OPERATOR'S MANUAL
18 Volt Cordless Pole Pruner
Model No. UT34020
Your new pole pruner has been engineered and manufactured to Homelite's high standard for dependability, ease of
operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual
before using this product.
Pay close attention to the Rules for Safe Operation, Warnings, and Cautions. If you use your pole pruner properly and
only for what it is intended, you will enjoy years of safe, reliable service.
Thank you for buying a Homelite pole pruner.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Advertisement
Table of Contents
Related Manuals for Homelite UT34020
Summary of Contents for Homelite UT34020
- Page 1 18 Volt Cordless Pole Pruner Model No. UT34020 Your new pole pruner has been engineered and manufactured to Homelite’s high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
-
Page 2: Table Of Contents
Introduction ... 2 Important Safety Instructions ... 3 - 5 Symbols ... 6 - 7 Specifications ... 7 Unpacking ... 7 Applications ... 8 Features ... 8 Assembly ... 9 Adjustments ... 10 Operation ... 11 - 14 Maintenance ... 15 Warranty ... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: Do not attempt to operate this unit until you have read thoroughly and understand completely all instructions, safety information, etc. contained in this manual. Failure to comply can result in accidents involving fire, electric shock, or serious personal injury. - Page 4 IMPORTANT SAFETY INSTRUCTIONS PRECAUTIONS AGAINST KICKBACK Kickback is a dangerous reaction that can lead to serious injury. Keep a good firm grip on the unit with both hands when operating the unit. Place your right hand on the rear handle and the left hand on the front handle. A firm grip will help you reduce kickback and maintain control of the unit.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS Do not dispose of batteries in a fire. The cell may explode. Batteries should be recycled, consult your local waste authority for information regarding available recycling and/or disposal options. When battery pack is not in use, keep it away from other metal objects like: paper clips, coins, keys, nails, screws, or other small metal objects that can make a connection from one terminal to another.
-
Page 6: Symbols
Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME Volts Amperes Hertz Watt Minutes Alternating Current Direct Current... -
Page 7: Specifications
If any parts are damaged or missing, contact your nearest Homelite Authorized Service Center to obtain replacement parts before attempting to operate the pole pruner. The blade, allen wrench, battery pack, battery charger, and this operator’s manual are also included. -
Page 8: Applications
Use the pole pruner for limbing and pruning small branches and limbs up to 4 in. (10.25 cm) in diameter. The long length of the pole pruner allows the operator to prune branches or limbs that are normally out of reach. KNOW YOUR POLE PRUNER See Figure 3. -
Page 9: Assembly
TO INSTALL AND REMOVE BLADE WARNING: Failure to remove the battery pack from the pole pruner could result in accidental starting which could possibly cause serious personal injury. INSTALLING THE BLADE See Figures 4 and 5. 1 Remove the battery pack from the pole pruner. 2 Remove the blade wrench from the storage area. -
Page 10: Adjustments
ADJUSTING THE SHAFT See Figures 7, 8 and 9. 1 Rotate the lower portion of the shaft adjustment collar to the “Unlock” position. See Figure 7 . 2 Lower shaft should now be free to slide down from inside the upper shaft. Make sure the shaft is pulled out to the desired position. -
Page 11: Operation
“Charging Your Pole Pruner” earlier in this manual, for normal recharging of batteries. If the charger/charging assembly does not charge your battery pack under normal circumstances, return both the battery pack and charger/charging assembly to your nearest Homelite Authorized Service Center for electrical check. BATTERY CHARGER... - Page 12 CAUTION: When placing battery pack in your pole pruner, be sure raised rib on battery pack aligns with groove in pole pruner's battery port and latches snap in place properly. Improper assembly of battery pack can cause damage to internal components. STARTING AND STOPPING THE POLE PRUNER See Figure 11.
- Page 13 WARNING: To prevent possible serious injury to yourself or to others, read, understand, and follow all instructions in this operator's manual. Keep the unit at full speed the entire time you are cutting. For second and final cuts (from top of limb or branch), hold the front cutting guide against the limb being cut.
- Page 14 As the angle of the pole pruner boom to ground increases, the difficulty of making the first cut (from the underside of limb) increases. Failure to follow this procedure can result in the blade binding and becoming pinched or trapped in the limb. If this should happen: 1 Stop the unit and remove the battery pack.
-
Page 15: Maintenance
WARNING: Any repairs requiring disassembly should only be performed by a Homelite Authorized Service Center. For the repair center nearest you, call 1-800-242- 4672. TRANSPORTING AND STORING Always place the blade cover on the blade before storing or transporting the pole pruner. -
Page 16: Warranty
One year for the following units: UT08110, UT20760, UT10901; Two years for all other Homelite products, if the product is used for personal, family or household use; 90 days, if any of the above products are used for product used for any other purpose, such as commercial or rental. - Page 17 NOTES...
-
Page 18: Parts Ordering / Service
Now that you have purchased your unit, should a need ever exist for repair parts or service, simply contact your nearest Homelite Authorized Service Center. Be sure to provide all pertinent facts when you call or visit. Please call 1-800-chainsaw (1-800-242-4672) for your nearest Homelite Authorized Service Center. You can also check our web site at www.homelite.com for a complete list of Authorized Service Centers.
