- Page 1 RCI-6900F HP TABLE OF RCI-6900F TB CONTENTS PAGE CHAPTER 1 SPECIFICATIONS General ..........
-
Page 2: General
7 7/8”(W) x 10 3/4” (D) x 2 3/8”(H) : (RCI-6900F TB) 7 7/8” (W) x 9 1/4” (D) x 3 7/8” (H) Weight 5 lb. (RCI-6900F HP), 7lb 6 oz (RCI-6900F TB) 1.1 TRANSMITTER AM/FM/CW ; SSB RF Power Output (RCI-6900FHP) 10W ; 25W PEP AM/FM/CW ;... -
Page 3: Control & Connections
Figure 2-1 Front Panel 2.0 INTRODUCTION This section explains the basic operating procedures for the RANGER RCI-6900F HP / RCI-6900F TB mobile transceiver. 2.1 CONTROL AND CONNECTIONS 2.1.1 FRONT PANEL Refer to the above Figure 2-1 for the location of the following controls. - Page 4 7. FR. POOL SELECTOR This switch is used to select the frequency range of operation (1 - 6). 8. MODE SWITCH This control allows you to select one of the following operating modes: CW/FM/AM/USB/LSB. 9. FINE/COARSE CONTROL Allows variation of the receiver operating frequency above and below the assigned frequency. Although this control is intended primarily to tune in SSB signal, it may be used to optimize AM/FM signals as described in the operating procedure paragraphs.
-
Page 5: Rear Panel
The channel display indicates the current selected channel. 2.1.2 REAR PANEL Figure 2-2 represents the location of the following connections: Figure 2-2 Rear Panel 1. ANTENNA This jack accepts 50 ohms coaxial cable with a PL-259 type plug. 2. POWER This connector accepts 13.8V DC power cable with built-in fuse. - Page 6 28.305 28.755 29.205 28.375 28.825 29.275 28.315 28.765 29.215 28.385 28.835 29.285 28.335 28.785 29.235 28.405 28.855 29.305 28.345 28.795 29.245 28.415 28.865 29.315 28.355 28.805 29.255 28.425 28.875 29.325 28.365 28.815 29.265 28.435 28.885 29.335 28.385 28.835 29.285 28.455 28.905 29.355 28.395...
-
Page 7: Microphone
2. Turn VOL. knob clockwise to apply power to the radio. 3. Set the VOL. to a comfortable listening level. 4. Set the MODE switch to the desired mode. 5. Listen to the background noise from the speaker. Turn the SQ knob slowly clockwise until the noise just disappears. -
Page 8: Operation
RCI-6900F TB DESCRIPTION 3.0 INTRODUCTION This section explains the technical theory of operation for the RCI-6900F HP / RCI-6900F TB mobile transceiver. 3.1 PLL CIRCUIT The Phase Lock Loop (PLL) circuit is responsible for developing the receiver’s first local oscillator signal and the transmitter’s exciter signal. -
Page 9: Pll Circuit
Q25, Q27, Q28, Q29 and Q61. The PLL circuit is programmed by the rotary channel switch GPS-0501. The GPS-0501 communicates the correct binary data information to the programmable divider inside of IC3. IC3 then controls the VCO (Voltage Controlled Oscillator), to oscillate on the correct frequency. - Page 10 - 10 -...
- Page 11 - 11 -...
- Page 12 RCI-6900F HP / RCI-6900F TB FREQUENCY COUNTER CIRCUIT DIAGRAM - 12 -...
- Page 13 RCI-6900F HP / RCI-6900F TB ECHO BOARD (EB-99) CIRCUIT DIAGRAM - 13 -...
-
Page 14: Alignment Procedures
RCI-6900F HP CHAPTER 4 RCI-6900F TB ALIGNMENT 4.0 REQUIRED TEST EQUIPMENT & DC Power Supply (13.8VDC, 20A) Frequency Counter (100 MHz) " RF Wattmeter (25~60 MHz, 100W) RF Signal Generator (100 MHz) Multimeter (Digital) Automatic Distortion Meter Automatic Modulation Meter... -
Page 15: Receiver Alignment
ITEM U.U.T. SETTING ADJUST MEASUREMENT POINT TX Power Set radio to Fr. Pool 2, CH 19 AM TX mode. L18,L37,L35, Maximum Output. Modulation Off. Set radio to Fr. Pool 2, CH 19 USB TX mode. AF signal 30mV, 1 KHz to microphone. Connect Oscilloscope to TP12. - Page 16 ITEM U.U.T. SETTING ADJUST MEASUREMENT POINT AM Sensitivity Set radio to Fr. Pool 2, CH 19 AM RX mode. L2,3,5,6,7,8, Audio output > 2V Set RF Gain Fully Clockwise. 9,10 S/N > 10 dB. Set SQ Fully Counter Clockwise. Set VOL Control at 2 o’clock. Set NB/ANL/OFF switch to OFF position.
- Page 17 Figure 4-2 Receiver test setup - 17 -...
