Page 1 projector User's Manual Instant big screen movie watching! Powered by:...
Page 3: Table Of Contents
Streaming Projector SPR1000 ™ Intended Use Statement ................6 Safety Information ..................6 Introduction ....................10 Getting Started ..................19 Remote Control ..................31 Connecting to other devices ...............33 Menu .......................40 Troubleshooting ..................44 Product Specification ................49 Accessory List ..................52 Limited Warranty ..................53 Regulatory Notices ..................54 ©...
Page 4: Important Notice
3M™ Streaming Projector SPR1000 Important Notice All statements, technical information, and recommendations related to 3M’s products are based on information believed to be reliable, but the accuracy or completeness is not guaranteed. Before using this product, you must evaluate it and determine if it is suitable for your intended application.
Page 5 Licensing, LLC in the United States and/or other countries. iPad is a trademark of Apple, Inc., registered in the U.S. and other countries. Roku, Roku Streaming Stick, and the Roku logo are registered trademarks of Roku, Inc. DLP and the DLP® logo are trademarks of Texas Instruments.
Page 6: Intended Use Statement
3M™ Streaming Projector SPR1000 Intended Use Statement The 3M™ Streaming Projector is designed to operate with the 3M Power Adapter and an HDMI® or MHL™ enabled device in environments that meet these conditions. • 0° to 35°C (32° to 95°F) •...
Page 7 Streaming Projector SPR1000 ™ Warning To reduce the risk associated with hazardous voltage, fire, explosion, battery leakage or overheating which may cause serious injury or death: • Do not leave the product in a car or in direct sunlight for extended periods of time.
Page 8 3M™ Streaming Projector SPR1000 To reduce the risks associated with hearing loss: • Be sure to read earphone manufacturer's instructions with respect to volume level. • User is responsible to set a safe volume level. To reduce the risk of injury to small children: •...
Page 9 Streaming Projector SPR1000 ™ Caution To reduce the risk associated with environmental disposal hazards which may cause minor or moderate injury: • Dispose of the product and accessories in accordance with the federal, state, local or regional laws which cover the disposal of electrical and electronic waste. To reduce the risks associated with projector LED bright light: •...
Page 10: Introduction
Choose from thousands of movies. • Game on. The 3M™ Streaming Projector is compatible with the Roku® Game Remote for Streaming Stick™ (available late October, sold separately), so you can fling some birds, spin the wheel or question some answers.
Page 11 Roku® Remote Control for Streaming Stick™ (available late October, sold separately), you can use the Roku Streaming Stick™ to watch online entertainment on a MHL enabled TV. Just plug the Roku Streaming Stick™ into your MHL enabled device, and you’re ready to start the show.
Page 12: Package Contents
3M™ Streaming Projector SPR1000 Package Contents The 3M™ Streaming Projector Power By Roku® comes with the following items. If you are missing any of these items please contact 3M. 3M Streaming Projector SPR1000 Roku® Streaming Stick Power Adapter Outlet Adapters (2)
Page 13: Parts Of Projector
Streaming Projector SPR1000 ™ Parts of Projector Front-Top View Button Panel – Turn on and control projector Speaker Air Vent – Do not block the air vents while projector is operating or cooling down. This will cause projector to overheat and automatically turn off. Projection Lens Focus Wheel –...
Page 14 3M™ Streaming Projector SPR1000 Bottom-Rear View Tripod Mount Air Vents – Do not block fans or vents while projector is operating or cooling down. This will cause projector to overheat and automatically turn off. DC Input – Powers the projector or charges the battery using the 3M power supply.
Page 15 Streaming Projector SPR1000 ™ Projector Button Panel Volume Down Button – Turns down speaker or audio out level. Down and Left Arrow for projector menu system. Volume Up Button – Turns up speaker or audio out level. Up and Right Arrow for projector menu system.
