Placing the wireless sender and wireless receiver
The wireless sender and wireless receiver must be separated by
at least 12 inches and be within 100 feet of each other for linked
operation.
To avoid risk of electric shock and fire, and to prevent damage,
locate the wireless sender and wireless receiver units with no
obstructions in front.
Wall mounting the wireless sender and
wireless receiver (optional)
The hanging holes for wall mounting both the wireless sender
and wireless receiver are 2 5/8" (67 mm) apart.
Note: If you need to mount the wireless sender or wireless
receiver on a wall, install it against the wall so that cool air can
travel through the ventilation slots in the unit and come out the
top.
2 5/8 inches
(67 mm)
