REFRIGERATOR
SERVICE MANUAL
CAUTION
PLEASE READ CAREFULLY THE SAFETY PRECAUTIONS OF THIS BOOK
BEFORE CHECKING OR OPERATING THE REFRIGERATOR.
MODEL: GR-B197WVS
http://biz.lgservice.com
Ref. No.
GR-B197GVCA
COLOR: SUPER WHITE
