2012 05+ Mustang (197)
Supplement, 1st Printing
USA (fus)

Table of Contents

10
11
11
12
12
13
14
14
14
15
19
19
23
24
30
30
31
35
3
3
4
5
1

Advertisement

Table of Contents
loading

Related Manuals for Ford 05+ Mustang 2012

Summary of Contents for Ford 05+ Mustang 2012

  • Page 1: Table Of Contents

    Table of Contents Introduction Welcome Breaking-in your vehicle Shelby GT500 Unique Features Driving your Shelby GT500 AdvanceTrac Driving through water Ground clearance Washing your vehicle Chassis Wheels and Tires Wheels Wheel lug nut torque Tire information Roadside Emergencies Wrecker towing Maintenance Engine oil Air filter(s)
  • Page 2 Errors and omissions excepted. © Ford Motor Company 2012 2012 05+ Mustang (197) Supplement, 1st Printing...

  • Page 3: Introduction

    WELCOME Congratulations on your decision to purchase or lease the latest from Ford SVT — the Shelby GT500. If you’ve owned or leased an SVT product in the past, we’re glad you’re back. If this is your first SVT vehicle, welcome to the SVT family! We are confident that our dedication...

  • Page 4: Breaking-In Your Vehicle

    Introduction SVT HISTORY The Ford Special Vehicle Team (SVT) was established in 1991 to “Polish the Ford Oval” by creating low-volume, factory-produced vehicles designed for those select few whose idea of driving is a high-powered, passionate experience — not just a means of getting from point A to point B.

  • Page 5: Shelby Gt500 Unique Features

    Shelby GT500 Unique Features • 5.4L DOHC 32V Supercharged V-8 engine with intercooler — 550 horsepower @ 6,200 rpm, 510 lb-ft torque @ 4,250 rpm SAE certified • Low-restriction, cold air intake system • SVT tuned 2.75” exhaust system with 4-inch tips •...
  • Page 6 Shelby GT500 Unique Features • Unique front fascia, rear fascia, aerodynamically tuned front splitter, fog lamps, hood with functional air extractors and rear decklid spoiler • Limited slip rear differential w/ 3.55 rear axle ratio (3.73 rear axle ratio included on the optional performance package) •...
  • Page 7 Shelby GT500 Unique Features SHELBY GT500 INSTRUMENT CLUSTER Upshift Illuminates when it is best to shift to the next highest manual transmission gear to maximize fuel economy. Multi-shift indicators: (Upshift): Set for maximum fuel economy 2. SVT: Performance shift indicator Performance shift indicator Your vehicle is equipped with a programmable performance shift indicator.
  • Page 8 Shelby GT500 Unique Features To use the performance shift indicator feature, first bring the vehicle to a complete stop then use the message center controls as follows: Note: The vehicle’s headlamps or park lamps must be on to perform/check light functions. 1.
  • Page 9 Shelby GT500 Unique Features Unique instrument cluster lighting Your vehicle is equipped with a unique instrument cluster color display. You can select R-W-B which will illuminate the speedometer in red, the Fuel/Boost/Temp/Oil pressure gauges in white and the tachometer in blue.

  • Page 10: Driving Your Shelby Gt500

    Driving your Shelby GT500 MANUAL 6-SPEED TRANSMISSION OPERATION Using the Clutch The manual transmission has a starter interlock that prevents cranking the engine unless the clutch pedal is fully depressed. To start the vehicle: 1. Make sure the parking brake is fully set. 2.

  • Page 11: Advancetrac

    AdvanceTrac system is still enabled. DRIVING YOUR SHELBY GT500 THROUGH WATER The Ford Shelby GT500 has aerodynamic devices attached to the underbody designed to help control airflow for superior performance. Therefore, the driver must be especially careful to avoid driving through deep or standing water.

  • Page 12: Ground Clearance

    Driving your Shelby GT500 GROUND CLEARANCE Because of low vehicle ground clearance, use caution when approaching curbs/curb stops from the front and rear as vehicle damage will occur. Additionally, when crossing speed bumps or driveway curbs, SVT recommends approaching at a 45 degree angle to reduce the risk of vehicle damage.

  • Page 13: Chassis

    Chassis SUSPENSION • MacPherson strut with L-arm front suspension • 8.8 inch solid rear axle with limited slip differential (3.55:1 ratio standard, 3.73:1 ratio optional)) Coupe stabilizer bars: • 33.2 x 5.0 mm tubular front stabilizer bar • 23.0 mm standard, 24.0 mm optional solid rear bar •...

  • Page 14: Wheels And Tires

    Wheels and Tires WHEELS Your SVT vehicle is equipped with unique wheels matched to the tires. These wheels are more susceptible to damage due to their diameter, width and low profile tires. To avoid damage to your wheels: • Maintain proper tire pressure (see Tires in this supplement). •...

