GSM TELEPHONE
SGH-U600
GSM TELEPHONE
CONTENTS
1. Specification
2. Exploded View and Parts list
3. Chart of Troubleshooting
4. Array course control
5. Block Diagrams
6. PCB Diagrams
7. MAIN Electrical Parts List
8. Reference data
9. Safety Precautions
10. Product Function

Advertisement

Table of Contents
loading

Summary of Contents for Samsung SGH-U600

  • Page 1 GSM TELEPHONE SGH-U600 GSM TELEPHONE CONTENTS 1. Specification 2. Exploded View and Parts list 3. Chart of Troubleshooting 4. Array course control 5. Block Diagrams 6. PCB Diagrams 7. MAIN Electrical Parts List 8. Reference data 9. Safety Precautions 10. Product Function...
  • Page 2: Table Of Contents

    Contents 1. Specification 1-1. GSM/CDMA General Specification ................1-1 1-2. GSM TX power class ....................1-2 2. Exploded View and Parts list 2-1. Cellular phone Exploded View ..................2-1 2-2. Cellular phone Parts list ....................2-2 2-3. Disassembly .......................2-4 2-4. Assembly ........................2-8 3. Chart of Troubleshooting 3-1.
  • Page 3 Contents 4. Array course control 4-1. Downloading Binary Files ..................4-2 4-2. Pre-requsite for Downloading ................4-2 4-3. S/W Downloader Program ..................4-3 5. Block Diagrams 6. PCB Diagrams 7. MAIN Electrical Parts List 8. Reference data 8-1. Reference Abbreviate ....................8-1 9. Safety Precautions 9-1.
  • Page 4: Specification

    0 pcl ~ 15 pcl Sensitivity -102 dBm -102 dBm -100 dBm -100 dBm T DM A M u x Cell Radius 35 Km 35 Km 2 Km SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 5: Gsm Tx Power Class

    8±4 dBm 8±4 dBm 9± 3dBm 6±4 dBm 6±4 dBm 7±3 dBm 4±4 dBm 4±4 dBm 5±3 dBm 2±5 dBm 2±5 dBm 0±5 dBm 0±5 dBm SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 6: Exploded View And Parts List

    QSP01 QCA01 QMI03 QLC01 QFR01 QVO02 QPC01 QCR68 QMP01 QFL01 QAN02 QAN06 QHI01 QCR04 QCR58 QAN07 QCK01 QSD01 QCR12 QRE01 QVO01 QRF03 QRF01 QBA01 QBA00 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 7: Cellular Phone Parts List

    QVO02 PMO-POWER KEY GH72-38555A QRE01 ASSY CASE-REAR GH98-04052A QCK01 PMO-KEY CAMERA GH72-37516A QRF03 PMO-COVER EAR/IF GH72-36576A QSD01 PMO-COVER MICRO SD GH72-36575A QVO01 PMO-VOLUME KEY GH72-37517A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 8 GH74-31527A MPR-ELEC TAPE GH74-31528A MPR-TAPE BATTERY ROOM GH74-31712A MPR-ELEC TAPE GH74-31714A MPR-INSU TAPE GH74-31884A MPR-ELEC TAPE CON TO CON B GH74-32141A AS-LCD WINDOW TAPE GH81-06188A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 9: Disassembly

    1) Open the RF COVER from the REAR case 1) Open the intenna cover dummy 1) Take off IMEI lable 1) UNSCREW the 5 POINTS SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 10 1) Separate the PBA with taking off the slide 1) Remove the number key tape FPCB on the other side 2) Open the actuator and take out the FPCB SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 11 2) Saparate Front cover from the slide upper ass'y 1) UNSCREW the 2 POINTS 1) Remove the Black shield tape on the 1) Open the Slide lower cover with lifting the case components SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 12: Assembly

    1) Put the front cover on the slide ass'y 2) Check the slide FPCB is right 1) SCREW the 2 POINTS 3) SCREW the 6 POINTS SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 13 1) Put the intenna cover - Handle with case, the intenna could be 1) Insert the numeric key FPCB damaged 2) Put the insulate tape on the connector. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 14 1) Combine the REAR cover with checking the locker 2) Press the connector to lock the cover 1) SCREW the 5 POINTS 1) SCREW the 2 POINTS 1) Set the IMEI lable SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 15 Exploded View and Parts List 1) Combine the REAR cover with checking the locker 2) Press the connector to lock the cover 1) SCREW the 5 POINTS 2-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 16: Chart Of Troubleshooting