-
Page 18: Chapter 5
Figure 4-3 Main PCB Adjustment Location RCI-6900F HP CHAPTER 5 RCI-6900F TB MAINTENANCE - 18 -... -
Page 19: Periodic Inspection
A fuse rated for more than the transceiver requirement should not be used, since it may permanently damage the equipment. Damage due to over fusing is not covered by the warranty. CHAPTER 6 RCI-6900F HP DIAGRAMS & RCI-6900F TB PARTS LIST... - Page 20 Information on most electrical and mechanical parts is included in the parts list. The reference designators are in alphanumeric order. 6.1 ORDERING REPLACEMENT PARTS Parts orders should be referred to the parts department at: Ranger Communications, Inc. 3377 Carmel Mountain Road San Diego, CA 92121 Tel: 858-259-0287...
- Page 21 PART LIST: RCI-6900F HP / RCI-6900F TB ROTARY SW P.C.B ITEM REFERENCE NUMBER RANGER PART DESCRIPTION NUMBER EPT900030Z ROTARY SW P.C.B R315 RCP168214Z 820 OHM 1/16W R312,R313,R314, RCP161524Z 1.5K OHM 1/16W R316-R324 J303,J304,J305,J306 WX01070705 JUMPER WIRE J308 WX01070708 JUMPER WIRE...
- Page 22 PART LIST: RCI-6900F HP ANT P.C.B ITEM REFERENCE NUMBER RANGER PART DESCRIPTION NUMBER EPT360042Z ANT P.C.B RCY010004Z 0 OHM 0.1W RCY014714Z 470 OHM 0.1W R3,R4 RCY011014Z 100 OHM 0.1W RCY013314Z 330 OHM 0.1W R5,R11 RCY011024Z 1K OHM 0.1W RCY012224Z 2.2K OHM 0.1W RCY014724Z 4.7K OHM 0.1W...
- Page 23 PART LIST: RCI-6900F TB POWER P.C.B ITEM REFERENCE NUMBER RANGER PART DESCRIPTION NUMBER EPA010010B POWER PCB R18,R19 RCM141004A 10 Ω ¼ W RCM141014A 100 Ω ¼ W RCM144714A 470 Ω 1/4W RCM141024A 1K Ω 1/4W RCP121034Z 10K Ω 1/2W RFP102714Z 270 Ω...
- Page 24 NUMBER C18,C19 CC0501515A 150PF 50WV CC0502215A 220PF 50WV C9,C14 CC0505615G 560PF 50WV C10,C23,C24,C25, CC0501047L 0.1uF 50WV C26,C27,C28,C37, C38,C39,C40,C41, C42,C43,C44,C45 C7,C8 CC5001037L .01uF 50WV CC5001204A 12PF 500WV CC5003904A 39PF 500WV CD5006604Z 68PF 300WV CD3008204Z 82PF 300WV C16,C22,C33 CD3001514Z 150PF 300WV CE052257Z 2.2uF 50WV CE0254777Z 470PF 25WV...
- Page 25 PART LIST: RCI-6900F TB SWR P.C.B ITEM REFERENCE NUMBER RANGER PART DESCRIPTION NUMBER EPA010020B SWR P.C.B R13,R14 RCY010004Z 0 Ω 0.1W RCY011014Z 100 Ω 0.1W R1,R3,R4 RCY014714Z 470 Ω 0.1W R5,R11 RCY011024Z 1K Ω 0.1W RCY014724Z 4.7K Ω 0.1W R7,R8,R10 RCY011034Z 10K Ω...
- Page 26 PART LIST: RCI-6900F HP / RCI-6900F TB BAND P.C.B ITEM REFERENCE NUMBER RANGER PART DESCRIPTION REMARK NUMBER EPT690070Z BAND P.C.B RCP164704Z 47 OHM 1/16W J1,J5,J6,J7 EX07N48223 PCB CONN/S 2PIN EX07W48826 PCB CONN/S 5PIN J4,J12 EX07W48827 PCB CONN/S 6PIN RCI-6900FTB EX07N48224...
- Page 27 PART LIST: RCI-6900F HP / RCI-6900F TB MIC P.C.B ITEM REFERENCE NUMBER RANGER PART DESCRIPTION NUMBER EPT690050Z MIC P.C.B C502, C503,C504 CC0501027L 0.001uF 50WV C505,C506,C501 CC0501037L 0.01uF 50WV L501 ECCHK16001 CHOKE COIL L502 ECBAD18526 BEAD COIL EX06N41020 MIC JACK MIC-50F...
- Page 28 - 28 -...
- Page 29 PART LIST: RCI-6900F HP / RCI-6900F TB COUNTER P.C.B ITEM REFERENCE NUMBER RANGER PART DESCRIPTION NUMBER EPT900040Z COUNTER P.C.B RCY010004Z 0 OHM 0.1W R19-R39 RCY011014Z 100 OHM 0.1W RCY013314Z 330 OHM 0.1W RCY014714Z 470 OHM 0.1W R4,R5 RCY012224Z 2.2K OHM 0.1W RCY014724Z 4.7K OHM 0.1W...
