Electric and Gas Dryer

PRODUCT FEATURES

" OUTSTANDING PERFORMANCE
Besides the large capacity, you can benefit from faster drying time, quiet
operation, and energy efficiency.
" STAINLESS STEEL DRUM
Stainless steel drum resists rust.
" DIGITAL FABRIC CARE
Multi-Level temperature control takes better care of your clothes.
" EASE OF USE
An entire selection of user-friendly functions make operating the dryer
easier.
" ONE TOUCH SELECTIONS
To choose an option, press its button once. No need to press buttons multiple times to scroll through a list
of options.
Your dryer provides sensor drying and time drying programs.
Sensor Dry
The dryer senses the dampness of the laundry and automatically determines the heat level and operation
time. You might see a sudden increase or decrease in operation time if the sensor determines more or less
drying is required. This is not a malfunction.
Time Dry
Use TIME DRY to select heat level and drying time manually. This can be used if clothes are not as dry as
you like them at the end of the cycle. Use TIME DRY for heavy and bulky items and thick work.
A NOTE TO YOU
Thank you for purchasing a DAEWOO Dryer.
Please read this manual carefully, as it provides instructions
on safe installation, use, and maintenance
Record the model and serial numbers,and retain the manual for future reference.
For more information, please visit our website at http://www.e-daewoo.com
DWR-WE5413WC/SC/RC
DWR-WE6413WC/SC/RC
What are Sensor Dry and Time Dry?
CONTACT INFORMATION
Website : http://www.e-daewoo.com
Call : 1-877-393-7823(1-877-DWESVC3)

Advertisement

Table of Contents
loading

Related Manuals for Daewoo DWR-WE5413WC

Summary of Contents for Daewoo DWR-WE5413WC

  • Page 1: Product Features

    Thank you for purchasing a DAEWOO Dryer. Please read this manual carefully, as it provides instructions on safe installation, use, and maintenance Record the model and serial numbers,and retain the manual for future reference. For more information, please visit our website at http://www.e-daewoo.com...
  • Page 2 The warranty information for your dryer is located at the end of this manual. Warranty Service is available by contacting the nearest DAEWOO Service Center. If this product is installed and operated according to the instructions in this manual, DAEWOO will repair or replace any parts defective in material or workmanship throughout the warranty period, beginning with the date of purchase.

  • Page 3: Table Of Contents

    PART 6. GAS REQUIREMENTS AND INSTRUCTIONS ................25 PART 7. USER - MAINTENANCE INSTRUCTIONS ...................26 PART 8. OPERATING YOUR DRYER ......................28 PART 9. TROUBLESHOOTING GUIDE.......................35 DAEWOO DRYER LIMITED WARRANTY....................39 SPECIFICATIONS PART 1 Type : Electric and Gas Dryer Rating : Please refer to the rating label regarding detailed information.

  • Page 4: Important Safety Instructions

    11) Do not touch the steam nozzle in the drum during or after the STEAM cycle. NOTE: Because of continuing product improvements, Daewoo reserves the right to change specifications without notice. For complete details, see the Installation Instructions packed with your product before...

  • Page 5: Grounding Instructions

    [GROUNDING INSTRUCTIONS] A. For a grounded, cord-connected appliance: This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This appliance must be equipped with a cord having an equipment-grounding conductor and a grounding plug.
  • Page 6 WARNING! To reduce the risk of fire or explosion, electric shock, property damage, personal injury or death when using this appliance, please follow all instructions and information, including those in this manual and instructions provided by your gas supplier. • Do not store or use any gasoline, dry-cleaning solvents other flammable vapors or liquids in the area surrounding this appliance.

  • Page 7: Part 2. Initial Steps For Installing Your Dryer

    INITIAL STEPS FOR INSTALLING YOUR DRYER PART 2 The following instructions will guide you through the initial steps of setting up your dryer. Please note that every section of this manual provides important information regarding the preparation and use of your dryer, and it is important that you review this entire manual before proceeding with any installation or use.
  • Page 8 Minimum clearances on above, behind, and sides of the unit, as shown below, are required. Those required minimum clearances are set forth in the picture below. Please keep the following instructions in mind when installing in a closet or recessed area: •...
  • Page 9 Installation nstructions Open in position, adjust the leveling legs of the dryer until it is level from left to right and front to back. Be sure to tighten the leveling leg lock nuts against the bottom of the dryer. The leveling legs must remain firmly on the floor and the dryer should not rock.
  • Page 10 STEP 2. Connecting the Exhaust System WARNING! • To reduce the risk of fire this appliance MUST BE EXHAUSTED OUTDOORS. • The appliance shall not be exhausted into a chimney, a wall, a ceiling, an attic, a crawl space, or a concealed space of a building.