  • Page 15: Tire Information

    • The Shelby GT500 original equipment tires are optimized for performance in both wet and dry conditions. Ford does not recommend using the original equipment tires when temperatures drop to approximately 40°F (5°C) or below (depending on tire wear and environmental conditions) or in snow/ice conditions.
  • Page 16 Wheels and Tires • The Shelby GT500 optional P265/40-19 front, P285/35-20 rear directional tires were designed for track use and may exhibit significantly reduced tread life and increased tire noise compared to the standard equipment tires under normal driving conditions. Increasing the front camber settings beyond the factory settings may further accelerate tread wear and induce tire noise.
  • Page 17 Do not apply heat or blow heated air directly on the tires. Always inspect the tires after storage periods and before use as outlined in the owner’s guide. Ford does not recommend using these high performance summer tires when temperatures drop to approximately 40°F (5°C) or below, or in snow/ice...
  • Page 18 Never perform high speed driving with winter tires. Please call the Ford Performance Info Center at 1-800-FORD-SVT (367-3788) for specific winter tire recommendations. Tire rotation Because your vehicle is equipped with unique larger tires on the rear wheels, you can only rotate the tires side to side.

  • Page 19: Roadside Emergencies

    When towing with a flatbed, 4x4 blocks must be used when loading/unloading your vehicle. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. Note: If the vehicle is towed by other means or incorrectly, vehicle damage may occur.
  • Page 20 Roadside Emergencies Transportation Instructions When towing the vehicle, make sure that you use two mini J hooks and attach them to the crossmember oblong holes as shown. Other methods may damage the vehicle. 2012 05+ Mustang (197) Supplement, 1st Printing USA (fus)
  • Page 21 Roadside Emergencies Wheel Lift When towing the Shelby GT500, for front loading, the front tires must be 16 in. (41 cm) higher than the rear. Rear lift towing is not recommended, as vehicle damage may occur. 2012 05+ Mustang (197) Supplement, 1st Printing USA (fus)
  • Page 22 Roadside Emergencies Flatbed The diagram below illustrates the maximum ramp angle allowable to load your vehicle on a flatbed. Vehicle damage may occur with greater angles. 1. 36 in. (91 cm) 4x4 loading block 2. 18 in. (45.72 cm) 4x4 loading block 3.

  • Page 23: Maintenance

    Maintenance 5.4L DOHC SUPERCHARGED V8 ENGINE 1. Battery 2. Supercharger 3. Engine oil dipstick 4. Brake fluid reservoir 5. Air filter assembly 6. Intercooler coolant reservoir 7. Engine coolant reservoir 8. Engine oil filler cap 9. Windshield washer reservoir 10. Power distribution box 2012 05+ Mustang (197) Supplement, 1st Printing USA (fus)

  • Page 24: Engine Oil

    ENGINE OIL RECOMMENDATION Use Motorcraft SAE 5W-50 full synthetic or an equivalent SAE 5W-50 full synthetic oil meeting Ford specification WSS-M2C931-B. Do not use supplemental engine oil additives, cleaners or other engine treatments. They are unnecessary and could lead to engine damage that is not covered by Ford warranty.
  • Page 25 Maintenance 5. Locate and carefully remove the engine oil level dipstick. 6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again. • If the oil level is between the lower and upper holes, the oil level is acceptable. DO NOT ADD OIL.
  • Page 26 Maintenance When the engine is cold, check the level of the engine coolant in the reservoir. Fill your engine coolant reservoir as outlined in Adding engine coolant in this section. • The coolant should be at the “cold fill range” as listed on the engine coolant reservoir and intercooler coolant reservoir.
  • Page 27 Maintenance Adding coolant When adding coolant, make sure it is a 50/50 mixture of coolant and distilled water. Add the mixture to the coolant reservoir, when the engine is cool, until the appropriate fill level is obtained. WARNING: Do not add coolant when the engine is hot. Steam and scalding liquids released from a hot cooling system can burn you badly.
  • Page 28 Maintenance WARNING: To reduce the risk of personal injury, make sure the engine is cool before unscrewing the coolant pressure relief cap. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. If you must remove the pressure relief cap or radiator cap (depending upon engine application), follow these steps to avoid personal injury: 1.
  • Page 29 Maintenance After any coolant has been added, check the coolant concentration (refer to the Maintenance and Specifications chapter of your Owner’s Guide). If the concentration is not 50/50 (protection to –34°F/–36°C), drain some coolant and adjust the concentration. It may take several drains and additions to obtain a 50/50 coolant concentration.

  • Page 30: Air Filter(S)

    Maintenance AIR FILTER Refer to scheduled maintenance information for the appropriate intervals for changing the air filter element. When changing the air filter element, use only the Motorcraft air filter element listed. Refer to Motorcraft part numbers in this chapter. WARNING: To reduce the risk of vehicle damage and/or personal burn injuries do not start your engine with the air cleaner removed and do not remove it while the engine is running.

