RocketFish RF-MAB2 Quick Setup Manual

Bluetooth Stereo Headset
RF-MAB2
FIND YOUR USER GUIDE ONLINE!
We are going green so a copy of your User Guide is
not provided in the box but is available online.
Go to www.rocketfishproducts.com,
click Support & Service, enter your model number
in the box under Manual, Firmware, Drivers &
Product Information, then click Search.
Before using your new product, please read
these instructions to prevent any damage.
QUICK SETUP GUIDE
Congratulations on your purchase of the Rocketfish Mobile
Bluetooth Stereo Headset. Listen to music wirelessly with
Bluetooth audio devices and answer phone calls hands-free.
You can use the headset to answer and make calls and to play
music stored on your cell phone.
Features
Volume
Logo
with LED
Receiver
Receiver
USB port
Microphone

Package contents

• Bluetooth Stereo Headset • AC wall adapter
• USB charging cable • Quick Setup Guide
• Replacement earphone pads

Turning the headset on and off

• To turn the headset on or off, press and hold the Power
button for three seconds. The LED flashes blue.

Pairing the headset

Cell phone or MP3 player
1 With the headset turned off, press and hold Talk until
the LED blinks blue and red rapidly, indicating pairing mode
is activated (This typically takes three to six seconds).
2 On the phone or MP3 player when paring mode is activated,
select RF-MAB2 from the list of discovered devices, then
enter the password 0000 (four zeros) to pair your headset.
For more information on pairing Bluetooth devices to your
cell phone or MP3 player, see the device' s documentation.
Note: After the headset has been successfully paired with the
cell phone or MP3 player, the headset connects automatically
to the phone or MP3 player the next time the headset is
turned on near the phone or player.
Computer running Windows 7:
Note: Before you pair the headset with the computer, make
sure that the computer is equipped with a Bluetooth radio.
Refer to the computer' s documentation or contact the computer
manufacturer for more information. If you do not have a
Bluetooth radio, install a Bluetooth USB adapter (dongle).
1 Turn on Bluetooth on the computer. For instructions, see the
computer' s documentation or contact the computer
manufacturer.
2 Double-click the Bluetooth icon in the system tray, near the
clock.
3 Click Add a device.
4 With the headset turned off, press and hold
the LED blinks blue and red rapidly, indicating pairing mode
is activated (This typically takes three to six seconds).
5 Double-click the RF-MAB2 icon on the computer or
highlight the icon and click Next.
Play/Pause
6 Click Close after the headset has been paired.
Note: To use the headset, it must be selected as the default
Power/Talk
recording and playback device on the computer. If the headset
is not the default playback device, complete Steps 7 through 11.
7 Click Start, then click Control Panel.
8 Click Hardware and Sound, then under Sound, click
Manage audio devices.
9 On the Recording tab, select Headset Microphone
Bluetooth Hands-free Audio, then click Set Default.
10 On the Playback tab, select Speakers Bluetooth
Hands-free Audio, then click Set Default.
11 Click OK.
Computer running Windows Vista:
Note: Before you pair the headset with the computer, make
sure that the computer is equipped with a Bluetooth radio.
Refer to the computer' s documentation or contact the computer
manufacturer for more information. If you do not have a
Bluetooth radio, install a Bluetooth USB adapter (dongle).
1 Turn on Bluetooth on the computer. For instructions, see
the computer' s documentation or contact the computer
manufacturer.
2 Double-click the Bluetooth icon in the system tray, near the
clock.
3 Click Add Wireless Device.
4 With the headset turned off, press and hold
the LED blinks blue and red rapidly, indicating pairing
mode is activated (This typically takes three to six seconds).
5 Double-click the RF-MAB2 icon on the computer or
highlight the icon and click Next.
6 Click Close after the headset has been paired.
Note: The headset should be automatically selected as the
default playback device. If the headset is not the default
playback device, complete Steps 7 through 9.
7 Click Start, then click Control Panel.
8 Click Hardware and Sound, then under Sound, click
Manage audio device.
9 On the Playback tab, select Speakers 2-Bluetooth
Hands-free Audio, then click Set Default.
10 On the Recording tab, select Headset Microphone
2-Bluetooth Hands-free Audio, then click Set Default.
11 Click OK.
Computer running Windows XP:
Talk until
Note: Before you pair the headset with the computer, make
sure that the computer is equipped with a Bluetooth radio.
Refer to the computer' s documentation or contact the computer
manufacturer for more information. If you do not have a
Bluetooth radio, install a Bluetooth USB adapter (dongle).
1 Turn on Bluetooth on the computer. For instructions, see the
computer' s documentation or contact the computer
manufacturer.
2 Double-click the Bluetooth icon in the system tray, near the
clock. My Bluetooth Places opens.
3 Click Add a New Bluetooth Device. The Add Bluetooth
Device Wizard opens.
4 Click Next.
5 With the headset turned off, press and hold
the LED blinks blue and red rapidly, indicating pairing mode
is activated (This typically takes three to six seconds).
6 Double-click the RF-MAB2 icon on the computer or
highlight the icon and click Next.
Note: If you are unable to locate the RF-MAB2 icon, click the
Search Again button.
7 Enter 0000 (four zeros) in the Bluetooth security code
field, then click Next.
8 Select one of the Bluetooth hands-free types shown on the
Add a Bluetooth Device Wizard screen, then click Next.
9 Select the services shown on the wizard screen to use with
your Bluetooth headset, then click Finish.
10 To connect the device, double-click the MAB2 Hands-Free
Unit icon or the RF-MAB2 Stereo Audio icon.
Note: To use the headset, it must be selected as the default
Talk until recording and playback device on the computer. If the headset is
not the default playback device, complete Steps 11 through 14.
11 Click Start, then click Control Panel.
12 Click Sounds, Speech, and Audio Devices.
13 Click the Sounds and Audio Devices icon.
14 On the Audio tab, select Bluetooth Hands-free Audio
or Bluetooth Stereo Audio in the Sound recording list,
and select Bluetooth Hands-free Audio in the Sound
playback list, if it is an option.
Talk until
