OWNER'S MANUAL AND INSTALLATION
Register your product at www.samsung.com/register
CONTENTS
...............................................................2
........................................................5
SETTING UP THE REFRIGERATOR ........................................................5
MAJOR FEATURES.....................................................................................5
CONTROL PANEL .......................................................................................6
DIGITAL PANEL ..........................................................................................8
TEMPERATURE CONTROL ......................................................................9
ICE and COLD WATER DISPENSER.........................................................9
SHELVES and BINS...................................................................................10
FOOD STORAGE GUIDE .........................................................................11
DRAWER GUIDE...............................................13
REMOVING THE FREEZER ACCESSORIES .........................................15
REMOVING THE REFRIGERATOR ACCESSORIES..............................15
CLEANING THE ACCESSORIES .............................................................16
WATER FILTER..........................................................................................17
DOORS.......................................................................................................17
INSTALLATION OF THE REFRIGERATOR ............................................18
REMOVING THE REFRIGERATOR DOORS...........................................29
REATTACHING THE REFRIGERATOR DOORS.....................................22
LEVELING THE REFRIGERATOR ...........................................................24
CHECKING THE WATER DISPENSER LINE ..........................................27
INSTALLATION OF THE WATER DISPENSER LINE..............................28
TROUBLESHOOTING ...............................................................................31
SIDE BY SIDE
REFRIGERATOR
................................................18
DA99-01278C REV(1.1)

Advertisement

Table of Contents
loading

Related Manuals for Samsung Side by Side Refrigerator

Summary of Contents for Samsung Side by Side Refrigerator

  • Page 1: Table Of Contents

    REMOVING THE REFRIGERATOR DOORS...........29 REATTACHING THE REFRIGERATOR DOORS........22 LEVELING THE REFRIGERATOR ............24 ADJUSTING THE CLEARANCE BETWEEN THE DOORS ....26 CHECKING THE WATER DISPENSER LINE ..........27 INSTALLATION OF THE WATER DISPENSER LINE......28 TROUBLESHOOTING ................31 Register your product at www.samsung.com/register DA99-01278C REV(1.1)

  • Page 2: Safety Warning Signs

    SAFETY WARNING SIGNS SAFETY INFORMATION • Before operating the appliance, please read this manual thoroughly and retain it for your reference. • Because these following operating instructions cover various models, the characteristics of your WARNING refrigerator may differ slightly from those described in this manual. OTHER SIGNS USED CAUTION/WARNINGS USED Represents something you must NOT do.
  • Page 3 • If you smell pharmaceutical or smoke, pull out power plug immedi- pull out the power plug. ately and contact your Samsung electronics service center. - Deterioration in the insulation may cause fire. • Keep ventilation opening in the appliance enclosure or mounting •...
  • Page 4 SAFETY WARNING SIGNS WARNING SIGNS FOR DISPOSAL • When disposing of this or other refrigerator/s, remove the door/door In the event of a power failure, call the local office of your seals, door latch so that small children or animals cannot become Electricity Company and ask how long it is going to last.

  • Page 5: Operating Instructions

    SETTING UP THE REFRIGERATOR Once you have performed the following steps, your refrigerator should be fully operational. If not, check the power supply and electricity source. If you have any questions, contact your SAMSUNG service center. Place the refigerator in an appropriate...

  • Page 6: Control Panel

    CONTROL PANEL With Chilled Bin With Coolselect Zone FREEZE BUTTON To set the freezer temperature, press FRIDGE BUTTON the button repeatedly to change the set temperature in sequence between To set the fridge temperature, press the button and -25 . repeatedly to change the set temperature in sequence between 7 and 1 .
  • Page 7 CONTROL PANEL(Homebar Option) With Chilled Bin With Coolselect Zone FREEZE BUTTON To set the freezer temperature, press FRIDGE BUTTON the button repeatedly to change the set temperature in sequence between -14 To set the fridge temperature, press the button and -25 . repeatedly to change the set temperature in sequence between 7 and 1 .

  • Page 8: Digital Panel

    DIGITAL PANEL Freezer indicates the current freezer temperature. Fridge indicates the current refrigerator temperature. Quick Cool, Thaw, and Select show the status of the CoolSelect Zone Drawer Power Freeze • This light goes on when you press the Power Freeze button. Press this button to quickly return the freezer to its set temperature.

