Model No. HRSY54370
Serial No.
(Write the serial number in the space
above for reference.)
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you have
questions, or find there are miss-
ing or damaged parts, we will
guarantee you complete satisfac-
tion through direct assistance
from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
Patent Pending
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
USER'S MANUAL
for future reference.
Advertisement
Related Manuals for Healthrider HRSY54370
Summary of Contents for Healthrider HRSY54370
- Page 1 ¨ Model No. HRSY54370 Serial No. (Write the serial number in the space above for reference.) Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or find there are miss-...
-
Page 2: Table Of Contents
Remove the EXPLODED DRAWING/PART LIST and the PART IDENTIFICATION CHART before beginning assembly. HealthRider is a registered trademark of HealthRider Corp., a subsidiary of ICON Health & Fitness, Inc. ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase. -
Page 3: Important Precautions
3. If you feel pain or dizziness at any time while exercising, stop immediately and begin cool- ing down. 4. Use the home gym system only on a level surface. Cover the floor or carpet beneath the home gym system for protection. -
Page 4: Before You Begin
Mountain Time (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is HRSY54370. The serial number can be found on a decal attached to the HealthRider cover of this manual). -
Page 5: Assembly
ASSEMBLY Before beginning assembly, carefully read the following information and instructions: ¥ Place all parts of the home gym system in a cleared area and remove the packing materials; do not dispose of the packing materials until assembly is completed. - Page 6 2. Press four 2Ó Square Inner Caps (68) into the Frame (2). Identify the Left Wheel Channel (3) and the Right Wheel Channel (4) by comparing the welded brackets on the bottom of each Wheel Channel. Slide the Left Wheel Channel (3) onto the indicated Small Wheels (40) attached to the Frame (2).
- Page 7 4. Slide the Support Tube (32) onto the Base (1). Attach the Support Tube to the Base with two 3/8Ó x 2Ó Bolts (43) and two 3/8Ó Nylon Locknuts (39). Do not tighten the Nylon Locknuts yet. 5. Attach the Support Tube (32) to the Right Wheel Channel (4) with two 3/8Ó...
- Page 8 7. Lubricate the 1/2Ó x 3 1/2Ó Carriage Bolt (49). Attach the Lift Tube (11) to the Frame (2) with the Carriage Bolt and a 1/2Ó Nylon Jam Nut (50). 8. Attach the Platform Cover (34) and the Crossbar (18) to the Frame (2) with two 3/8Ó x 2 3/4Ó Bolts (45) and two 3/8Ó...
- Page 9 11. Press a 1Ó Round Inner Cap (36) into one of the Press Arms (6). Press a 1 3/4Ó Square Inner Cap (65) into the Press Arm. Repeat this step for the other Press Arm (6). 12. Identify the Right Butterfly Arm (15) and the Left Butterfly Arm (14).
- Page 10 14. Cut the plastic zip tie (not shown) from the Cable (35). Be careful not to damage the Cable. Pull on the Cable (35) until you have enough slack to route the Cable around the Pulley (41) attached to the Right Butterfly Arm (15). Tighten the 3/8Ó x 2Ó...
- Page 11 ADJUSTMENT, beginning on page 12 of this manual. Before using the home gym system, pull the cable a few times to be sure that it moves smoothly over the pulleys. If the cable does not move smoothly, find and correct the problem. IMPORTANT: If the cable is not properly installed, it may be damaged when a high resistance setting is used.
-
Page 12: Adjustment
ADJUSTMENT The instructions below describe how each part of the home gym system can be adjusted. Refer to the exercise guide accompanying this manual to see how the home gym system should be set up for each exercise. IMPOR- TANT: When attaching the lat bar or nylon strap, make sure that the attachments are in the correct start- ing position for the exercise to be performed. - Page 13 ATTACHING THE LAT BAR, ROW BAR, OR NYLON STRAP TO THE LOW PULLEY STATION Attach the Lat Bar (21) to the Cable (35) with a Cable Clip (38). For some exercises, the Chain (37) should be attached between the Lat Bar and the Cable with two Cable Clips.
-
Page 14: Trouble-Shooting And Maintenance
TROUBLE-SHOOTING AND MAINTENANCE Inspect and tighten all parts each time you use the home gym system. Replace any worn parts immediately. The home gym system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. -
Page 15: Cable Diagrams
The cable diagram below shows the proper routing of the Cable (35). Use this diagram to be sure that the Cable has been assembled correctly. The starting and ending points have been labeled. The numbers show the proper route for the Cable. IMPORTANT: If the Cable has not been correctly routed, the HealthRider ¨... - Page 16 1/4" Washer (55) 3/8" Washer (46) 1/4" Nylon Locknut (54) 3/8" Nylon Jam Nut (74) 3/8" Nylon Locknut (39) 1/2" Nylon Jam Nut (50) 1/4" x 2 3/4" Bolt (63) 3/8" x 2 1/2" Carriage Bolt (60) 3/8" x 2 1/2" Bolt (51) 1/2"...
- Page 17 1/4" x 2 1/2" Carriage Bolt (57) 3/8" x 2" Bolt (43) 1/4" x 3/4" Bolt (56) 3/8" x 1" Bolt (16) 1" Square Inner Cap (64) 3/4" Tap Screw (62) 3/4" Round Outer Cap (69) 1 3/4" Square Inner Cap (65) 3/4"...
- Page 18 PART LISTÑModel No. HRSY54370 Key No. Qty. Description Base Frame Left Wheel Channel Right Wheel Channel Press Frame Press Arm Name Plate Platform Dial Knob Inner Dial Tube Lift Tube Leg Lever Seat Frame Left Butterfly Arm Right Butterfly Arm 3/8Ó...
- Page 19 EXPLODED DRAWINGÑModel No. HRSY54370 R1197A...
-
Page 20: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information: 1. The MODEL NUMBER of the product (HRSY54370). 2. The NAME of the product (HealthRider ¨...