Page 16 3M™ Streaming Projector SPR1000 Parts of Roku Streaming Stick HDMI® (MHL™) Connector – Plugs into the 3M™ Streaming Projector. Power LED – Provides power, remote communication and boot up status for the Streaming Stick™. Reset Button – Used to reset the Streaming Stick.
Page 17 Streaming Projector SPR1000 ™ Parts of Remote Control Infrared LED – Transmits remote control commands to projector. Arrow Buttons – Move the selector or cursor in projector menu or the MHL enabled device's screen. Standby – Turns the projector's lamp off or on. OK Button –...
Page 18 3M™ Streaming Projector SPR1000 Rewind – Rewinds video and music during playback. Volume Down – Decreases the audio volume. Lamp ON/OFF – Turns off the projector lamp while keeping projector power on. Menu Button – Press to open the projector menu. Home Button –...
Page 19: Getting Started
Streaming Projector SPR1000 ™ Getting Started In the following section, you will install the Roku® Streaming Stick™ into the projector, charge the projector's battery, and turn on the projector. Roku Streaming Stick The Roku Streaming Stick comes with 3M™ Streaming Projector SPR1000 and plugs into the HDMI/MHL port on the 3M Streaming Projector.
Page 20 3M™ Streaming Projector SPR1000 Power Adapter The power adapter is used to charge the battery or power the projector. There are two outlet adapters. When the power adapter is first shipped, it is fitted with a blank outlet adapter. This must be removed before installing an outlet adapter. Installing an Outlet Adapter Press the "PUSH"...
Page 21 Streaming Projector SPR1000 ™ Select the outlet adapter that will plug into your wall outlet and align to the power adapter. Slide the outlet adapter down until it clicks into place. © 2012 3M. All Rights Reserved.
Page 22: Charging The Battery
3M™ Streaming Projector SPR1000 Charging the Battery The rechargeable battery in the 3M Streaming Projector SPR1000 gives you up to two hours of battery life while in ECO lamp mode. When the battery needs to be charged, the status indicator LED starts flashing red. The battery should be fully charged before using the projector for the first time.
Page 23: Turning The Projector On And Off
MHL-enabled devices such as the Roku Streaming stick receive power from the projector. You can turn off the projector's lamp without turning off the MHL-enabled device using the remote control.
Page 24: Status Indicator Light
3M™ Streaming Projector SPR1000 Turning the Lamp On and Off: You can turn the projector's lamp off without turning the projector off by pressing the lamp button on the remote control. The projector lamp will turn off immediately while the cooling fans continue to run. While the projector's lamp is off, the status indicator remains green.
Page 25: Setting Up The Projector
Streaming Projector SPR1000 ™ Setting up the Projector The projector is quick and easy to set up. You can project the image onto most flat surfaces. This section covers positioning the projector, focusing the image, and adjusting the brightness and contrast settings. Choosing a surface The best surface for the image is a flat, white surface.
Page 26 3M™ Streaming Projector SPR1000 Attaching the Projector to Tripod (Optional Accessory) On the bottom of the projector, you will find a tripod socket (1/4"-20) that fits most standard camera tripods, including the optional 3M tripod (78-6972-0073-7). © 2012 3M. All Rights Reserved.
Page 27: Distance Versus Image Size
™ Distance versus Image Size The 3M Streaming Projector can project an image from 9 inches (22.1 cm) to 105 inches (265.7 cm) wide. As you increase the size of the projected image, you will need to decrease (darken) the ambient room lighting. Refer to the chart for associated dimensions.
Page 28: Adjusting Brightness/Contrast Settings
3M™ Streaming Projector SPR1000 Adjusting the Focus After you find a place for the projector, rotate the focus wheel to sharpen the image. Focus Adjusting the Brightness and Contrast Settings You can use the projector brightness and contrast settings to adjust the image based on the lighting conditions.
Page 29 Streaming Projector SPR1000 ™ Using the Projector Keypad: Press the menu button; press the Info button; press the volume down to decrease the brightness and volume up to increase the brightness. You can exit the menu by pressing the menu button twice. Adjusting Contrast Adjust the contrast setting until details in the bright level of the image appear.
