Summary of Contents for Chauvet Circus
- Page 1 User Manual...
-
Page 2: Table Of Contents
CONTACT US ................................... 20 CHAUVET®, 2010, All Rights Reserved Information and specifications in this User Manual are subject to change without notice. CHAUVET® assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. Author: Anthony Chiappone... -
Page 3: Before You Begin
In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Manual Conventions CHAUVET® manuals use the following conventions to differentiate certain types of information from the regular text. EANING... -
Page 4: Safety Instructions
Safety Instructions Please read these instructions carefully. It includes important information about the installation, usage and maintenance of this product. · Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. ·... -
Page 5: Introduction
2. I NTRODUCTION Product Overview Back Panel Power Out Power In Fuse holder Safety Control Panel (LED Display) DMX In DMX Out 2. Introduction 1/17/2011 6:15 PM... -
Page 6: Setup
3. S ETUP AC Power This fixture is auto-ranging and runs on 100~240 VAC, 50/60 Hz power. To determine the power requirements for a particular fixture, see the label affixed to the back plate of the fixture or refer to the fixture’s specifications chart. A fixture’s listed current rating indicates its average current draw under normal conditions. -
Page 7: Power Linking
This fixture contains power linking via the Edison outlet located in front of the power input cable. Please see the diagram below for further explanation. The maximum quantity of Circus™ fixtures that may be linked is26 units @ 120V, 40 units @ 230V... -
Page 8: Mounting
Mounting Orientation The Circus™ may be mounted in any position, provided there is adequate room for ventilation. Rigging Be sure that the structure can support the weight of the fixture. Please see the “Technical Specifications” section of this manual for a detailed weight listing. Mount the fixture securely. This may be done with a screw, nut and bolt, or a mounting clamp. -
Page 9: Operating Instructions
Strobe rate (off, slow~fast) Configuring the Starting Address The Circus™ fixture uses three DMX channels. In this DMX configuration/personality, the highest configurable address is 510. Any address higher than this will prevent access to all of the channels while in this mode; however, if you desire to use one of the other DMX configurations (personalities), please consider the total DMX channels when selecting a DMX address. -
Page 10: Operation
Operation DMX Operation This operating mode will allow for DMX control. You must set the starting address for this mode. If this is your first time using DMX, then it is recommended that you refer to the “DMX Primer” section in the “Appendix” of this manual. Please see the instructions below for details on this mode. - Page 11 Continued from previous page HANNEL UNCTION ALUE ETTING Run Speed 000 ó 255 0~100% (When running programs) Sound Sensitivity 000 ó 255 0~100% (When in Sound Active Mode) Strobe Speed 000 ó 255 0~100% (Only for programs) 4. Operating Instructions 1/17/2011 6:15 PM...
-
Page 12: Master/Slave Mode (Auto, Sound Active)
Master/Slave Mode (Auto, Sound active) When additional (slave) fixtures are daisy chained to the master, they will all synchronize with the master and run the same lighting show. Please see the instructions below for details on this mode. Master: Place the master fixture first in the daisy chain. Set the master fixture to operate in either automatic or sound-active mode;... -
Page 13: Auto-Configure
Auto-Configure This fixture has 42 built in light shows. In this mode, the fixture will cycle through each of these programs. Please see the instructions below for details on this mode. Plug the fixture into power. Press <MENU> until AUTO appears on the LED screen. Press <ENTER>... -
Page 14: Appendix
#32 · Keep DMX cables separated from · Interference from AC wires power cables or black lights If you still have a problem after trying the above solutions, please contact CHAUVET® Technical Support. 5. Appendix 1/17/2011 6:15 PM... -
Page 15: Dmx Primer
Maximum recommended number of fixtures on a daisy chain: 32 Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET® certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 16: Cable Connectors
Cable Connectors Cabling must have a male XLR connector on one end and a female XLR connector on the other end. DMX connector configuration COMMON DMX + INPUT OUTPUT Terminator To avoid signal transmission problems and interference, it is always advisable to connect a DMX signal terminator. -
Page 17: 3-Pin To 5-Pin Conversion Chart
3-Pin to 5-Pin Conversion Chart If you use a controller with a 5-pin DMX output connector, you will need to use a 5-pin to 3-pin adapter. The chart below details a proper cable conversion: IN TO ONVERSION HART Conductor 3-Pin Female (Output) 5-Pin Male (Input) Ground/Shield Pin 1... -
Page 18: General Maintenance
Package must be clearly labeled with a Return Merchandize Authorization Number (RMA #). Products returned without the RMA # will be refused. Call CHAUVET® and request an RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 19: Technical Specifications
Data input ................... locking 3-pin XLR male socket Data output ................locking 3-pin XLR female socket Data pin configuration..............pin 1 shield, pin 2 (-), pin 3 (+) Protocols ......................DMX-512 USITT DMX Channels .......................... 3 ORDERING INFORMATION Circus™ ........................CIRCUS WARRANTY INFORMATION Warranty....................2-year limited warranty... -
Page 20: Contact Us
Voice .................... 954-929-1115 (Press 4) Fax ................954-929-5560 (Attention: Service) Email ..................tech@chauvetlighting.com World Wide Web ............... http://www.chauvetlighting.com UNITED KINGDOM & IRELAND General Information ................CHAUVET® Europe Ltd Address ........................Unit 1C Brookhill Road Industrial Estate Pinxton, Nottingham, UK NG16 6NT Voice ....................+44 (0)1773 511115 Fax .....................+44 (0)1773 511110...
