Page 1: User Manual
DVL-2455 61 CM (24") FULL HD LED TV WITH INTEGRATED DVD PLAYER, DVB-T AND CI User Manual For information and support, www.lenco.eu UM_DVL-2455_GB V1.0... -
Page 2: Table Of Contents
Table of content What’s in the box? ....................3 Safety Precautions ....................4 IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY BEFORE USE..4 Functional parts ......................7 Top View of the TV ....................7 Front View of the TV ....................7 To turn the TV power ON .................. -
Page 3: What's In The Box
Dear customer, Thank you for purchasing this Lenco product. Quality and usability is our top priority. In order to let you fully enjoy this product, we manufactured this product using high quality standards, materials, components and care. Note: This user manual is printed prior to the product development. When a part of the product specification must be changed to improve operability or other functions, priority is given to the product specification itself. -
Page 4: Safety Precautions
Safety Precautions IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY BEFORE USE. CAUTION RISK OF ELECTRICAL SHOCK DO NOT OPEN CAUTION: TO PREVENT ELECTRICAL SHOCK, DO NOT REMOVE ANY COVER SCREWS. THERE ARE NO USER SERVICEABLE PARTS INSIDE. REQUEST A QUALIFIED SERVICE PERSON TO PERFORM SERVICING. This symbol indicates that there are important operating maintenance instructions in the user manual accompanying this unit. - Page 5 SAFETY PRECAUTIONS (continued) This unit has been produced according to all current safety regulations. The following safety tips should safeguard users against careless use and the dangers connected with such use. Although this unit has been carefully manufactured and rigorously checked before leaving the factory, as with all electrical appliances, it is possible for problems to develop.
- Page 6 Safety instructions – continued Scratched discs If your disc is badly scratched, it will not play. You may be able to repair the disc if you use a disc polisher. Cleaning the Lens If the lens becomes dirty, it may cause a skipping of sound during DVD / CD operation. Clean the lens with a commercially available lens cleaner and blower or carefully wipe it with a soft dry cloth.
-
Page 7: Functional Parts
Functional parts Top View of the TV Front View of the TV 1. V- Button 2. V+ Button 3. CH- Button 4. CH+ Button 5. MENU Button 6. SOURCE Button 7. Standby Button 8. Open/Close 9. Play/Pause 10. Remote sensor 11. -
Page 8: Rear View Of The Tv
Rear view of the TV NOTE: When using external equipment with this TV set, please read the instruction manual of the external equipment. Switch off all power supplies to the equipment and TV set before connection. Always ensure that the input and output terminals are correctly connected. -
Page 9: Remote Control Unit
Remote control unit STANDBY: Switch on TV when at standby mode. AUTO: Press to do auto configuration directly in PC source. MUTE: Press to mute the sound. Press again or press VOL+ to unmute. 0-9: Press 0-9 to select a TV channel directly when you are watching TV. - Page 10 DEL/ RENAME/ MOVE/ SKIP: Navigation buttons in TV mode. OPEN/CLOSE Button: Press OPEN/CLOSE button to load disc on disc tray. Button: Press these button to go to the previous/next chapter(DVD). Button: These buttons allow skipping ahead/back at 5- level speed. Press “PLAY”button to return to normal playback. REPEAT Button: To press this button you can repeatedly play a title(DVD) or all tracks(CD) .
-
Page 11: Tv Mode
TV Mode CHANNEL menu Press [MENU] to display the main menu. Press [◄/►] to select "CHANNEL" in the main menu, then press [▼] to select and [OK] to enter. Auto Tuning: Press [▼] and [OK] to enter AUTO Tuning and press [▲/►/▼/◄] to select a language and press [OK] to start. -
Page 12: Picture Menu
Signal Information (For DTV only): Press [▼] and [OK] to enter "Signal Information" submenu. This menu displays signal details, including Channel, Network,Modulation, Quality and Strength. Picture menu Press [MENU] to display the main menu. Press [◄/►] to select "PICTURE" in the main menu, then press [▼] and [OK] to enter. -
Page 13: Time Menu
Time menu Press [MENU] to display the main menu. Press [◄/►] to select "TIME" in the main menu, then press [▼] and [OK] to enter. Clock (For DTV only): Display the current system time. It’s not available. Time Zone (For DTV only): Press [►] or [OK] to enter "Time Zone"... -
Page 14: Av/Scart/Ypbpr/Pc
language. Hearing Impaired (For DTV only): Press [►] or [OK] to set the hearing impaired to "On" or "Off". Restore Factory Default: Press [▲/▼] button to select Restore Factory Default, then press [OK] button to enter a dialogue.Press [◄] button selecting Yes to restore factory default by choosing OSD language,country and conducting Channel Tuning . -
Page 15: Troubleshooting
1.Press buttons to select submenu and change it in General setup page 2.Use the same way to change other submenu in AUDIO and Preference. Troubleshooting Before calling for service, you can check the following items on symptoms and solutions. No picture: Check other channel, maybe station problem. -
Page 16: Service And Support
Service and support Lenco has written this user manual with the utmost care. If you still have difficulties using this product after you have read user manual than you can contact us via www.lenco.eu or by phone: Lenco helpdesk: Germany... -
Page 17: Personal Notes
SCART CVBS & RGB PC-IN Earphone input 0.2-2.0Vrms CVBS L/R RCA input 0.2-2.0Vrms Component Speaker output 2x2.5W THD+N<10% Power In DC +12V 4A Power ON 26W, Standby <1W consumption Screen size 15.4" Resolution Up to 1280x800 Panel Luminance 200 cd/m² Contrast ratio 400:1 Viewing angle... -
Page 18: End Of Life
End of life This symbol indicates that the relevant electrical product or battery should not be disposed of as general household waste in Europe. To ensure the correct waste treatment of the product and battery, please dispose them in accordance to any applicable local laws of requirement for disposal of electrical equipment or batteries.
