- Page 1 DSL-100D for PPPoE DSL-100D for PPPoE PCI ADSL Modem PCI ADSL Modem Quick Install Guide Quick Install Guide...
-
Page 2: Quick Install Guide
POWER OFF your computer. Disconnect its power, and remove its case. (Follow your PC manufacturer's instructions to prevent damage or injury.) Place the DSL-100D into an available PCI slot. DSL-100D Driver Installation DSL-100D Driver Installation Replace the cover and POWER ON your computer. - Page 3 DSL-100D Driver Installation DSL-100D Driver Installation continued At this screen, make sure that “Search for the best driver for your device...” is selected. Click Next At this window, check “Specify a location.” Click Browse Windows OS RFC 1483(MPoA) RFC 1577(IPoA)
- Page 4 Match your OS with the correct RFC series (as shown in the table on the previous page) to select the proper drivers for the DSL-100D modem. Then select the proper folder in the “Browse for Folder” screen, as shown below.
- Page 5 DSL-100D Driver Installation DSL-100D Driver Installation continued Click Next Click Next The computer will now install and build the drivers information database. If this screen appears, place your Windows Operating System CD into your CD drive. Click OK...
- Page 6 DSL-100D Driver Installation DSL-100D Driver Installation continued Click Finish Click Yes and the computer will restart automatical- DSL-100D Modem Configuration DSL-100D Modem Configuration Right click on the icon, circled here, located in the lower right hand corner of your computer screen, in the systray box.
- Page 7 DSL-100D Modem Configuration DSL-100D Modem Configuration continued Select Configuration When this screen appears, make sure that the ADSL Service Provider is selected. Click on “PVC Table,” to edit the connection type.
- Page 8 Manually Setting up Dial-Up Networks Manually Setting up Dial-Up Networks Go to START>PRO- GRAMS>COMMUNI- CATIONS>DIAL-UP NETWORKING Double Click on “Make New Connection.” Make sure that “D-Link DSL-100D ADSL Modem” is selected in the “Select a device” menu. Click Next...
- Page 9 Setting up Dial-Up Networks Setting up Dial-Up Networks continued continued Enter “0” in the tele- phone number section. Click Next Click Finish...
- Page 10 Logging On Logging On Enter User name and Password. Click Connect You can now access the Internet using your DSL-100D ADSL modem!