    3. Flow Chart of Troubleshooting 3-1 BASEBAND 3-1-1. Power ON 'Power On' does not work Check the current Download again consumption more than 100mA Check the VBAT Charge the Battery more than 3.3V ① Check the VLDO7_1.8V Check UCP300 C314 of UCP300 is more than 1.8V ②...
  • Page 17 Flow Chart of Troubleshooting...
  • Page 18 Flow Chart of Troubleshooting VBAT HP_CORE_1.6V VCCD_1.8V D200 R214 U201 L200 ADJ2 MODE|DATA VLDO1_1.5V L201 DEF_1 C210 C211 C212 C213...
  • Page 19 Flow Chart of Troubleshooting...
  • Page 20 Flow Chart of Troubleshooting 9-2-2. Initial Initial Failure ① Check VCCD, VCCD_1.8V of UCP300 Check UCP300 "High" when the phone is boot on` ② Check the HP_CORE_1.6V of Check U201 U201 is "High" ③ LCD display is O.K? Check HDC500 and LCD part Sound is O.K? Check audio part...
  • Page 21 Flow Chart of Troubleshooting VMOT_3.3V VCAM_2.8V VCCD_2.9V 3.1V_TOUCH VBAT VCCD_2.9V VCAM_1.8V HDC500 TOUCH_RST TOUCH_IRQ SCL_TOUCH_M SDA_TOUCH_M PWR_ON 10 10 LCD_ADS_O MLCD_CS_O 11 11 12 12 LCD_WEN_O 13 13 14 14 LCD_DO(0) LCD_DO(1) 15 15 16 16 LCD_DO(2) LCD_DO(3) 17 17 18 18 LCD_DO(4) LCD_DO(5)
  • Page 22: Sim Part

    Flow Chart of Troubleshooting 3-1-3. Sim Part Phone can't access SIM card ① Check the pin 1 of Check the circuit related to SIM300 UCP300 Voltage = 3V ② Check the SIM connector's resolder or change (SIM300) SIM300 connector's to SIM card ③...
  • Page 23 Flow Chart of Troubleshooting SIM300 VSIM SIM_RST SIM_CLK SIM_IO 11 11 C334 C330 C331 C332 C333...
  • Page 24: Charging Part

    Flow Chart of Troubleshooting 3-1-4. Charging Part Abnormal charging part ① Battery Contact at Battery Check BTC500 BTC500? ② Charger input of Check the IFC500 IFC500 ?
  • Page 25 Flow Chart of Troubleshooting VCCD_1.8V R524 R525 VBAT JIG_ON_IF_B SDS_RXD_B IFC500 ZD500 R_ANT EAR_MICP EAR_MICN EAR_R EAR_L R527 EAR_SWITCH R528 JACK_IN R529 EAR_CHECK T_OPT R530 SDS_RXD R531 JIG_ON_IF USB_D+ USB_D- L501 USB_5.0V TA_VEXT ZD504 ZD502 ZD503 TA502 L500 C520 C517 C518 C519 TA501...
  • Page 26: Microphone Part

    Flow Chart of Troubleshooting 3-1-5. Microphone Part Microphone does not work Check the assembled status of Reassemblage microphone microphone. Check the reference resolder or change voltage on mic path (R409, R409=2.9V TA403,C431,R411) Is microphone ok? Check UCP300 3-11...
  • Page 27 Flow Chart of Troubleshooting VAUDIO_3.1V TI_1.8V C423 C424 C426 C425 VCCA_2.9V TA401 EAR_R RIGHT_LOP HPROUT R409 R455 RIGHT_LOM HPRCOM TA402 SPK_P EAR_L LEFT_LOP HPLOUT R456 SPK_N LEFT_LOM HPLCOM CSP_MICP MONO_LOP CSP_MICN MONO_LOM GPIO2 GPIO1 TA403 U408 MICDET C431 TI_SDIN MICBIAS DOUT R411 YMU_EAR_R...
  • Page 28: Speaker Part

    Flow Chart of Troubleshooting 3-1-6. Speaker Part Speaker does not work Is the terminal of check the specker connector Speaker OK? HDC500 ① Check the Change or resolder p in 5 8, 59o f H DC 5 00 HDC500 "HIGH" ②...
  • Page 29 Flow Chart of Troubleshooting VBAT SPK_N_CON SPK_N_OUT SPK_P_CON R420 AOUTAN U409 SPK_P_OUT R431 AOUTAP R432 AMP_EN C470 C471 C472 C473 3-14...
  • Page 30: Lcd

