ELECTRICAL CONNECTION (UK ONLY) If your appliance comes fitted with a plug, it will incor- If the plug is a moulded-on type, the fuse cover must be porate a 13 Amp fuse. If it does not fit your socket, the re-fitted when changing the fuse using a 13 Amp Asta plug should be cut off from the mains lead, and an approved fuse to BS 1362.
RADIANT HEATER Technical Data Type Category Maximum Medium Gas pressure Input Input Input 1.50 4.20 2.85 28÷30 mbar This appliance is designed to operate with Butane at nominal pressure: 28 ÷ 30 mbar. For a regular gas combustion the required air quantity is: 8,4 m WARNINGS ALWAYS use heater in accordance with instructions.
GENERAL SAFETY INSTRUCTIONS Gas bottle Gas Bottle with 15 kg of maximum capacity can be installed. Changing of gas bottle must not be carried out in the presence of a naked flame. Use the gas bottle always in upright position. If a screw on regulator is used ensure that the regulator washer is present and in good condition -replace if in any doubt.
OPERATING INSTRUCTIONS Lighting the heater 1. Turn on the gas at the gas bottle tap. 2. FROM «G» POSITION, fully depress the control knob for 10 seconds and turn to (Small Flame) position. (If pilot flame does not ignite return to starting position and repeat).
IMPORTANT DO NOT cover the appliance when in operation, this could cause a dangerous rise of the temperature of the fan heater with consequent risk of fire. Important notes Your heater must always be earthed: warranty does not cover damages caused by non- observance of this warning.
