- Page 1 Wind Top AP1612 All-in-One (AIO) PC MS-A612 System G52-A6121X8...
-
Page 2: Table Of Contents
Preface Preface Contents Copyright Notice ���������������������������������������������������������������������������������������������iii Trademarks ����������������������������������������������������������������������������������������������������iii Revision ���������������������������������������������������������������������������������������������������������iii Upgrade and Warranty ���������������������������������������������������������������������������������� iv Acquisition of Replaceable Parts ������������������������������������������������������������������ iv Technical Support ����������������������������������������������������������������������������������������� iv Green Product Features �������������������������������������������������������������������������������� iv Environmental Policy ����������������������������������������������������������������������������������� v Chemical Substances Information ����������������������������������������������������������������� v Battery Information ����������������������������������������������������������������������������������������� v Safety Instructions �����������������������������������������������������������������������������������������... -
Page 3: Copyright Notice
Trademarks All trademarks are the properties of their respective owners� ￭ MSI is a registered trademark of Micro-Star Int’l Co�, Ltd� ￭ Intel is a registered trademark of Intel Corporation� ￭... -
Page 4: Upgrade And Warranty
Alterna- tively, please try the following help resources for further guidance� ◙ Visit the MSI website for technical guide, BIOS updates, driver updates and other information via http://www�msi�com/service/download/ ◙... -
Page 5: Environmental Policy
Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products� ◙ Visit the MSI website and locate a nearby distributor for further recycling information� ◙ Users may also reach us at cso@msi�com for information regarding proper Disposal, Take-back, Recycling, and Disassembly of MSI prod- ucts�... -
Page 6: Safety Instructions
Preface Preface Safety Instructions Read the safety instructions carefully and thoroughly� All cautions and warnings on the equipment or user’s manual should be noted� Keep the User’s Guide that comes with the package for future reference� Keep this equipment away from humidity and high temperature� Lay this equipment on a reliable flat surface before setting it up�... - Page 7 Wind Top AP1612 Wind Top AP1612 Never pour any liquid into the opening that could damage or cause electri- cal shock� Place the power cord in a way that people are unlikely to step on it� Do not place anything on the power cord�...
-
Page 8: Ce Conformity
Preface Preface CE Conformity Hereby, Micro-Star International CO�, LTD declares that this de- vice is in compliance with the essential safety requirements and other relevant provisions set out in the European Directive� FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules�... -
Page 9: Weee Statement
Wind Top AP1612 Wind Top AP1612 WEEE Statement (English) Under the European Union (“EU”) Directive on Waste Electrical and Electronic Equipment, Directive 2002/96/EC, which takes effect on August 13, 2005, products of “electrical and electronic equipment” cannot be discarded as municipal waste anymore and manufacturers of covered electronic equipment will be obligated to take back such products at the end of their useful life�... - Page 10 Preface Preface (Greek) (Ελληνικά) Σύμφωνα με την Οδηγία 2002/96/ΕΚ της Ευρωπαϊκής Ένωσης («ΕΕ») περί Απόρριψης Ηλεκτρικού και Ηλεκτρονικού Εξοπλισμού (WEEE), η οποία λαμβάνει ισχύ στις 13 Αυγούστου 2005, τα προϊόντα «ηλεκτρικού και ηλεκτρονικού εξοπλισμού» δεν είναι δυνατόν να απορριφθούν πλέον ως κοινά απορρίμματα και οι κατασκευαστές κεκαλυμμένου...
- Page 11 Wind Top AP1612 Wind Top AP1612 (Indonesia) (Bahasa Indonesia) Sesuai dengan Regulasi Uni Eropa (“UE”) perihal WEEE (Limbah Peralatan Listrik dan Elektronik), Directive 2002/96/EC, yang berlaku sejak 13, 2005, produk “peralatan listrik dan elektronik” tidak lagi dapat dibuang sebagai sampah umum dan pabrik peralatan elektronik diwajibkan untuk mengambil kembali produk terse- but pada saat masa pakainya habis�...
- Page 12 Preface (Danish) (Dansk) I henhold til direktiv fra den europæiske union (EU) vedrørende elektrisk og elektronisk affald , Direktiv 2002/96/EC, som træder i kraft den 13� august 2005, må produkter som “elektrisk og elektronisk udstyr” ikke mere bortskaffes som kommunalt af- fald�...