    Flow Chart of Troubleshooting 3-1-7. LCD LCD does not Display First, Check the connection of HDC500 and LCD ① Have a some problem of Replace a connector (HDC500, connector (HDC500, J1) ② Check of Backlight does work (pin 19, 20) ③...
  • Page 31: Flow Chart Of Troubleshooting

    Flow Chart of Troubleshooting VCCD_1.8V CORE_1.2V CORE_1.2V_O CORE_1.2V_PLL VCAM_2.8V VCCD_2.9V VDD_TV_2.8V USB_1.2V USB_3.3TV USB_3.3CV C438 C432 C427 C436 C437 C428 C433 C434 C435 C430 C439 C440 C441 A(1) M_SA0 SOUT0 A(2) M_SA1 XRTS0 D[0:15] M_SA2 SIN0 D(0) M_SD0 XCTS0 D(1) M_SD1 D(2) M_SD2...
  • Page 32 Flow Chart of Troubleshooting 3-1-8. Camera Camera does not work Check the connection of J2 and CAMERA Module Check camera FPCB Change camera module and check of J2 and J2 Check the voltage pin 4 of U413 Change U413 (Pin 4 : 3.3V) Check pin C5, C2 of U412 Check...
  • Page 33 Flow Chart of Troubleshooting VCAM_EN VBAT VCA_3.3V U413 3 VIN VOUT STBY C476 C477 C478 3-18...
  • Page 34 Flow Chart of Troubleshooting 3-2. RF 3-2-1. GSM850 Receiver CONTINUOS RX ON RF INPUT : 190CH Cell power : -50dBm CHECK NORMAL CONDITION c atch the channel? C100 RFS100 F101 CHECK pin6 ≥ -65dBm? resolder or change F101 CHECK F101 pin18,19 ≥...
  • Page 35 Flow Chart of Troubleshooting 3-2-2. GSM900 Receiver CONTINUOS RX ON RF INPUT : 62CH Cell power : -50dBm CHECK NORMAL CONDITION c atch the channel? C100 RFS100 F101 CHECK pin6 ≥ -65dBm? resolder or change F101 F101 CHECK pin17,18 ≥ - resolder or change 65dBm? L105, L106, C115...
  • Page 36: Dcs Receiver

    Flow Chart of Troubleshooting 3-2-3. DCS Receiver CONTINUOS RX ON RF INPUT : 698CH Cell power : -50dBm CHECK NORMAL CONDITION c atch the channel? C100 RFS100 F101 CHECK pin6 ≥ -65dBm? resolder or change F101 F101 CHECK pin14,15 ≥ - resolder or change 65dBm? L107, L108...
  • Page 37 Flow Chart of Troubleshooting 3-2-4. PCS Receiver CONTINUOS RX ON RF INPUT : 698CH Cell power : -50dBm CHECK NORMAL CONDITION c atch the channel? C100 RFS100 F101 CHECK pin6 ≥ -65dBm? resolder or change F101 F101 CHECK pin12,13 ≥ - resolder or change 65dBm? L109, L110...
  • Page 38 Flow Chart of Troubleshooting 3-23...
  • Page 39 Flow Chart of Troubleshooting 3-24...
  • Page 40 Flow Chart of Troubleshooting 3-2-5. GSM850 Transmitter F101 pi n 8 UCP300 CONTINUS TX ON F101 a bout check & CONDITION pin 6 : 2.8V 2~5dBm? change MS TX level 19 CH : 190 PAM100 pin7 RBW : 100KHz 3~6dBm? F101, C100 VBW : 100KHz check &...
  • Page 41 Flow Chart of Troubleshooting 3-2-6. GSM900 Transmitter F101 pi n 8 UCP300 CONTINUS TX ON F101 a bout check & CONDITION pin 6 : 2.8V 2~5dBm? change MS TX level 19 CH : 62 PAM100 pin7 RBW : 100KHz 3~6dBm? F101, C100 VBW : 100KHz check &...
  • Page 42: Dcs Transmitter