  • Page 31: Refill Capacities

    Maintenance 2012 05+ Mustang (197) Supplement, 1st Printing USA (fus)
  • Page 32 Maintenance 2012 05+ Mustang (197) Supplement, 1st Printing USA (fus)
  • Page 33 Maintenance USING THE RIGHT BULBS Function Trade Number Park lamp, turn lamp, side marker (front) 3156K Luggage compartment lamp S211 Fog lamp PS24N DRIVETRAIN Item Description Rear axle 8.8 in. solid rear axle with limited-slip differential 3.55:1 ratio 3.73:1 ratio (Optional Performance Package) Driveshaft 2-piece steel Transmission...
  • Page 34 Maintenance ENGINE INFORMATION Item Description Configuration Longitudinally mounted, 90-degree V8, cast aluminum cylinder block and cylinder heads Bore x Stroke 90.2 x 105.8 mm (3.55 x 4.165 in.) Displacement 5410 cc/330 cid Compression ratio 8.4:1 Horsepower 550 horsepower @ 6200 rpm Torque 510 lb-ft torque @ 4250 rpm 6250 rpm fuel shut-off...

  • Page 35: Warranty Coverage

    Ford dealer nationwide. SVT does not recommend modifying or racing SVT vehicles, as they are designed and built to be driven as delivered from the factory. The Ford Motor Company Warranty Guide discusses vehicle usage and the installation of aftermarket parts and their effect on warranty coverage.

  • Page 36: Scheduled Maintenance Guide

    Ford Motor Company has recommended maintenance intervals for various parts and component systems based upon engineering testing. Ford Motor Company relies upon this testing to determine the most appropriate mileage for replacement of oils and fluids to protect your vehicle at the lowest overall cost to you and recommends against maintenance schedules that deviate from the scheduled maintenance information.
  • Page 37 Please consult your Warranty Guide for complete warranty information. Chemicals or additives not approved by Ford are not required for factory recommended maintenance. In fact, Ford Motor Company recommends against the use of such additive products unless specifically recommended by Ford for a particular application.
  • Page 38 Scheduled Maintenance Guide Value Shopping for Your Vehicle’s Maintenance Needs Your dealership recognizes the competitive landscape of maintenance and light repair automotive services. With factory-trained technicians, and one-stop service from routine maintenance like oil changes and tire rotations to repairs like brake service, check out the value your dealers can offer.
  • Page 39 In order to keep your vehicle running right, it is important to have the systems on your vehicle checked regularly. This can help identify potential issues and prevent major problems. Ford Motor Company recommends the following multi-point inspection be performed at every scheduled maintenance interval to help make sure your vehicle keeps running great.
  • Page 40 Scheduled Maintenance Guide 2012 05+ Mustang (197) Supplement, 1st Printing USA (fus)
  • Page 41 Scheduled Maintenance Guide 2012 05+ Mustang (197) Supplement, 1st Printing USA (fus)
  • Page 42 Scheduled Maintenance Guide 2012 05+ Mustang (197) Supplement, 1st Printing USA (fus)
  • Page 43 Scheduled Maintenance Guide Every 15,000 miles Replace cabin air filter (if equipped) (24,000 km) Every 30,000 miles Replace engine air filter (48,000 km) Replace fuel filter Every 45,000 miles Replace spark plugs (72,000 km) Every 105,000 miles Change engine coolant (168,000 km) Inspect accessory drive belt(s) Every 150,000 miles...
  • Page 44 Scheduled Maintenance Guide Maintenance Schedule Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#:...
  • Page 45 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...
  • Page 46 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...

  • Page 47: Special Operating Conditions

    Scheduled Maintenance Guide SPECIAL OPERATING CONDITIONS If you operate your vehicle primarily in any of the following conditions, you need to perform additional maintenance as indicated. If you occasionally operate your vehicle under any of these conditions, it is not necessary to perform the additional maintenance. For specific recommendations, see your dealership service advisor or technician.
  • Page 48 Scheduled Maintenance Guide Special Operating Condition Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#:...
  • Page 49 Scheduled Maintenance Guide EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS ILEAGE ILEAGE EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#: OURS OURS...
  • Page 50 ❑ Rear axles and power take-off (PTO) units containing synthetic fluid and light duty trucks equipped with Ford-design axles are lubricated for life. These fluids are not to be checked or changed unless a leak is suspected, service is required or the axle assembly has been submerged in water.

  • Page 51: Engine Coolant Change Log

    Scheduled Maintenance Guide ENGINE COOLANT CHANGE RECORD Initial change Six years or 105,000 miles (168,000 km) (whichever comes first) After initial change Every three years or 45,000 miles (72,000 km) Engine Coolant Change Log EALER ALIDATION EALER ALIDATION P&A C P&A C RO#: RO#:...