-
Page 13: Overview
Chapter 1 Overview This system is designed with green commerce and smart digital lifestyle, using an LED backlit display to increase clarity, while reducing the burden to the eyes. With the compact chassis and flexible stand, it blends technology with life, making computers easier to use - suitable for both individuals and businesses. -
Page 14: Packing Contents
Overview Overview Packing Contents Wind Top Series AC/DC Adapter AC Power Cord User Manual & LCD Display Wiper Driver/Utility Disk Quick Guide Keyboard (Optional) Mouse (Optional) Stylus (Optional) * Please contact us immediately if any of the items is damaged or missing� * The illustrations are for reference only and your packing contents may slightly vary depending on the model you purchased�... -
Page 15: System Overview
Wind Top AP1612 Wind Top AP1612 System Overview Front View Microphone The built-in microphone can be used for video chatting online� Webcam The built-in webcam with the microphone can be used for picture taking, video recoding, online conferencing and any other interactive applications�... -
Page 16: Rear View
Overview Overview Rear View Ventilator The ventilator on the enclosure is used for air convection and to prevent the equipment from overheating� Do not cover the ventilator� Stand Use this stand to position your system on a flat and stable surface� Cable Routing Hole Route the cables through the cable routing hole to avoid cable spaghetti when connecting devices�... - Page 17 Wind Top AP1612 Wind Top AP1612 Top & Bottom View LAN2 LAN1 Ventilator The ventilator on the enclosure is used for air convection and to prevent the equipment from overheating� Do not cover the ventilator� Line-Out Jack This connector is provided for headphones or speakers�...
- Page 18 Overview Overview RJ-45 LAN Jack (LAN2 Optional) The standard RJ-45 LAN jack is provided for connection to the Local Area Network (LAN). You can connect a network cable to it. Green/ Orange Yellow Color LED State Condition Right Yellow LAN link is not established. On (steady state) LAN link is established.
-
Page 19: Side View
Wind Top AP1612 Wind Top AP1612 Side View System Power Button Press the system power button to turn the system on or off� System Power LED The power LED glows when the system is turned on and goes off when the system is shut down�... - Page 20 Overview Overview USB 2�0 Port The USB (Universal Serial Bus) port is for attaching USB devices such as key- board, mouse, or other USB-compatible devices� It supports up to 480Mbit/s (Hi-Speed) data transfer rate� Power Jack The AC/DC adapter converts AC power to DC power for this jack� Power sup- plied through this jack supplies power to the PC�...
-
Page 21: System Specifications
Wind Top AP1612 Wind Top AP1612 System Specifications Processor ■ Intel Celeron Processor B800 Series ® ® Chipset ■ Intel HM65 chipset ® Memory ■ 1 DDR3 1333 MHz SO-DIMM slot ■ Supports the maximum of 4GB ■ Wired LAN: supported by Realtek RTL8111E Gigabit Ethernet controller ®... - Page 22 Overview Overview Storage ■ Hard Disk Drive: 2�5”, SATAII ■ Card Reader: SD/ MMC/ MS card reader Smart card reader (Optional) Stereo Speaker ■ 2 stereo speakers WebCam ■ 0�3 MP WebCam with microphone Power Supply ■ 65 Watt AC/ DC adapter with active PFC Input: 100-240V, 1�5A, 50-60Hz Output: 19V 3�42A...
-
Page 23: Component Replacement & Upgrade
Wind Top AP1612 Wind Top AP1612 Component Replacement & Upgrade Please note that certain components preinstalled in the product may be up- gradable or replaceable by user’s request depending on the models users pur- chased� 1-11 1-11 To learn more about upgrade limitation, please refer to the specifications in the User’s Manual�... -
Page 25: Getting Started
Chapter 2 Getting Started This chapter provides you with the information on hard- ware setup procedures� While connecting peripheral devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity�... -
Page 26: Safety & Comfort Tips
Getting Started Getting Started Safety & Comfort Tips The AIO PC is a portable platform that allows you to work anywhere� However, choosing a good workspace is important if you have to work with your PC for a long period of time� 1�... -
Page 27: Hardware Setup
Wind Top AP1612 Wind Top AP1612 Hardware Setup Positioning Your System 1. Place your system on a flat and steady surface such as a table or desk. 2. Tilt the display and pull the stand outwards to your desired extent. Make sure... - Page 28 Getting Started Getting Started Connecting the AC Power 1. Assemble the AC/DC adapter and the AC power cord. 2. Plug the DC end of the adapter to the AIO PC. 3. Plug the male end of the AC power cord to the electrical outlet. Important We suggest that you connect the AC/DC adapter to your AIO PC first and then connect the AC power cord to the socket-outlet for safety concerns.
-
Page 29: Powering On The System
Wind Top AP1612 Wind Top AP1612 Powering on the System Press the power button to power on the system�... -
Page 31: System Operations
Chapter 3 System Operations This chapter provides you with essential information on system operations� Important All information is subject to change without prior notice�... -
Page 32: System Booting Setup For The First Time
System Operations System Operations System Booting Setup for the first time For the first-time use, you will need to go over the following steps to start using your Wind Top Series AIO PC� The entire booting setup will take you around 30 minutes�... -
Page 33: Touch Panel Calibration (Only For Single-Touch Model)
Wind Top AP1612 Wind Top AP1612 Touch Panel Calibration (Only for single-touch model) Wind Top Series AIO PC has touch panel function� If the mouse cursor can not match the move, users could use the calibration tool installed in the system to adjust the accuracy of the touch panel�... - Page 34 System Operations System Operations 3� Follow the on-screen instructions to calibrate the touch panel� Important Do not touch the screen directly with any sharp-pointed object� • Actual product specifications may vary with territories� •...
