5 RC-QZA295WRZZ
!
1-5 RC-QZA218WRE0
!
1-6 RMOTEA433WRZZ
1-6 RMOTEA346WRE0
1-6 RMOTEA356WRE0
1-7 RTHM-A119WRE0
1-8 RLMPTA087WRZZ
1-8 RLMPTA082WRZZ
1-8 RLMPTA085WRZZ
1-9 RMOTDA264WRZZ
1-9 RMOTDA252WRZZ
1-9 RMOTDA186WRE0
1-10 RTRN-A729WRZZ
!
1-10 RTRN-A730WRZZ
!
!
1-11 RV-MZA288WRE0
*
!
1-11 RV-MZA321WRZZ
*
!
1-11 RV-MZA340WRZZ
*
1-12 QFS-TA014WRE0
1-13 FPWBFA385WRKZ
2-1 GCABUA889WRPZ
2-1 GCABUA883WRPZ
2-2 GDAI-A360WRWZ
2-3 GLEGPA074WRE0
4-1 PHOK-A131WRFZ
*
4-2 LBNDKA163WRPZ
4-3 NFANJA053WRFZ
4-4 *************
*
4-5 MLEVPA233WRF0
4-6 PCUSGA620WRPZ
4-7 PCOVPA394WREZ
4-8 PDUC-A833WRPZ
4-9 PDUC-A853WRWZ
4-10 PPACGA176WREZ
4-11 PCUSGA399WRE0
4-12 PCUSUA278WRP0
4-13 PCUSUA235WRP0
4-14 PCUSGA614WRPZ
4-15 PCUSGA615WRPZ
4-16 MROD-A019WREZ
4-17 PCUSGA616WRPZ
6-1 FROLPA101WRKZ
6-2 NTNT-A117WREZ
6-4 TCAUAA268WRRZ
6-5 TCAUAA292WRRZ
7-1 XHPSD40P08K00
7-2 LX-CZA070WRE0
7-3 LX-CZA073WRE0
7-4 LX-CZ0052WRE0
7-5 LX-EZA042WRE0
7-6 XHPSD30P06000
7-7 XHPSD40P08000
7-8 XHTSD40P08RV0
7-9 XHTSD40P08000
7-10 XOTSD40P08000
7-11 XOTSE40P08000
7-11 XOTSF40P08000
PRICE NEW PART
RANK MARK RANK
ELECTRIC PARTS
Secondary interlock switch / door sensing switch
AG
Monitor fuse 20A and monitor switch assembly (D3V-1G-2C25)
AN
Power supply cord
AU
-- Power supply cord (Interchangeable) for production use
Power supply cord (Interchangeable) for production use
--
Power supply cord (Interchangeable) for production use
--
High voltage rectifier assmebly
AR
High voltage rectifier assembly (Interchangeable)
AR
High voltage rectifier assembly (Interchangeable)
AR
High voltage capacitor
AV
High voltage capacitor (Interchangeable)
AW
Fan motor
AX
Fan motor (Interchangeable)
AV
Fan motor (Interchangeable) for production use
--
Thermal cut-out 145C [oven]
AK
Oven lamp
AL
Oven lamp (Interchangeable)
AL
Oven lamp (Interchangeable)
AH
Turntable motor
AT
Turntable motor (Interchangeable)
AN
Turntable motor (Interchangeable)
AW
Power transformer
BG
Power transformer (Interchangeable) for production
--
Magnetron
BK
Magnetron (Interchangeable)
BH
Magnetron (Interchangeable) for production use
--
Temperature fuse 150deg.C [Magnetron]
AG
Noise filter assembly
AV
CABINET PARTS
Outer case cabinet [R-308KK]
BF
Outer case cabinet [R-308KW]
BF
Bottom plate
AS
Foot
AC
OVEN PARTS
Latch hook
AL
Capacitor holder
AK
Fan blade
AG
Oven cavity [Not a replacement part]
--
Switch lever
AG
Cushion
AF
Waveguide cover
AK
Air duct
AM
Fan duct
AP
TTM packing
AC
Cushion
AF
Cushion
AB
Cushion
AE
Cushion
AE
Cushion
AE
Chassis support
AN
Cushion
AK
MISCELLANEOUS
Turntable support
AR
Turntable
AS
DHHS caution label
AF
Monitor caution
AE
SCREWS, NUTS AND WASHERS
Screw : 4mm x 8mm
AA
Special screw
AC
Special screw
AC
Special screw
AA
Special screw
AB
Screw : 3mm x 6mm
AA
Screw : 4mm x 8mm
AA
Screw : 4mm x 8mm
AA
Screw : 4mm x 8mm
AA
Screw : 4mm x 8mm
AA
Screw : 4mm x 8mm [R-308KW]
AA
Screw : 4mm x 8mm [R-308KK]
AA
3
DESCRIPTION
R308KW