  • Page 11: Alternate Exhaust Directions

    ALTERNATE EXHAUST DIRECTIONS 1. Remove screw and exhaust duct. 2-1. Detach and remove the knockout that 2-2. Reconnect the new duct[8.66 inch(22cm)] matches the desired venting direction to the blower housing, and fixing the duct to the base. (Right side not available on Gas Dryers) 3-1.
  • Page 12 STEP 3. Connection of Gas Supply (Gas dryer only). In addition to the following, please refer to manual section on Gas Requirements and Instructions. 1. New stainless steel flexible connector. Use this type of connector only if allowed by local codes. Use Design AGA Certified Connector.
  • Page 13 STEP 4. Electrical Plug Connections Following steps are several warnings and instructions concerning making the electrical connection for electric dryers. More detailed information concerning the electrical connection is provided in the manual section entitled Electrical Requirements for Electric Dryer. It is important that you thoroughly review that section and the remainder of this manual, before taking any steps to install or use this dryer.
  • Page 14 STEP 5. Preparation of the Dryer Prior to the first use of this appliance, use all purpose cleaning products or a solution of detergent and water, with damp cloth to remove from the inside of the dryer drum/drying compartment any dust or dirt that may have accumulated inside the dryer.
  • Page 15 STEP 8. Procedure for Reversing the Door The door on your dryer can be installed to open either to the left or the right. Follow these instructions to reverse the direction in which your door opens: Note : Door and latch should be aligned at the center when closed. STEP 9.
  • Page 16 STEP10. Connecting the inlet water hose for steam features Caution! The dryer must be connected to the cold water faucet using the new inlet hose. Do not use old hoses Do not overtighten, as it may damage the coupling. 1. Before installing dryer turn the cold water faucet off. 2.

  • Page 17: Part 3 Accessories Installation

    ACCESSORIES INSTALLATION PART 3 Stacking Kit Installation Instructions(DRYER & PEDESTAL) To ensure safe and secure installation, please observe the instructions below. WARNING! Incorrect Installation can cause serious accidents. The weight of the dryer and the height of installation makes the stacking procedure too risky for one person. This procedure should be performed by 2 or more experienced service personnel.

  • Page 18: Part 4. Electrical Requirements For Electric Dryer

    ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYERS PART 4 The following are additional instructions regarding electrical connections and requirements for electric dryers. Important Warning To help prevent fire, electric shock, serious injury or death, the wiring and grounding must conform to the latest edition of the National Electrical Code, ANSI/NFPA 70 and all applicable local regulations.
  • Page 19 Review the following options to determine the appropriate electrical connection for your home: Use the instructions in this section if your home has a Use the instructions in this section if your home has a 4-wire receptacle (NEMA type 14-30R) and you will be 3-wire receptacle (NEMA type 10-30R) and you will be using a UL listed, 120/240 volt minimum, 30 amp, using a UL listed, 120/240 volt minimum, 30 amp,...

  • Page 20: Wire Connection : Direct Wire

    4-wire connection : Direct wire Important : Grounding through the neutral conductor is prohibited for (1) new branch-circuit installations, (2) mobile homes, (3) recreational vehicles, and (4) areas where local codes prohibit grounding through the neutral conductor. Prepare minimum 5 ft (1.52 m) of length in order for dryer to be replaced.
  • Page 21 3-wire connection : Direct wire Important : Grounding through the neutral conductor is prohibited for (1) new branch-circuit installations, (2) mobile homes, (3) recreational vehicles, and (4) areas where local codes prohibit grounding through the neutral conductor. Prepare minimum 5 ft (1.52 m) of length in order for dryer to be replaced.
  • Page 22 Option 1: 4-wire connection with a power supply cord. • lf your local codes or ordinances do not allow the use of a 3-wire connection, or you are installing your dryer in a mobile home, you must use a 4-wire connection. 1.
  • Page 23 Option 2: 3-Wire connection with a power supply cord. lf your local codes or ordinances permit the connection of a frame-grounding conductor to the neutral wire, use these instructions. If your local codes or ordinances do not allow the connection of a frame-grounding conductor to the neutral wire, use the instructions under Section 1: Optional 3- wire connection.

  • Page 24: Part 5. Electrical Requirements For Gas Dryers

    ELECTRICAL REQUIREMENTS FOR GAS DRYERS PART 5 120 Volt, 60 Hertz, with 3-Prong Grounding Plug Following are additional instructions regarding electrical connections and requirements for gas dryers. Important Warning To help prevent fire, electric shock, serious injury or death, the wiring and grounding must conform to the latest edition of the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1, and all applicable local regulations.

  • Page 25: Part 6 Gas Requirements And Instructions

    GAS REQUIREMENTS AND INSTRUCTIONS PART 6 Following are important instructions and information concerning the requirements for the gas supply and service for gas dryers. Important Warning The gas supply and service for a gas dryer must comply with all local codes and ordinances. In the absence of any local codes or ordinances in your area, the gas supply and service for your gas dryer must comply with the latest edition of the National Fuel Gas Code, ANSI Z223.1/NFPA 54.