-
Page 35: Network Connection Under Windows
Wind Top AP1612 Wind Top AP1612 Network Connection under Windows Wired LAN 1� Go to [Start] > [Control Panel]� 2� Select [Connect to the Internet] under [Network and Internet]�... - Page 36 System Operations System Operations 3� Select [Broadband (PPPoE)] to connect using DSL or cable that requires a user name and password� 4� Type the information from your Internet Service Provider (ISP) and click [Connect] to establish your LAN connection�...
-
Page 37: Wireless Lan
Wind Top AP1612 Wind Top AP1612 Wireless LAN 1� Go to [Start] > [Control Panel]� 2� Select [Connect to the Internet] under [Network and Internet]�... - Page 38 System Operations System Operations 3� Select [Wireless] to connect using a wireless router or a wireless network� 4� A list of available WLAN connections pops up� Choose a connection from the list or click [Open Network and Sharing Center] to establish a new connec- tion�...
- Page 39 Wind Top AP1612 Wind Top AP1612 6� Followingly, choose [Manually connect to a wireless network] and click [Next] to continue� 7� Enter information for the wireless network you intend to add and click [Next] to proceed� 8� A new WLAN connection has been made� Click [Close] to exit or select...
-
Page 40: Power Management
System Operations System Operations Power Management Power management of personal computers (PCs) and monitors has the poten- tial to save significant amounts of electricity as well as deliver environmental benefits� To be energy efficient, turn off your display or set your PC to sleep mode after a period of user inactivity�... - Page 41 Wind Top AP1612 Wind Top AP1612 ■ The Shut Down Computer menu presents the options of Sleep (S3/S4) & Shut Down (S5) for rapid and easy management of your system power� Power Management through ENERGY STAR qualified monitors (Optional) The power management feature allows the computer to initiate a low-power or “Sleep”...
-
Page 42: System Recovery Tool
System Recovery Tool Important The Recovery Tool is only available on systems bundled with Windows OS and MSI utilities by default� The purposes for using the Recovery Tool may include: ■ Restore the system back to the initial status of original manufacturer’s default settings�... -
Page 43: System Backup
Wind Top AP1612 Wind Top AP1612 3� Enter the Recovery Tool� This tool contains three features: Backup System, Restore System and Recover to factory default� System Backup It is highly recommended that users back up the system as the solution in the event of a catastrophic disk failure or other accidents�... - Page 44 System Operations System Operations 2� Select [BACKUP] to start the system backup immediately� The Initial Backup The initial backup may take a while� Please let it complete without interruption� 3-14 3-14 Subsequent Backups Subsequent backups will replace the previous backup files�...
- Page 45 Wind Top AP1612 Wind Top AP1612 3� The system backup is in progress� Please note that it may take a while� Do not switch off the power, or it may cause unknown damage to the system� 4� Alternatively, select [CANCEL] to stop the system backup immediately� Please do not switch off the power while the system backup cancellation is in prog- ress�...
-
Page 46: System Restore
System Operations System Operations 5� The following message indicates a successful system backup� Press [OK] to finish� System Restore This tool helps to return the system to a previous state with the backup files that users created and saved in the hard disk drive beforehand� If no backup files are available, the system will be restored to the default setup�... - Page 47 Wind Top AP1612 Wind Top AP1612 2� Select [OK] or [NEXT] so that the system can recover to the previous backup or default setup� Alternatively, select [CANCEL] to stop the system restore immediately� With backup files: restoring the system to the previous back- ...
- Page 48 System Operations System Operations 3� The system restore is in progress� Please note that it may take a while� Do not switch off the power, or it may cause unknown damage to the system� 4� The following message indicates a successful system restore� Press [OK] to finish�...
-
Page 49: System Recovery
Wind Top AP1612 Wind Top AP1612 System Recovery This tool helps to recover the system back to factory default settings� All data on the HDD will be erased while all settings will be restored to factory default� Follow the instructions below to continue: 1�... - Page 50 System Operations System Operations 3� Please select [OK] so that the system can recover its default setup� 4� The system recovery is in progress� Please note that it may take a while� Do not switch off the power, or it may cause unknown damage to the system� 3-20 3-20...
- Page 51 Wind Top AP1612 Wind Top AP1612 5� The following message indicates a successful system recovery� Press [OK] to finish� Restart the system and access the Windows operating system as usual� If the recovery process fails or is interrupted, please start the whole procedure all over again�...