    Flow Chart of Troubleshooting 3-2-7. DCS Transmitter F101 pi n 8 UCP300 CONTINUS TX ON F101 a bout check & CONDITION pin 21 : 2.8V 2~5dBm? change MS TX level 12 CH : 698 PAM100 pin2 RBW : 100KHz 3~6dBm? F101, C100 VBW : 100KHz check &...
  • Page 43: Pcs Transmitter

    Flow Chart of Troubleshooting 3-2-8. PCS Transmitter F101 pi n 8 UCP300 CONTINUS TX ON F101 a bout check & CONDITION pin 21 : 2.8V 2~5dBm? change MS TX level 12 CH : 660 PAM100 pin2 RBW : 100KHz 3~6dBm? F101, C100 VBW : 100KHz check &...
  • Page 44 Flow Chart of Troubleshooting 3-29...
  • Page 45: Bluetooth

    Flow Chart of Troubleshooting 3-2-9. Bluetooth Part BT connection disable Check BT function ON Enable BT function Check the voltage of Check U102 and change C137 is around 1.8V Check 32KHz Clock on Check U103 or U103 Initial part Check the Resolder or change assembled status of AN102...
  • Page 46 Flow Chart of Troubleshooting VBAT VBT_1.8V U102 R1114D181D-TR-F VBT_EN VOUT R118 C136 C137 C139 330nF 1000nF 2200nF 3-31...
  • Page 47 Flow Chart of Troubleshooting ANT102 ACS2450EBAEC U103 BTTM46C2SA PCM_CLK PCM_CLK PIO0 PCM_IN PCM_IN PIO1 VBT_1.8V PCM_OUT PCM_OUT PIO2 PCM_SYNC PCM_SYNC PIO3 PIO4 UART_CTS PIO5 UART_RTS PIO6 BT_TXD UART_RX PIO7 BT_RXD UART_TX PIO8 PIO9 RESETB USB_DN VDD_1.8V USB_DP VDD_PIO VDD_REG C138 2200nF 3-32...
  • Page 48: Array Course Control

    4. Array course control Test Jig (GH80-03307A) Test Cable (GH39-00478A) RF Test Cable (GH39-00182A) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 49: Downloading Binary Files

    • Three binary files for downloading U600. – U600XXYY.s3 : Main source code binary. 4-2. Pre-requsite for Downloading • Downloader Program(OptiFlash.exe) • U600 Mobile Phone • Data Cable • Binary files SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 50: S/W Downloader Program

    2. Select the “Options” -> “Settings” -> “Generic” -> “Specify hardware platform”. Choose hardware platform for the downloader file setting. Set the everything else as the default values which are shown below SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 51 However, OptiFlash will use a slower speed if either the PC’s or the phone’s serial hardware is incapable of handling the selected speed SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 52 Set the directory path and choose the latest s/w binary, for example “ U600XXYY.s3”, for the downloader binary setting. The reserved memory regions are included in optiflash program, platform.def. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 53 7. After finishing downloading, Certain memory resets should be done to guarantee the normal performance. 8. Confirm the downloaded version name and etc. : *#1234# Full Reset : *2767*3855# SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 54: Block Diagrams

    5. Block Diagrams SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 55: Pcb Diagrams

    U403 VR301 U407 D200 TA400 OSC100 SIM300 U504 U406 U100 TP500 U505 F101 U506 BAT300 ZD502 U103 RFS100 ZD500 U500 TA502 G502 ANT102 ANT101 ANT100 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 56 TP512 TP513 TP510 TP516 F502 F501 F500 U413 V502 BTC500 U202 TA500 VR311 V501 V500 U409 U401 U410 U203 U408 VR200 U300 CD500 ZD504 ZD501 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 57: Main Electrical Parts List

