EAW VFR159i Specifications

VFR159i
FEAtURES
• Two-way, full range loudspeakers
• Beamwidth-matching crossover point
• Large, user-rotatable horn for optimized pattern control
• Easy lift handles (Black version only)
DESCRiPtiON
The new VFR "i" revision brings the VF concept more fully into the EAW prod-
uct line. VFR "i" Series black versions use handles from the KF and JF Series. An
installation only white version comes without handles or a pole mount cup.
The VFR159i two-way, full range loudspeaker system includes a direct-ra-
diating, vented, 15-in LF cone transducer and a 1-in exit / 1.75-in voice coil
HF compression driver loaded with a large, square, user-rotatable 90x60
or 60x45 coverage pattern horn built on the classic MK Series horns. These
horns deliver exceptional high frequency dispersion, and their square shape
lets users "rotate the enclosure around the horn" to maintain directivity in
a horizontal configuration. The standard horn is field replaceable with an
optional 60x45 horn. This change incorporates a passive filter adjustment to
maintain consistent acoustic response and smooth beamwidth throughout
the crossover region.
Because VF Series full range systems (VFR/VFM) use HF sections similar to
those developed for the MK Series, EAW engineers could employ the same
revolutionary "beamwidth-matching" internal passive crossover/filter net-
works that set the MK Series apart from all other two-way systems. If pow-
ered by an EAW-specified amplifier or via a UX Series digital signal processor,
the VFR159i can enjoy the benefits of EAW Focusing, a technology that elimi-
nates the anomalies inherent in the time domain of any loudspeaker.
The VFR159i black version includes traditional portable features such as a
pole-mount cup, parallel NL4 4-terminal connector, barrier strip connector,
an optional transformer and handles that accept accessory covers for per-
manent installation. The white, installation-only versions omit handles and
the pole-mount cup but include NL4 connector, barrier strip connector, an
optional transformer, and multiple mounting points. The new design leaves
the enclosure sides completely smooth and attractive. Optional rigging hard-
ware is available for preconfigured arrays with VFS sub bass systems.
Six year warranty.
Eastern Acoustic Works • One Main Street • Whitinsville, MA 01588 • tel 800 992 5013 / 508 234 6158 • fax 508 234 8251 • www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice.
Specifications
2-WAY FULL-RANGE LOUDSPEAKER 90° × 60°
See NOTES TABULAR DATA for details
CONFiGURAtiON
Subsystem:
Transducer
LF 1× 15-in cone
HF 1× 1-in exit, 1.75-in voice coil Horn-loaded
compression driver
Operating Mode:
Amplifier Channels
Single-amp LF/HF
PERFORMANCE
Operating Range:
54 Hz to 20 kHz
Nominal Beamwidth:
Horz 90°
Vert 60°
Axial Sensitivity (whole space SPL):
LF/HF 98 dB
input impedance (ohms):
Nominal
LF/HF 8
input taps (With ACC-TXVFR Transformer installed):
70V
LF/HF 128W / 64W / 32W / 16W
High Pass Filter: High Pass =>50 Hz, 12 dB/octave Butterworth
Accelerated Life test:
LF/HF 69.3 V
Calculated Axial Output Limit (whole space SPL):
Average
LF/HF 126 dB
ORDERiNG DAtA
Description
EAW VFR159i Black
EAW VFR159i White
Optional Accessories
EAW ACC TX VFR [ACC-TXVFR]
Eye Bolt Forged Shoulder M10 X 1.5 X 37mm
EAW U-Bracket V15U BLK [UBKT-V15U]
EAW U-Bracket V15U WHT [UBKT-V15U]
EAW Flybar SBK-MK53 VFS-VFR159 BLK [FB5VSK]
EAWC Kit Horn 60X45 [HK64VR]
Part Number: RD0751 Rev A00
Loading
Vented
External Signal Processing
High pass filter
54 Hz to 20 kHz
Minimum
6.5 @ 130 Hz
100V
128W / 64W / 32W
600 W @ 8 ohm
Peak
132 dB
Part Number
2041030-90
2041015-90
2039034
0029818
2038546
2039032
2038320
0033364
May 2013