- Page 30 PART LIST: RCI-6900F HP/ RCI-6900F TB LED DISPLAY P.C.B ITEM REFERENCE NUMBER RANGER PART DESCRIPTION NUMBER EPT900022Z LED DISPLAY P.C.B LED DISPLAY PCB EX03N40003 LED DISPLAY 1,2,3,4,5,6 EX03N40476 LED DISPLAY TX/RX EX01N40004 LED RED/GREEN ON,NB/ANL,R.B,S/RF, EWPS33033X PUSH SW SWR,+10K LED DISPLAY PCB x 2pc...
- Page 31 - 31 -...
- Page 32 PART LIST: RCI-6900F HP / RCI-6900F TB ECHO P.C.B (EB-99) ITEM REFERENCE NUMBER RANGER PART DESCRIPTION NUMBER EPT0SSB50F ECHO P.C.B R3,R16 RCY011014Z 10 OHM 0.1W RCY014714Z 470 OHM 0.1W RCY011024Z 1K OHM 0.1W RCY012224Z 2.2K OHM 0.1W R17,R29 RCY014724Z 4.7K OHM 0.1W...
- Page 33 RCI-6900 HP / RCI-6900 TB MAIN PCB REMARK: COMPONENT SIDE (BLUE) - 33 -...
- Page 34 RCI-6900F HP / RCI-6900F TB MAIN PCB. REMARK: SMD COMPONENT SIDE (BLUE) - 34 -...
- Page 35 RCI-6900 HP / RCI-6900 TB MAIN PCB REMARK: COPPER SIDE (WHITE) PART LIST RCI-6900F HP MAIN PCB - 35 -...
- Page 36 EX07N48222 P/C/S 5P J10,13,15 EX07N48331 P/C/S 6P REFERENCE RANGER DESCRIPTION EX07N48543 P/C/S 9P NUMBER PART NO. EX07N48209 P/C/S 10P EPT990010Z MAIN P.C.B EX07N48244 P/C/S 3P 150 Ω 1/2W R274,275 RCP121514Z EX07N48884 P/C/S 6P 10K Ω 1/2W R270 RCP121034Z J27,30 EX07N48151...
- Page 37 C/F/R 22K Ω R34,93,110,133,134, RCY012234Z ,178,181,190,191,192 138,139,141,187,222 ,204,259,265,322,121 C/F/R 27K Ω R122 RCY012734Z ,349 C/F/R 33K Ω R2,264 RCY013334Z C5,23,26,41,56,74,77 CK1473AB7R 0.047UF C/F/R 39K Ω RCY013934Z ,78,80,81,94,101,106 50WV C/F/R 47K Ω R7,62,63,99,143,155- RCY014734Z ,109,119,125,157,162 157,160-165,166-173, ,170,199,258,262,272 149,198,200,229,234, ,274,277,283,284,296 343,345,353,355,236 CK2474AB7R 0.47UF 25WV C/F/R 68K Ω...
- Page 38 COVER B RCI-6900F HP MISC. PARTS MT2950070X SHIELD COVER C REFERENCE RANGER DESCRIPTION NUMBER PART NO. ES300835SQ SPEAKER EX03N40005 SIGNAL METER PT9000060I FRONT PANEL PT9000020E CH KNOB PT9000040E INNER KNOB PT9000050E OUTER KNOB PT3600080A SIGNAL METER HOLDER PT9000070E BAND KNOB...
- Page 39 PART LIST EX07N41330 P/C/S 2P J1,11,20,21,19,32,35 EX07N48223 P/C/S 2P RCI-6900F TB MAIN PCB J7,29,31,3 EX07N48350 P/C/S 3P J2,9 EX07N48490 P/C/S 4P REFERENCE RANGER DESCRIPTION EX07N48222 P/C/S 5P J10,13,15 EX07N48331 P/C/S 6P NUMBER PART NO. EX07N48543 P/C/S 9P EPT990010Z MAIN P.C.B EX07N48209...
- Page 40 ,188,194,217,223,228 ,201,207,226,232,234 ,239-243,248,251,252 ,235,238,240,250,251 ,296,301,323,324,346 ,254,255,268,281,292 ,348,350,362 ,297,298,303,324,325 C/F/R 12K Ω R191,137 RCY011234Z ,340,341,342,346,350 C/F/R 15K Ω R193 RCY011534Z C7,31,36,47,55,58,93 CK1102AB7L 0.001UF C/F/R 22K Ω R34,93,110,133,134, RCY012234Z ,104,133,135,145,150 50WV 138,139,141,187,222 ,178,181,190,191,192 C/F/R 27K Ω R122 RCY012734Z ,204,259,265,322,349 C/F/R 33K Ω R2,264 RCY013334Z ,121...
- Page 41 JS052010MN SET SCREW M2x0.4Px10 Q47,Q49 JN242012ZS NUT M2x1.2t MT2950050X SHIELD RCI-6900F TB MISC. PARTS COVER A MT2950060X SHIELD COVER B REFERENCE RANGER DESCRIPTION MT2950070X SHIELD NUMBER PART NO. COVER C WA9812300C DC CORD EX03N40005 SIGNAL METER EX04N40654 MIC BLACK PT9000060I...
