How Does It Work - Baxi ECOGEN Product Manual

We've explained the many benefits of switching to Baxi Ecogen, but
how exactly does it work? While an undoubtedly innovative and
overview on how inner workings of the Baxi Ecogen. For a more
detailed explanation, don't hesitate to get in touch.
Stirling engine
Power Piston
Electrical generation
For electricity generation, the Baxi Ecogen uses a
free piston Stirling engine. This engine is heated
by burning gas. The helium working fluid expands
and contracts to move a piston up and down. This
piston travels between a copper coil, generating
up to 1kW of electricity at 50Hz single phase.

How does it work?

Electrical connection
The Baxi Ecogen uses a single cable connection
for its own electricity consumption and for
additional wiring is required for electrical output
and the Baxi Ecogen can be connected to the
existing domestic electricity circuit.
Displacer
Planar Spring
5
