Page 1: Rotary Mower
Manual Rotary Mower HRS216PDA • HRS216SDA HRR216PDA • HRR216SDA • HRR216S3DA HRT216SDA • HRT216S3DA ¿Necesita un manual en Español? Vea a la página 58. © 1997, 1999 American Honda Motor Co., Inc.—All Rights Reserved... - Page 2 Keep this owner’s manual handy, so you can refer to it any time, and make sure the manual stays with the lawn mower if you sell it. This owner’s manual is considered a permanent part of the lawn mower and should remain with the mower if resold.
- Page 3 INTRODUCTION Congratulations on your selection of a Honda lawn mower. We are certain you will be pleased with your purchase of one of the finest lawn mowers on the market. We want to help you get the best results from your new mower and to operate it safely.
-
Page 4: A Few Words About Safety
Of course, it is not practical or possible to warn you about all the hazards associated with operating or maintaining a lawn mower. You must use your own good judgment. You will find important safety information in a variety of forms, including: Safety Labels —... -
Page 5: Table Of Contents
MOWER SAFETY ..........4 A FEW WORDS ABOUT SAFETY IMPORTANT SAFETY INFORMATION IMPORTANT MESSAGE TO PARENTS... -
Page 6: Mower Safety
MOWER SAFETY IMPORTANT SAFETY INFORMATION Most accidents with walk-behind mowers can be prevented if you follow all instructions in this manual and on the mower. The most common hazards, according to accident statistics, are discussed below, along with the best way to protect yourself and others. Avoid Rotating Blades Rotating blades can cause serious cuts and even amputate fingers, hands, toes, or feet. -
Page 7: Important Message To Parents
YOUR CHILDREN’S SAFETY IS VERY IMPORTANT to Honda. That’s why we urge you to read this message before letting your youngster operate this lawn mower. Lawn mowers are tools, not toys. As with any equipment, bad judgments can result in serious injuries. -
Page 8: Safety Label Locations
MOWER SAFETY SAFETY LABEL LOCATIONS The labels shown here contain important safety information. Please read them carefully. These labels are considered permanent parts of your mower. So if a label comes off or becomes hard to read, contact an authorized Honda dealer for a replacement. (HRT/HRT ONLY) WARNING AVOID SERIOUS INJURY OR DEATH. -
Page 9: Controls
COMPONENT IDENTIFICATION DRIVE CLUTCH LEVER (SD & S3D) RECOIL STARTER GRIP REAR CUTTING HEIGHT ADJUSTMENT LEVER OIL FILLER CAP SIDE DISCHARGE DOOR (HRS, HRT) (HRS216SDA shown) Model Identification To easily identify your model, refer to the chart on page 46. CONTROLS HANDLEBAR FLYWHEEL BRAKE LEVER... - Page 10 CONTROLS FUEL TANK CAP SPARK PLUG CAP CARBURETOR (HRT216S3DA shown) Record the frame and engine serial numbers in the space below. You will need these serial numbers when ordering parts and when making technical or warranty inquiries (see page 58). Frame serial number: MZ__ __ –...
-
Page 11: Description Of Controls
DESCRIPTION OF CONTROLS Fuel Valve The fuel valve controls fuel flow from the fuel tank to the carburetor. The fuel valve must be ON to start and operate the mower. The fuel valve should be kept OFF when the mower is not in use. Throttle Lever CHOKE –... - Page 12 CONTROLS Drive Clutch Lever (SD, S3D) The drive clutch lever engages and disengages the transmission that drives the rear wheels. The drive clutch lever should only be engaged after the engine has been started. Shift Lever (S3D) The shift lever is used to select the ground speed.
-
Page 13: Before Operation
BEFORE OPERATION ARE YOU READY TO MOW? Be sure to wear protective clothing. Long pants and eye protection can lower your risk of injury from thrown objects. Wear footwear that protects your feet and won’t let you slip if you mow on slopes or uneven ground. -
Page 14: Check Your Mower
A worn or damaged blade can break, causing blade pieces to be thrown from the mower. When a blade needs sharpening or replacement take the lawn mower to an authorized Honda servicing dealer. Or, if you have a torque wrench, you can remove and install the blade(s) yourself (page 38). - Page 15 Engine Oil Level Check the engine oil level with the engine stopped and the mower on a level surface. 1. Remove the oil filler cap, and wipe the dipstick clean. 2. Insert and remove the dipstick without screwing it into the filler neck.
