This manual covers different models. The cooktop you have purchased may have some or all of the items listed. The locations and
appearances of the features shown here may not match your model.
Control Panel
1. Left Rear Control Knob
2. Right Rear Control Knob
Cooktop
1
2
1. Ceramic Glass Cooktop
2. Surface Cooking Area
(Dual Watt Element on some models)

PARTS AND FEATURES

3. Left Front Control Knob
(Dual Watt Element on some models)
3
3. Model and Serial Number Plate
(located on outside bottom of
cooktop)
1
2
3
4
5
4. Right Front Control Knob
5. Surface Cooking Area Locator
4
5
4. Control Panel
5. Hot Surface Indicator Light
