GB
8-07-2003
15:32
AIR CONDITIONING WITH SEMI-PERMA-
NENT INSTALLATION
If desired, Pinguino can also be installed on a
semi-permanent basis fig. 7.
In this case it will be necessary to:
• Drill a hole in a perimeter wall or in a win-
dow pane. Observe the height limits (fig.
9) and the dimensions of the hole given in
fig. 8.
In the window-
In the base
pane
of the
window
frame
8
Pagina 9
S e t t i n g u p
7
In the wall: we
advise you to
insulate the sec-
tion of the wall
with appropria-
te
insulation
material.
• Fit the flange (13) supplied to the hole.
• Fix the hose (14) in the housing at the rear
of the appliance (fig 1)
• Fit the end of the hose to the flange (15)
as shown in fig. 9.
When the hose (14) is not connected, the
hole can be closed off with the flange stop-
per (13).
N.B.
When operating the appliance with semi-per-
manent installation, it is advisable to leave a
door slightly ajar (even only 1cm), to ensure
free circulation of air.
DEHUMIDIFICATION
Position the appliance in the room without
inserting the air exhaust hose (14); this ensures
that the dehumidified air will be released
directly into the atmosphere.
The air emitted through the front grill will be
cold while the air from the rear will be warm
(fig. 10) thus ensuring that the room is dehu-
midified without variation in temperature.
9
10
9