- Page 16 BEFORE OPERATION Fuel Fuel tank capacity: 0.29 US gal (1.1 l) If the engine has been running, allow it to cool. Refuel in a well-ventilated area before starting the engine. See page 37 for fuel recommendations and page 59 for information on oxygenated fuels. Remove the fuel tank cap and check the fuel level.
- Page 17 Refer to page 35 for air cleaner service. Grass Bag (HRT216) A lawn mower works like a vacuum cleaner; it blows air through the bag, which traps the grass clippings. Always empty the grass bag before it becomes filled to the limit of its capacity.
- Page 18 BEFORE OPERATION Mulching Plug (HRR, HRT) The mulching plug helps to curve the inside of the mower deck for more efficient mulching. Install and remove the mulching plug by raising the rear door as shown. The mulching plug only fits one way. Remove the mulching plug when using a grass bag.
-
Page 19: Mowing Precautions
MOWING PRECAUTIONS Before operating the mower for the first time, please review the MOWER SAFETY beginning on page 4 and the previous chapter, titled BEFORE OPERATION. Even if you have operated other mowers, take time to become familiar with how this mower works and practice in a safe area until you build up your skills. - Page 20 OPERATION 1. SD, S3D: Release the drive clutch lever (page 10). If the drive clutch lever is engaged, the mower will move forward when you operate the starter. 2. Pull back on the flywheel brake lever and hold it against the handlebar.
-
Page 21: Operating The Controls For Mowing
OPERATION OPERATING THE CONTROLS FOR MOWING Throttle Lever For best cut quality, always mow with the throttle lever in the FAST position. When the blades rotate at the preset fast speed, it creates a strong fan action that lifts and cuts grass more efficiently. Do not try to increase the preset engine speed, the blades could fracture and come apart. - Page 22 OPERATION Drive Clutch Lever (SD, S3D) Push the drive clutch lever forward DRIVE CLUTCH LEVER and hold it against the handlebar to propel the mower forward. Release the drive clutch lever to stop the mower’s forward movement. Always release the drive clutch lever before starting the engine.
-
Page 23: Stopping The Engine
OPERATION STOPPING THE ENGINE SLOW Move the throttle lever to the SLOW position. DRIVE CLUTCH LEVER (SD, S3D) Release the drive clutch lever (SD, S3D). Release the flywheel brake lever. When the mower is not in use, turn the fuel valve to OFF. FUEL VALVE... -
Page 24: Safe Mowing Practices
OPERATION SAFE MOWING PRACTICES For your safety, keep all four wheels on the ground, and be careful to avoid losing your footing and your control of the mower. Keep a firm grip on the handlebar, and walk, never run, with the mower. Be very careful when mowing uneven or rough ground. -
Page 25: Mowing Tips
A worn, cracked, or damaged blade can break, and pieces of the damaged blade can become dangerous projectiles. Thrown objects can cause serious injury. Inspect the blade(s) regularly, and do not operate the mower with a worn or damaged blade. The Distributor’s Limited Warranty (page 51) does not cover parts damaged by accident or collision. - Page 26 OPERATION When to Mow Most grasses should be mowed when they have grown to 1 inch above their recommended height. More frequent mowing is required for mulching than for bagging. For best mulching results, you may need to mow the lawn twice a week during the growing season. Cutting Height Consult a local nursery or lawn and garden center for cutting height recommendations and advice about specific types of grasses and...
- Page 27 OPERATION Wet Grass Wet grass is slippery and can make you lose your footing. Also, wet grass clippings will clog the mower deck and collect in clumps on the lawn. Always wait for wet grass to dry before mowing. Fallen Leaves When equipped with the grass bag (optional for HRS, HRR models), your mower can be used to pick up fallen leaves for disposal.
- Page 28 OPERATION Mowing Patterns Your Honda mower will work most efficiently if you use the following mowing patterns as much as possible. Mower deck and equipment design, and the direction in which the blade rotates, cause these mowing patterns to give the best results. Mulching Use a counterclockwise mowing pattern.