Page 30: Volume Up/Down
3M™ Streaming Projector SPR1000 Volume Up/Down The volume buttons on the projector and the remote control adjust the sound from the speakers or the audio output. Additionally, MHL enabled devices plugged into the projector can adjust the projector volume level using the device's remote. Display Volume Level: Press the volume up or down button to display the volume slider.
Page 31: Remote Control
Streaming Projector SPR1000 ™ Remote Control The 3M remote control controls the projector, the Roku Streaming Stick™, or any other MHL enabled device plugged into the projector. Remove Protective Film Before you can begin using the remote control, you must remove the protective film from the battery compartment.
Page 32: Replacing The Battery In The Remote Control
3M™ Streaming Projector SPR1000 Replacing the Battery in the Remote Control Replace the battery in the remote control with a CR2025 battery. Remove the battery and battery tray by holding the latch toward the center of the tray and then pull latch the tray out of the remote control.
Page 33: Connecting To Other Devices
Streaming Projector SPR1000 ™ Connecting to other devices The 3M Streaming Projector connects to other digital video devices such as tablets, computers, smartphones, and dvd players. Compatible device will most likely have one of the following video output connectors: Description...
Page 34: Connecting To The Projector
3M™ Streaming Projector SPR1000 Notes: 1. Not all devices with a microUSB port are MHL enabled devices. Check the device's specification before purchasing a MHL cable. 2. Some products have proprietary connectors not shown above (such as the dock connector on the Apple iPad or iPhone.) Check for digital video accessory adapters or cables from the manufacturer.
Page 35 D C in Connecting to a MHL Device The 3M Streaming Projector supports MHL through the HDMI port. While playing video and audio from your MHL compatible device, the 3M Streaming Projector charges your device. Additionally, you can control your device using the projector's remote control.
Page 36 3M™ Streaming Projector SPR1000 Notes: 1. MHL cable not included. This cable is also known as a "passive MHL cable". 2. Please reference the device's user manual and specification for compatibility with MHL. © 2012 3M. All Rights Reserved.
Page 37 Streaming Projector SPR1000 ™ Connecting to a HDMI Video Device The 3M Streaming Projector can playback video and audio from a device with HDMI output. Connect one end of the HDMI cable to the projector’s HDMI/MHL input. Connect the other end of the cable to the video device’s HDMI output.
Page 38 3M™ Streaming Projector SPR1000 Connecting to a Display Port® Video Device The 3M Streaming Projector can play video and audio from your Display Port compatible device. You will need a Display Port to HDMI adapter or cable. Connect the DisplayPort to HDMI adapter to the device.
Page 39 Streaming Projector SPR1000 ™ Notes: 1. The DisplayPort adapter and HDMI Cable are not included. 2. Please reference the device's user manual and specification for compatibility with Display Port. © 2012 3M. All Rights Reserved.
Page 40: Menu
3M™ Streaming Projector SPR1000 Menu The projector's menu allows you to adjust the brightness, contrast, lamp power, and picture mode. The following section describes each setting and how to navigate the menu system. Item Menu Item Description Brightness Adjusts the dark levels of the image. Contrast Adjusts the bright levels of the image.
Page 41: Using The Menu
Streaming Projector SPR1000 ™ Item Menu Item Description Image Orientation Changes the image orientation - Normal (Default) - Upside down - Upside down and mirrored - Mirrored Picture Mode Changes the image based on the input type: video or computer. Navigation Help Since the buttons on the projector have multiple purposes, Navigation Help provides a key for the buttons on the projector.
Page 42 3M™ Streaming Projector SPR1000 Return to Menu Item Selection: Press the Menu button or press OK on the remote control. On-Screen Icons One of the following icons will appear when the projector does not detect an input, detects a MHL device but no input, or the video resolution is not supported. - No input detected - video resolution is not supported - A MHL device is detected but the video signal is not...