  • Page 26: Part 7. User - Maintenance Instructions

    USER-MAINTENANCE INSTRUCTIONS PART 7 Following are important instructions and information concerning the exhaust requirements for your dryer. Important Warning To reduce the risk of fire, electric shock, or injury to person, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance. To reduce the risk of fire, combustion, or accumulation of combustible gases, DO NOT exhaust dryer air into an enclosed and unventilated area, such as an attic, wall, ceiling, crawl space, chimney, gas vent, or concealed space of a building.
  • Page 27 Exhaust and Dryer Maintenance WARNING! Disconnect the dryer’s electric power prior to any cleaning or maintenance. 1. After one year of use, the interior and complete exhaust system of the dryer should be examined and cleaned if necessary. 2. Before one year of use, when drying performance has become unsatisfactory, please examine and clean the exhaust duct for better drying performance.

  • Page 28: Part 8. Operating Your Dryer

    OPERATING YOUR DRYER PART 8 Following are instructions for starting and using your new dryer. Please refer to specific sections of this manual for more detailed information. Important Warning: To reduce the risk of fire, electric shock, or injury to person, read this entire manual, including the Important Safety Instructions.
  • Page 29 Select cycles designed for option Custom Anti damp dry Time Dry MoreTime LessTime Rack Dry Level Program Crease beep Perm Press Bulky Delicate Towel Normal Speed Dry Steam Spray Air Dry Iron dry Gym Shoes * When the course is set on reduce static, the cooling time will turn to 30 sec. A.
  • Page 30 Power Button Speed Dry • Use this button for power on or off. Use for small loads or loads that need less drying time. Cycle Selection Air Dry • Turn the knob to select the desired cycle based Use the Air Dry Modifier for items that require drying on laundry types and conditions.

  • Page 31: Reduce Static

    Mist More Time Less Time Time Change Button Option Buttons More Time More Time • Press MORE TIME or LESS TIME until the desired drying (1) CUSTOM PROGRAM Less Time Less Time time is set. Set up your favorite combination of settings and save them here for one touch NOTE: Time change button is available only recall.
  • Page 32 Rack Dry Anti-Crease Mist Reduce Static (5) Damp Dry Beep Suggested Items Temperature Suggested for Rack Drying Setting Time* When you select the damp (Minutes) dry beep option, a beep will More Time alert you when your load is Washable wool items just damp enough for ironing or pressing.

  • Page 33: Starting Your Dryer

    • Check to see that coverings are securely stitched. Starting your dryer • Shake and fluff pillows by hand periodically during the cycle. 1 Before use • Dry item completely. Foam rubber pillows are slow • Clean lint screen before or after each cycle. to dry.
  • Page 34 4 To use a manual dry cycle 5 Pausing or restarting • Select a Manual Dry Cycle. • To pause the dryer at any time:Open the door or • Press MORE TIME or LESS TIME until the desired press START/PAUSE. drying time is displayed.

  • Page 35: Part 9. Troubleshooting Guide

    TROUBLESHOOTING GUIDE PART 9 Save time and money! Review the charts on the following pages first and you may not need to call for service. 1. Problem: My Dryer Won’t Start Question What to Do • Is the dryer plugged in? Confirm that the dryer’s plug is securely and completely pushed into the laundry room’s power outlet.
  • Page 36 5. Problem: There Is Lint On My Clothes Question What to Do • Is your lint filter full? Please refer to the manual section on cleaning the lint filter, and please confirm that the lint filter is clean. It is important that the lint filter is clean before each new load of laundry.
  • Page 37 9. Problem: It Takes Too Long For My Clothes To Dry Question What to Do • Did you properly sort your loads of Separate heavy weight items from light weight items when creating laundry? loads. • Are you drying large loads of heavy Heavy fabrics take longer to dry because they tend to retain more fabrics? moisture.
  • Page 38 12. Problem: If the steam has something wrong Question What to Do • Water drips from nozzle when steam This is the condensation of water. Dripping water will be stopped in cycle starts. the short time. • Steam doesn’t generate but no error Check if the cord of dryer is connected.

  • Page 39: Daewoo Dryer Limited Warranty

    DAEWOO DRYER LIMITED WARRANTY - USA Your DAEWOO will be will repaired or replaced, at DAEWOO's option, if it proves to be defective in material or workmanship under normal use, during the warranty period ("Warranty Period") set forth below, effective from the date ("Date of Purchase") of original consumer purchase of the product.
  • Page 40 V V I I S S I I O O N N C C R R E E A A T T I I V V E E , , I I N N C C . . 서울 종로구 통의동 6번지 이룸빌딩 4층 담 당 전은일 님 브 랜 드 DAEWOO 언 어 영 어 B. MODEL DWR-WE5413WC/SC/RC DWR-WE6413WC/SC/RC M O D E L 미주향 DRYER MANUAL 일 정 1차 2차 3차 4차 제 판...