-
Page 29: Transporting
TRANSPORTING BEFORE LOADING If the engine has been running, allow it to cool for at least 15 minutes before loading the mower on the transport vehicle. A hot engine and exhaust system can burn you and can ignite some materials. Turn the fuel valve to OFF. -
Page 30: Maintenance
THE IMPORTANCE OF MAINTENANCE Good maintenance is essential for safe, economical, and trouble-free operation. It will also help reduce air pollution. Improper maintenance, or failure to correct a problem before operation, can cause a malfunction in which you can be seriously hurt or killed. -
Page 31: Maintenance Safety
MAINTENANCE SAFETY Some of the most important safety precautions follow. However, we cannot warn you of every conceivable hazard that can arise in performing maintenance. Only you can decide whether or not you should perform a given task. Failure to properly follow maintenance instructions and precautions can cause you to be seriously hurt or killed. -
Page 32: Emission Control System Information
MAINTENANCE EMISSION CONTROL SYSTEM INFORMATION Source of Emissions The combustion process produces carbon monoxide, oxides of nitrogen, and hydrocarbons. Control of hydrocarbons and oxides of nitrogen is very important because, under certain conditions, they react to form photochemical smog when subjected to sunlight. Carbon monoxide does not react in the same way, but it is toxic. - Page 33 MAINTENANCE Replacement Parts The emission control systems on your new Honda engine were designed, built, and certified to conform with EPA and California emission regulations. We recommend the use of genuine Honda parts whenever you have maintenance done. These original-design replacement parts are manufactured to the same standards as the original parts, so you can be confident of their performance.
-
Page 34: Maintenance Schedule
MAINTENANCE MAINTENANCE SCHEDULE REGULAR SERVICE PERIOD Perform at every indicated interval Blade condition and Check blade bolt tightness Grass Bag (HRT) Check Check Engine oil Change Check Air Cleaner Clean Replace Clean-adjust Spark plug Replace Spark arrester Clean-inspect (optional equipment) Idle speed Check-adjust Flywheel brake... -
Page 35: Engine Maintenance
ENGINE MAINTENANCE Engine Oil Change Drain the used oil while the engine is warm. Warm oil drains quickly and completely. 1. Turn the fuel valve to OFF to reduce the possibility of fuel leakage (see page 21). 2. Wipe the oil filler area clean, then remove the oil filler cap/dipstick. - Page 36 MAINTENANCE Engine Oil Level Check 1. Wipe the dipstick clean. 2. Insert and remove the dipstick without screwing it into the filler neck. Check the oil level shown on the dipstick. 3. If the oil level is low, add oil to reach the upper limit mark on the dipstick.
- Page 37 Air Cleaner Service A dirty air filter restricts air flow to the carburetor, reducing engine performance. If you operate the mower in very dusty areas, clean the air filter more often than specified in the MAINTENANCE SCHEDULE. NOTICE Operating the engine without an air filter, or with a damaged filter, will allow dirt to enter the engine, causing rapid engine wear.
- Page 38 MAINTENANCE Spark Plug Service Refer to page 47 for replacement spark plug numbers. NOTICE An incorrect spark plug can cause engine damage. For good performance, the spark plug must be properly gapped and free of deposits. 1. Disconnect the spark plug cap and remove dirt from the area.
- Page 39 Carburetor Modification for High Altitude Operation At high altitude, the standard carburetor air-fuel mixture will be too rich. Performance will decrease, and fuel consumption will increase. A very rich mixture will also foul the spark plug and cause hard starting. High altitude performance can be improved by specific modifications to the carburetor.
-
Page 40: Blade Removal And Installation
MAINTENANCE BLADE REMOVAL AND INSTALLATION If you remove the blade(s), use a torque wrench for installation. Wear heavy gloves to protect your hands. To avoid weakening the blade(s), or causing imbalance or poor cutting, the blade(s) should be sharpened by trained staff at an authorized Honda servicing dealer. -
Page 41: Grass Bag Cleaning And Replacement
If you don’t have a torque wrench, have an authorized Honda servicing dealer tighten the blade bolts before you use the mower. If the blade bolts are overtightened, they could break. If the blade bolts are not tightened enough, they could loosen or come out. In either case, it would be possible for the blade to fly off while you are operating the mower. -
Page 42: Troubleshooting
ENGINE PROBLEMS Engine Will Not Start 1. Check control positions. Fuel valve OFF. 2. Check fuel. 3. Remove and inspect spark plug. 4. Take mower to an authorized Honda servicing dealer, or refer to shop manual. Loss of Power 1. Check throttle position. 2. -
Page 43: Vibration Problems
VIBRATION PROBLEMS Excessive Vibration 1. Check mower deck and blade(s). 2. Take mower to an authorized Honda servicing dealer for repair. MOWING AND BAGGING PROBLEMS Poor Cut Quality or Poor Mowing/Bagging Performance 1. Check that the throttle lever is in the FAST position. -
Page 44: Storage
4. Stop the engine and allow it to cool. 5. After the lawn mower is clean and dry, touch up any damaged paint, and coat other areas that may rust with a light film of oil. - Page 45 Fuel Gasoline will oxidize and deteriorate in storage. Old gasoline will cause hard starting, and it leaves gum deposits that clog the fuel system. If the gasoline in your mower deteriorates during storage, you may need to have the carburetor and other fuel system components, serviced or replaced.
