JVC RC-ST3SL Service Manual

Cd portable system
Hide thumbs Also See for RC-ST3SL:

Advertisement

Quick Links

Download this manual See also: Instruction Manual
Revised 28/9/2004 Service Policy added
SERVICE MANUAL
SERVICE POLICY
No service parts are available for this model.
Exchange only.
Contents
CD PORTABLE SYSTEM
RC-ST3SL
TUNER
TAPE
CD
PRESET/
PROGRAM
INTRO
REPEAT
FM MODE
RANDOM
VOL
HBS
EQ
Specification --------------------------------------------------------------------------------------------1-2
Safety Precautions -----------------------------------------------------------------------------------1-3
Preventing static electricity ------------------------------------------------------------------------ 1-5
Block Diagram ---------------------------------------------------------------------------------------- 1-6
Schematic Diagrams -------------------------------------------------------------------------------- 1-8
COPYRIGHT
2003 VICTOR COMPANY OF JAPAN, LTD.
STANDBY
REMOTE
SENSOR
SEARCH UP
PLAY/PAUSE
SEARCH DOWN
STOP
RANDOM
INTRO
RC-ST3
CD PORTABLE SYSTEM
Area Suffix
B -------------------------- U.K.
E -------Contnental Europe
EN ------- Northern Europe
EV --------- Eastern Europe
No.MB063
2003/11

Advertisement

loading

Related Manuals for JVC RC-ST3SL

Summary of Contents for JVC RC-ST3SL

  • Page 1 Revised 28/9/2004 Service Policy added SERVICE MANUAL CD PORTABLE SYSTEM SERVICE POLICY RC-ST3SL No service parts are available for this model. Exchange only. TUNER TAPE PRESET/ PROGRAM INTRO REPEAT FM MODE RANDOM STANDBY REMOTE SENSOR SEARCH UP PLAY/PAUSE SEARCH DOWN...
  • Page 2 Specification Compact disc player Signal detection system Non-contact optical pickup (semiconductor laser) Number of channels 2 channels (stereo) Frequency response 20 Hz - 20 000 Hz Signal-to-noise ratio 90 dB Wow and flutter Less than measurable level Tuner FM frequency range 87.50 MHz - 108.00 MHz AM frequency range 522 kHz - 1 629 kHz...
  • Page 3 1. This design of this product contains special hardware and many circuits and components specially for safety purposes. For continued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services should be performed by qualified personnel only.
  • Page 4 (U.K only) 1. This design of this product contains special hardware and many circuits and components specially for safety purposes. For continued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replacement parts must be identical to those used in the original circuits.
  • Page 5 Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as mechanism unit.

  • Page 6: Block Diagram

    Block Diagram FM ANT FM OSC. FM RF IC101 LA1823 IC102 LC72131 FM F/E , IF/DET/MPX AM RF/IF/DET. AM ANT TU-5V AM OSC. REG. VD103 TU L&R CH. R/P HEAD REC L&R CH. R/P SW. IC201 TA8142AP R/P PRE.AMP. R/P SW. P/B L&R CH.
  • Page 7 DISC IC901 IC902 LA9242M LC78622E (ASP.) (DSP.) PICKUP SPINDLE MOTOR IC903 LA6541D MOTOR/ACTUATOR DRIVER SLED MOTOR Q907 CD DOOR LEAF SW. IC701 LC587008 Q704 (u-COM.) JOG.VOL. P-CON. LAMP CASS.DECK LEAF SW. L. SPEAKER 5V REG. IC301 TA8227P POWER AMP. DECK MOTOR R.
  • Page 8 Schematic Diagrams...
  • Page 10 1-10...
  • Page 11 1-11...
  • Page 12 JVC Euorpe Limited JVC House JVC Budiness Park 12 Priestley Way, London NW2 7BA United Kingdom 2003/11 (No.MB063)