Page 43: Reset Button
Streaming Projector SPR1000 ™ Reset Button The reset button restarts the projector in the event the projector stops responding. Reset the projector by disconnecting the video input and power, and then press the reset button using an uncoiled paper clip. This will turn off the projector and allow you to turn the projector on again.
Page 44: Troubleshooting
There is a dust cap on the end of the connector. Remove it before inserting it into the projector. • When you insert the stick, make sure the word Roku is facing out. The cover hits the Roku Streaming Stick when I close the cover. •...
Page 45 The projector button panel is on but the projector is not projecting an image. • The video source (such as the Roku Stick) is outputting a black image. First, try removing the Roku Streaming Stick or disconnect the video cable. Do you see the 3M logo screen? If not, try turning off the projector and turning it on again.
Page 46 3M™ Streaming Projector SPR1000 The projector is powered on and the Roku Stick is inserted but the 3M Streaming Projector displays the No Input Detected screen. • You should see a power light on the stick. If you do not, the stick may not be inserted properly.
Page 47 Streaming Projector SPR1000 ™ Focusing the Image The image is blurry. • Use the focus wheel on the side of the projector (next to the lens) to sharpen the image. • Reduce the input resolution. The native resolution of the projector is 480p. Therefore, resolutions greater that 720p may appear blurry.
Page 48 3M™ Streaming Projector SPR1000 • Turn up the volume on the external speakers. • There may be a moment of silence in the show you are watching. Using the Remote Control The remote control does not work. • Remove the plastic film that is in-between the battery and the remote control. •...
Page 49: Product Specification
Streaming Projector SPR1000 ™ Product Specification Description Specification Imager Technology TI DLP Size 0.3" Resolution WVGA 854 x 480 Pixels Aspect Ratio 16:9 Projection Distance 16 5/8 in. – 199 1/4 in. (42.2 – 506 cm) Image Size 10 in. – 120 in. Diagonal (25.4– 304.8 cm) Throw Ratio (Diagonal: Distance) 1:1.66 Lens Offset...
Page 50 3M™ Streaming Projector SPR1000 Description Specification Power Consumption 11.5 Watts (Standard Lamp Mode) 7.0 Watts (Eco Lamp Mode) Battery Specification Description Specification Type Rechargeable Lithium-Ion Battery Rated Capacity 7.4 V, 2600mAh Video and Audio Support The following list shows the resolutions that are supported by the projector. The projector displays a WVGA (854 x 480) image.
Page 51 Streaming Projector SPR1000 ™ Description Resolution Refresh Rate Aspect Ratio (width x height) 720 x 576p 50 Hz 16:9 720p 1280 x 720p 59.94/60 Hz 16:9 1280 x 720p 50 Hz 16:9 1080i 1920 x 1080i 59.94/60 Hz 16:9 1440 x 1080i 50 Hz 16:9 Audio Support...
Page 53: Limited Warranty
Streaming Projector SPR1000 ™ Limited Warranty The 3M™ Streaming Projector (the “3M Product”) is warranted to be free from defects in material or manufacture for a period of 90 days from the date or purchase. If the product does not conform to the warranty within the warranty period, 3M’s exclusive obligation is to repair, replace or refund the purchase price of the non- conforming product.
Page 54: Regulatory Notices
3M™ Streaming Projector SPR1000 Regulatory Notices FCC STATEMENT - CLASS B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 55: Weee Statement
Streaming Projector SPR1000 ™ INSTRUCTIONS TO USERS: This equipment complies with the requirements of FCC equipment provided that the following conditions are met. If the cables include a EMI ferrite core, attach the ferrite core end of the cable to the projector. Use the cables which are included with the projector or specified.
Page 56: Rohs Statement
3M™ Streaming Projector SPR1000 RoHS Statement Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment (known as “RoHS”), 2011/65/EU of the European Parliament and of the Council and the Regulation 1907/2006 (known as “REACH”) relating to “Substances of Very High Concern”...