- Page 46 STORAGE Draining the Fuel Tank and Carburetor 1. Remove the carburetor drain bolt with a 10 mm wrench, and drain the carburetor bowl fuel into an approved container. Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel.
-
Page 47: Storage Precautions
STORAGE STORAGE PRECAUTIONS If your mower will be stored with gasoline in the fuel tank and carburetor, it is important to reduce the hazard of gasoline vapor ignition. Select a well-ventilated storage area away from any appliance that operates with a flame, such as a furnace, water heater, or clothes dryer. -
Page 48: Specifications
1-speed self propelled, 3-speed single mulching blade twin mulching blades grass bag side-discharge door & chute l =standard equipment m = optional accessory; see your Honda lawn mower dealer DIMENSIONS, WEIGHTS & CAPACITIES Length Width Overall Height Dry Weight... - Page 49 MAINTENANCE Fuel Engine Oil Transmission lubricant (SD, S3D) Spark Plug Type (Resistor plugs reduce interference with radio and television reception.) Maximum Governed Speed Throttle Cable Blade Bolt Torque TRANSMISSION Type Ground Seds TUNEUP Spark Plug Gap Idle Speed Valve Clearance (cold) Other Specifications Unleaded gasoline with a pump octane rating of 86 or higher...
-
Page 50: Assembly
Unpacking & Handlebar Setup Remove all the protective cardboard from the mower, including the piece around the handlebar. Loosen the two knobs on the lower section of the handlebar enough to raise the handlebar into the mowing position. Once the handlebar is in place, tighten the knobs securely. -
Page 51: Assembly & Set-Up
Add Oil & Fuel The mower is shipped WITHOUT OIL in the engine. Add enough SAE 10W-30 (API service category SH or SJ) oil to bring the oil level between the upper and lower limit marks on the dipstick as shown. The oil capacity is 0.58 US qt (0.55 l). -
Page 52: Additional Information
Contact a servicing Honda lawn mower dealer to purchase any of these accessories or genuine replacement parts. Be sure to have the serial number from the lawn mower and engine (page 7 & 8) when you call the dealer. Your dealer can also help you purchase other parts for your lawnmower that are not listed here. -
Page 53: Warranty
To Obtain Warranty Service: You must take the Honda Harmony lawn mower, riding mower, or lawn tractor and proof of original retail purchase date, at your expense, to any Honda Power Equipment dealer in the United States, Puerto Rico, or the U.S. Virgin Islands who is authorized to service that product, during the dealer’s normal business hours. - Page 54 ADDITIONAL INFORMATION Exclusions: THIS WARRANTY DOES NOT EXTEND TO PARTS AFFECTED OR DAMAGED BY ACCIDENT AND/OR COLLISION, NORMAL WEAR, FUEL CONTAMINATION, USE IN AN APPLICATION FOR WHICH THE PRODUCT WAS NOT DESIGNED, OR ANY OTHER MISUSE, NEGLECT, INCORPORATION OR USE OF UNSUITABLE ATTACHMENTS OR PARTS, UNAUTHORIZED ALTERATION, OR ANY CAUSES OTHER THAN DEFECTS IN MATERIAL OR WORKMANSHIP OF THE PRODUCT.
- Page 55 Accessories, Replacement Parts, and Apparel Warranty PRODUCTS COVERED BY THIS WARRANTY: Accessories Replacement Parts Apparel To Qualify for this Warranty: The accessories, replacement parts, or apparel must be purchased in the United States, Puerto Rico, or the U.S. Virgin Islands from American Honda or a dealer authorized by American Honda to sell those products.