  • Page 9: Temperature Control

    TEMPERATURE CONTROL Freezer Refrigerator • • The refrigerator temperature can be set between The freezer temperature can be set between and 1 . and -25 . • • Press the Fridge button repeatedly until the desired Press the Freeze button repeatedly until the desired temperature is shown in the temperature display.

  • Page 10: Shelves And Bins

    SHELVES AND BINS Freezer Xtra Space (on some models) Door Bin Ice Maker Bucket Light Ice Chute Glass Shelf Light Switch Tilt Pockets Plastic Drawers Wire Type Drawers (for RSC6F) Front Leg Cover Refrigerator Dairy Compartment Water Filter Compartment Light (upper) Wine Shelf (On Some Models) Spill-proof glass Shelf...

  • Page 11: Food Storage Guide

    FOOD STORAGE GUIDE FROZEN FOOD STORAGE IN FREEZER To get more space , you can remove the TRAY- ICE BUCKET, and PARTITION COOL. It does not affect thermal and mechanical characteristics. A declared storage volume of frozen food storage compartment is calculated with these parts removed. Ice chute Do not put your fingers, hands or any other unsuitable objects in the chute or ice-maker buck- et, as this may result in personal injury or material damage.
  • Page 12 FOOD STORAGE GUIDE CHILLED FOOD STORAGE IN REFRIGERATOR Drawer • Can be used to store meats and dry foods. Stored food should be wrapped securely using foil or other suitable wrapping materials or containers. Wine Shelf (On Some Models) • Place your wine bottles on the shelf to maintain their taste.

  • Page 13: Coolselect Zone

    CoolSelect Zone Drawer GUIDE “Quick Cool” Button • You can use the Quick Cool feature with the CoolSelect Zone • “Quick Cool” allows 1~3 canned beverages to cool within 60 min. • To cancel this option, press the “Quick Cool” button again. CoolSelect Zone returns to the previous temperature.
  • Page 14 CoolSelect Zone Drawer GUIDE “Select” Button Soft Freeze • When “Soft Freeze” is selected, the temperature on the digital panel displays (-5 C), regardless of the set tem- perature of the refrigerator. • “Soft Freeze” temperature helps keep meat and fish fresh for longer.

  • Page 15: Removing The Freezer Accessories

    REMOVING THE FREEZER ACCESSORIES Glass Shelf Ice Maker Bucket • Remove the bucket by lifting up and pulling out. • Pull the shelf out as far as it goes. Then lift it up and remove it. Front Leg Cover • Open the freezer and refrigerator Door Bin doors, remove three screws and...

  • Page 16: Cleaning The Accessories

    BEVERAGE STATION (On Some Models) To open Beverage Station, push the top portion of Beverage Station until meet clicking sound • It is recommended that you use the • The Beverage Station is convenient and Beverage Station for storing most frequent- reduces energy consumption, because you ly needed foods do not need to open the refrigerator door to...

  • Page 17: Replacing The Interior Light (Only Available On Some Models)

    • You can not use the water and ice dispenser without a water filter cartridge because the water line blocks at the water supply. Ordering replacement filters • To order more water filter cartridges, call 1-800-SAMSUNG and ask for accessory Part # DA29-00003A or contact your authorized Samsung dealer. DOORS The refrigerator doors have a special door opening and closing feature to make sure that they close all the way and are securely sealed.

  • Page 18: Installation Instructions

    INSTALLATION OF THE REFRIGERATOR Checking the Dimensions of your Entrance Door • Check the dimensions of your entrance door to determine whether the refrigerator can pass through it. NOTE • When refrigerator passes in door and depth or width of refrigerator is bigger, removes refrigerator doors.

  • Page 19: Removing The Refrigerator Doors

    REMOVING THE REFRIGERATOR DOORS Removing the Front Leg Cover Open the freezer and refrigerator doors, and then take off the front leg cover by turning the three screws counter-clockwise. FRONT LEG COVER SCREW Separating the Water Supply Line from the Refrigerator ➁...

  • Page 20: Removing The Freezer Door

    REMOVING THE REFRIGERATOR DOORS • Lift the door straight up. • Be careful not to pinch the water tubing and wire harness on the door. NOTE • Place doors on a protected surface. Removing the Freezer Door 1) With the door closed, remove the upper hinge cover (➀) using a screwdriver, and then disconnect the wires (➁).