    U502 IC-POWER SUPERVISOR 1203-004119 UCP300 IC-POWER SUPERVISOR 1203-004394 U402 IC-MULTI REG. 1203-004482 U201 IC-DC/DC CONVERTER 1203-004518 U501 IC-BATTERY 1203-004554 U405 IC-DC/DC CONVERTER 1204-002138 U407 IC-MELODY SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 58 R-CHIP 2007-000171 R534 R-CHIP 2007-000172 R536 R-CHIP 2007-000172 R537 R-CHIP 2007-001119 R309 R-CHIP 2007-001244 R312 R-CHIP 2007-001244 R314 R-CHIP 2007-001306 R439 R-CHIP 2007-007009 R438 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 59 R-CHIP 2007-008052 R430 R-CHIP 2007-008053 R512 R-CHIP 2007-008055 R207 R-CHIP 2007-008055 R212 R-CHIP 2007-008055 R213 R-CHIP 2007-008055 R216 R-CHIP 2007-008055 R508 R-CHIP 2007-008055 R509 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 60 R-CHIP 2007-008483 R535 R-CHIP 2007-008486 R514 R-CHIP 2007-008516 R108 R-CHIP 2007-008516 R211 R-CHIP 2007-008516 R450 R-CHIP 2007-008531 R204 R-CHIP 2007-008542 R107 R-CHIP 2007-008542 R109 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 61 R-CHIP 2007-009171 R412 R-CHIP 2007-009233 R505 R-CHIP 2007-009314 R116 R-CHIP 2007-009402 R411 R-CHIP 2203-000233 C217 C-CER,CHIP 2203-000438 C466 C-CER,CHIP 2203-000438 C467 C-CER,CHIP 2203-000438 C500 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 62 C-CER,CHIP 2203-005725 C108 C-CER,CHIP 2203-005727 C226 C-CER,CHIP 2203-005727 C227 C-CER,CHIP 2203-005729 C112 C-CER,CHIP 2203-005729 C448 C-CER,CHIP 2203-005736 C109 C-CER,CHIP 2203-005736 C118 C-CER,CHIP 2203-005736 C311 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 63 C-CER,CHIP 2203-006260 C324 C-CER,CHIP 2203-006260 C327 C-CER,CHIP 2203-006305 C126 C-CER,CHIP 2203-006305 C127 C-CER,CHIP 2203-006305 C130 C-CER,CHIP 2203-006305 C131 C-CER,CHIP 2203-006305 C459 C-CER,CHIP 2203-006305 C461 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 64 C-CER,CHIP 2203-006423 C429 C-CER,CHIP 2203-006423 C430 C-CER,CHIP 2203-006423 C434 C-CER,CHIP 2203-006423 C435 C-CER,CHIP 2203-006423 C437 C-CER,CHIP 2203-006423 C439 C-CER,CHIP 2203-006423 C440 C-CER,CHIP 2203-006423 C441 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 65 C-CER,CHIP 2203-006562 C417 C-CER,CHIP 2203-006562 C418 C-CER,CHIP 2203-006562 C419 C-CER,CHIP 2203-006562 C420 C-CER,CHIP 2203-006562 C421 C-CER,CHIP 2203-006562 C422 C-CER,CHIP 2203-006562 C433 C-CER,CHIP 2203-006562 C436 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 66 2203-006838 C401 C-CER,CHIP 2203-006838 C402 C-CER,CHIP 2203-006872 C138 C-CER,CHIP 2203-006872 C139 C-CER,CHIP 2203-006872 C406 C-CER,CHIP 2203-006872 C407 C-CER,CHIP 2203-006872 C408 C-CER,CHIP 2203-006872 C413 C-CER,CHIP 7-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 67 2703-002906 R105 INDUCTOR-SMD 2703-002910 L100 INDUCTOR-SMD 2703-003002 L403 INDUCTOR-SMD 2703-003196 L500 INDUCTOR-SMD 2801-004458 OSC400 CRYSTAL-SMD 2801-004466 OSC200 CRYSTAL-SMD 2801-004552 OSC100 CRYSTAL-SMD 2901-001348 F501 FILTER-EMI/ESD 7-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 68 IFC500 SOCKET-INTERFACE 3711-006323 HDC500 HEADER-BOARD TO BOARD 3711-006329 BTC500 HEADER-BATTERY 4202-001283 ANT102 ANTENNA-CHIP 4302-001158 BAT300 BATTERY-LI(2ND) 4709-001413 U103 BLUETOOTH MODULE GH09-00045A UCP200 IC MICOM 7-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 69: Reference Data

    PS : Pilot Symbol QPSK: Quadrature Phase Shift Keying RS : Reed-Solomon SI : Service Information TDM : Time Division Multiplexing TS : Transport Stream SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 70: Safety Precautions

    ● Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 71: Esd(Electrostaically Sensitive Devices) Precaution

    ● You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 72: Product Function

    - Image editor - Photo printing - Phone to TV - Offline mode - FM radio - Bluetooth - File viewer - SOS message 10-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 73 China china.samsungportal.com Asia asia.samsungportal.com Mideast & Africa mea.samsungportal.com This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. ⓒ Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2007. 03. Rev.1.0...
