- Page 1 TED8620R ADSL MODEM/ROUTER USER MANUAL VER:1.0...
- Page 2 ADSL MODEM/ROUTER USER MANUAL Manual Contents Chapter 1 TED8620R Introduction Chapter 2 TED8620R Hardware Installation Chapter 3 TED8620R Internet Connection Chapter 4 TED8620R Advanced Setting...
-
Page 3: Technical Feature
Internal Firewall, Prevent Hacker Attack 1.2 Package Content TED8620R ADSL MODEM/Router/Firewall User Manual Power adapter and power cord ADSL Splitter RJ45 network cable RJ11 Phone/DSL line 2 pcs 1.3 TED8620R Appearance 1.3.1 TED8620R LED Indicator TED8620R Front Panel... - Page 4 ADSL MODEM/ROUTER USER MANUAL There are five LED indicators in the front panel of TED8620R as following: LED Indicator Color Status Description Green Power on POWER — Power off On: LAN link established and active LAN_LINK Green Off: No LAN link...
- Page 5 Please install the TED8620R hardware system as following: Please connect TED8620R with ADSL power adaptor. Please connect the LAN port of TED8620R with your computer’s LAN card by RJ-45cable. Please insert ADSL phone into LINE port of TED8620R.
- Page 6 You can use other software to dial up directly or use router to dial up directly without special setting of TED8620R. If you want to use the built in software to dial up and use it’s router of TED8620R, please set up it as following: The TED8620R factory default setting of it’s IP address is...
- Page 7 ADSL MODEM/ROUTER USER MANUAL From the above screen we can see that in WAN Interface there are two kinds of bridge joint pattern with different parameters. When you config it please notice the VPI and VCI of local ISP .You can’t add two setting with same parameters (VCI, VPI) If you want to config same parameters as the built-in bridge joint pattern, please modify the corresponding bridge joint pattern.
- Page 8 If want to save the modified parameters permanently, please enter into User Management interface to save your setting. If you don’t do that, you will lose your setting when you use TED8620R next time and you have to setup again. This setting is to modify the intrinsic bridge pattern and if your setting of VPI &...
- Page 9 Main Manual is green. If it is red, please check if the connection of ADSL and the parameters are right. If right, the LED indicator of ADSL-LINK of TED8620R will light otherwise it will glint. 3.3 Access Internet by Fixed IP Address...
- Page 10 ADSL MODEM/ROUTER USER MANUAL Before setting please confirm if you have get the following parameters from your local ISP:VCI，VPI，User Access Method and Encapsulation format, User IP address, Subnet mask, Gateway, DNS. 3.3.2 ADSL MODEM Parameters Setting Please click Quick Configuration in the main manual, then the following screen will appear and now we illuminate them in detail.
- Page 11 ADSL MODEM/ROUTER USER MANUAL Bridged IP LLC in Encapsulation. Please input 8 in VPI and 35 in VCI and IP is 217.68.135.1 and choose Enable in DNS and input 202.96.134.133 and choose Enable in DNS. You needn’t to modify other parameters. Finally, please save them. If want to save the modified parameters permanently, please enter into User Management interface to save your setting.
- Page 12 ADSL MODEM/ROUTER USER MANUAL and input 8 in VPI and 35 in VCI and choose 1483 Bridged IP LLC in Encapsulation Finally, please save them. If want to save the modified parameters permanently, please enter into User Management interface to save your setting. If you don’t do that, you will lose your setting when you reboot the device and you have to setup again.
- Page 13 ADSL MODEM/ROUTER USER MANUAL...
-
Page 14: Lan Setup
ADSL MODEM/ROUTER USER MANUAL 4、TED8620R Advanced Setting 4.1 LAN Setup 4.1.1 LAN Setting Get LAN address：The default setting is manual. You’d better not modify it otherwise you cannot log in and access Internet. If you change it immodestly, please restore your ADSL MODEM by Reset button immediately. - Page 15 ADSL MODEM/ROUTER USER MANUAL If you want add IP address, please click ADD and if the IP address range is as same as the existing IP address range, you need to delete the existing IP pool. 4.1.3 DHCP Server Pool-Add When you want to add IP address or IP address Pool, the following screen will appear.
- Page 16 ADSL MODEM/ROUTER USER MANUAL 4.2 Admin Setting User Config：This page is to modify your password and your password can be up to 64 characters and please differentiate the small or large characters. After finishing modification, please click Submit. Commit & Reboot：This page is used to save the existing modification or reboot to restore setting according to different config.
- Page 17 ADSL MODEM/ROUTER USER MANUAL Reboot from last configuration Reboot from backup configuration Reboot from default configuration Local Image Upgrade：This page is used to update system software. Please obtain latest software from your local distributor. CAUTION: When you are updating your software, the power must be available otherwise the ADSL MODEM will be unreversed physical damaged and can’t work at all!