  • Page 21: Removing The Refrigerator Door

    REMOVING THE REFRIGERATOR DOORS Removing the Refrigerator Door 1) With the door closed, remove the upper hinge cover (➀) using a screwdriver, and then disconnect the wires (➁). 2) Remove hinge screws ( ➂ ) and ground screw ( ➃ ) counter-clockwise, and take off the upper hinge (➄) in the direction of the arrow (➅).

  • Page 22: Reattaching The Refrigerator Doors

    REATTACHING THE REFRIGERATOR DOORS Reattaching the Freezer Door 1) Insert the lower hinge ( ➀ ) in the bracket lower 2) Reattach the freezer door by inserting the hose ( ➂ ) in the lower side of the door into the hole in hinge (➁).

  • Page 23: Reattaching The Refrigerator Door

    REATTACHING THE REFRIGERATOR DOORS Reattaching the Refrigerator Door 1) Insert the lower hinge ( ➀ ) in the bracket lower 2) Place the hole in the refrigerator door (➂) over hinge (➁). the lower hinge (➃). 3) Insert the upper hinge shaft (➄) into the hole (➅). After levelling between the upper hinge hole (➆) and the hole of the cabinet (➇).

  • Page 24: Reattaching The Water Supply Line

    REATTACHING THE REFRIGERATOR DOORS Reattaching the Water Supply Line While pressing the front face of coupler (➁), insert the water line (➀) in the coupler. Push the "A" collar to the "B" body and hold. Tube must be fully inserted to the marked line to avoid leaks.

  • Page 25: Leveling The Refrigerator

    LEVELING THE REFRIGERATOR Make sure the refrigerator is level before adjusting its doors. The doors will be uneven if the refrigerator is not level. The front of refrigerator is adjustable. NOTE Insert a flat-blade screwdriver (-) ( ➀ ) into a slot of Case 1) Freezer door is lower than that of the refrigerator the control lever (➁), turn it clockwise and level the...

  • Page 26: Adjusting The Clearance Between The Doors

    ADJUSTING THE CLEARANCE BETWEEN THE DOORS Adjust Leveling first. NOTE Making small adjustments between doors. If the door of the freezer is lower than that of the If the door of freezer is higher than that of the refrigerator. refrigerator. Adjustment part Adjustment part Please open the doors and adjust them as follows:...

  • Page 27: Checking The Water Dispenser Line

    CHECKING THE WATER DISPENSER LINE 1) In order to operate the ice maker properly, water pressure of 1.4 ~10 is required. In this range a 100 cc paper cup can be filled in 10 secs. 2) The water filter removes particles. It does not sterilize or destroy any micro-organisms. 3) If the refrigerator is installed in an area with low water pressure (below 1.4 ), you should install a booster pump to compensate.

  • Page 28: Installation Of The Water Dispenser Line

    6.5mm of the plastic tubing to make sure you get a snug, leak-free connection. NOTE Before being used, the leakage in these places should be examined. CAUTION - Samsung Warranty does not cover WATER LINE INSTALLATION. - It’ll be done at customer’s charge except the retail price includes installation cost.
  • Page 29 INSTALLATION OF THE WATER DISPENSER LINE Connect the water line to the refrigerator. CONNECTION NUT WATER LINE - Remove the compressor cover of the refrigerator. - Connect the water line to the valve, as shown in the figure. - When connected, check if there is any leakage. If any, repeat the connection.

  • Page 30: Check Amount Of Water

    INSTALLATION OF THE WATER DISPENSER LINE Remove any residual matter inside the water supply line after installing filter. 1) Turn on the main water supply & shut-off the valve of the water supply line. WATER 2) Run water through the dispenser about the first six glassfuls of water.

  • Page 31: Troubleshooting

    TROUBLESHOOTING The refrigerator does not work at all or it does not Ice is not dispensed chill sufficiently • Did you stop the ice making function? • Check that the power plug is properly connected. • Is there any ice in the ice storage unit? •...
  • Page 32 This product and its electronic accessories should not be mixed with other commercial wastes for disposal. Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. In an effort to promote recycling this user manual is printed on recycled paper.