- Page 56 ADDITIONAL INFORMATION Exclusions: THIS WARRANTY DOES NOT EXTEND TO ACCESSORIES, PARTS, OR APPAREL AFFECTED OR DAMAGED BY ACCIDENT AND/OR COLLISION, NORMAL WEAR, USE IN AN APPLICATION FOR WHICH THE PRODUCT WAS NOT DESIGNED, OR ANY OTHER MISUSE, NEGLECT, INCORPORATION OR USE OF UNSUITABLE ATTACHMENTS OR PARTS, UNAUTHORIZED ALTERATION, IMPROPER INSTALLATION, OR ANY CAUSES OTHER THAN DEFECTS IN MATERIAL OR WORKMANSHIP OF THE PRODUCT.
- Page 57 ADDITIONAL INFORMATION Emission Control System Warranty Your new Honda Power Equipment engine complies with both the U.S. EPA and State of California emission regulations. American Honda provides the same emission warranty coverage for engines sold in all 50 states. Your Warranty Rights And Obligations: California The California Air Resources Board and American Honda Motor Co., Inc.
- Page 58 ADDITIONAL INFORMATION Warranty Coverage: Honda power equipment engines manufactured after January 1, 1995 and sold in the State of California, and U.S. EPA certified engines manufactured on or after September 1, 1996 and sold in all of the United States, are covered by this warranty for a period of two years from the date of delivery to the original retail purchaser.
- Page 59 Exclusions: FAILURES OTHER THAN THOSE RESULTING FROM DEFECTS IN MATERIAL OR WORKMANSHIP ARE NOT COVERED BY THIS WARRANTY. THIS WARRANTY DOES NOT EXTEND TO EMISSION CONTROL SYSTEMS OR PARTS WHICH ARE AFFECTED OR DAMAGED BY OWNER ABUSE, NEGLECT, IMPROPER MAINTENANCE, MISUSE, MISFUELING, IMPROPER STORAGE, ACCIDENT AND/OR COLLISION, THE INCORPORATION OF, OR ANY USE OF, ANY ADD-ON OR MODIFIED PARTS, UNSUITABLE ATTACHMENTS, OR THE UNAUTHORIZED ALTERATION OF ANY PART.
- Page 60 When you write or call, please give us this information: Model and serial numbers (see page 8) Name of the dealer who sold the lawn mower to you Name and address of the dealer who services your lawn mower Date of purchase...
-
Page 61: Oxygenated Fuels
OXYGENATED FUELS Some conventional gasolines are being blended with alcohol or an ether compound. These gasolines are collectively referred to as oxygenated fuels. To meet clean air standards, some areas of the USA and Canada use oxygenated fuels to help reduce emissions. -
Page 62: Honda Publications
ADDITIONAL INFORMATION HONDA PUBLICATIONS Two other documents are available from your Honda dealer (see page 53). There is the Shop Manual, which covers complete maintenance and overhaul procedures. It is intended to be used by a skilled technician. There is also the Parts Catalog, that provides a complete, illustrated parts lists. -
Page 63: Spark Arrester Service (Optional Equipment)
SPARK ARRESTER SERVICE (optional equipment) Your lawn mower engine is not factory-equipped with a spark arrester. In some areas, it is illegal to operate an engine without a spark arrester. Check local laws and regulations. An optional USDA approved spark arrester is available from an authorized Honda servicing dealer. -
Page 64: Index
Air Cleaner Inspection...15 Air Cleaner Service ...35 Assembly ...48 Blade: Inspection... 12 Installation ... 38 Removal ... 38 Carburetor: High Altitude Operation ... 37 Choke... 9 & 17 Clogged Mower Deck ...25 Clothing Recommendations...11 Component Identification ...7 Contents...3 Cutting Height: Adjustment Levers...10 Recommendations ...24 Cutting Width Recommendations...24... - Page 65 INDEX Oil (for engine): Change ... 33 Level Check... 13 Recommendations... 34 Operating the Controls for Mowing ... 19 Oxygenated fuels ... 58 Pre-Operation Check: Lawn ... 11 Mower... 12 Publications... 59 Safety: Important Message to Parents ... 5 Safe Mowing Practices ... 22 Important Safety Information ...
-
Page 66: Quick Reference Information
QUICK REFERENCE INFORMATION Fuel type capacity Engine Oil type capacity Spark Plug type Blade Bolts torque Carburetor idle speed Maintenance before each subsequent Unleaded gasoline with a pump octane of 86 or higher (page 38). 0.29 U.S. gallon (1.1 liter) SAE 10W-30, API SH or SH (page 35) 0.58 U.S. - Page 67 POM52774-A 600.2001.06 31VG4610 Printed on 00X31-VG4-6100 Recycled Paper PRINTED IN U.S.A.
