Escort SmartSite Owner's Manual

Specifications and Service
SPECIFICATIONS
Monitor
LCD profile widescreen ratio .............................................. 16:9 (4.3")
View angle (U/D/L/R) ........................................................ 50/70/70/70
Resolution ................................................................ 480 x 3 (RGB) x 272
Brightness (cd/m2) ............................................................................... 400
Contrast ratio ....................................................................................... 500:1
Response time (ms) (at 25°C) ............................................................... 15
Power requirement .............................................................. 12V/24V DC
Power consumption ........................................................................... ≤5W
Operating temperature range ...................................... -20°C to 70°C
Storage temperature range ...........................................-30°C to 80°C
Dimensions (mm) .......................................... 280 (L) x 91 (W) x 30 (D)
Weight (approx.) (gm) .................................580 (including bracket)
Camera
Image sensor: ..................CMD Digital-Clarity Active Pixel Image
Video system: ....................................................................................... NTSC
Resolution: ...............................................................................480 TV Line
View angle: ............................................................................... 160 degree
Working voltage: ...................................................................... 9–16 V DC
Waterproof
Accessories
5m Y cable
Silicon tape
SERVICE
Do not attempt to service the unit yourself, as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
To obtain service: Contact ESCORT (800-543-
1608) to obtain a Return Authorization Number.
Properly pack your product and include: your
name, complete return address, written
description of the problem with your product,
daytime telephone number, and a copy of the
original purchase receipt. Label the outside of
the package clearly with your Return
Authorization number. Ship the product prepaid
(insured, for your protection) to: ESCORT Inc.,
5440 West Chester Road, West Chester, OH
45069.
Out-of-warranty repairs:
For out-of-warranty repairs, include prepayment
in the amount you were quoted by the ESCORT
Customer Service Representative. If your
SmartSite has been damaged, abused, or
modified, the repair cost will be calculated on a
parts-and-labor basis. If it exceeds the basic
repair charge, you will be contacted with an
estimate. If the additional payment is not
received within 30 days (or if you notify us that
you do not wish to have your SmartSite repaired
at the price quoted), the unit will be returned
without repair. Payment can be made by check,
money order, or credit card.
ESCORT Inc.
5440 West Chester Road
West Chester OH 45069
800.433.3487
www.EscortInc.com
©2011 ESCORT Inc. ESCORT® and SmartSite™ are trademarks
of ESCORT Inc.
Features, specifications and prices subject to change
without notice.
Warranty
ESCORT One-Year Limited Warranty
What this warranty covers: ESCORT warrants
your product against all defects in materials and
workmanship.
For how long: One (1) year from the date of the
original purchase
What we will do: ESCORT, at our discretion, will
either repair or replace your product free of
charge.
What we will not do: ESCORT will not pay
shipping charges that you incur for sending your
product to us.
What you must do to maintain this
warranty: Show original proof of purchase
from an authorized ESCORT dealer.
Warranty exclusions: Warranty does not apply
to your product under any of the following
conditions:
The serial number has been removed or
modified.
Your product has been subjected to misuse or
damage (including water damage, physical
abuse, and/or improper installation).
Your product has been modified in any way.
Your receipt or proof of purchase is from a non-
authorized dealer or Internet auction site,
including E-bay, U-bid, or other non-authorized
resellers.
You are not the original purchaser of the
product from an authorized dealer or did not
receive it as a gift from the original purchaser of
product from an authorized dealer.
FCC ID: S20711281303-EF. This equipment has
been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of
the FCC rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in
a commercial environment.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with this user
manual, may cause harmful interference to radio,
in which case, the user will be required to correct
the interference at their own expense.
Any changes or modifications in construction
of this device that are not expressly approved by
the party responsible for compliance could void
the user's authority to operate the equipment.
4
