HP Compaq nw8440 Quickspecs

HP Compaq nw8440 Quickspecs

Mobile workstation
Hide thumbs Also See for Compaq nw8440:

Advertisement

Quick Links

Download this manual See also: Maintenance and Service Manual, User Manual
QuickSpecs
Overview
1.
Volume Mute Button with LED
2.
Volume Down Button
3.
Volume Up Button
4.
Serial Port
5.
Stereo Speakers
6.
Integrated Optical Drive
7.
2 USB 2.0 Ports
8.
Microphone Jack
9.
Integrated Microphone
10. Headphone Jack
11. Biometric Fingerprint Sensor (optional)
12. Pointstick
DA - 12449 North America — Version 17 — July 16, 2007
HP Compaq nw8440 Mobile Workstation
HP recommends
Windows Vista
13. Pointstick Buttons
14. Touchpad with scroll zone
15. Touchpad Buttons
16. Hard Drive Activity LED
17. Battery Charging LED
18. Power/Standby LED
19. Wireless On/Off LED
20. Power Button with LED
21. HP Info Center Button
22. Wireless On/Off Button with LED
23. Presentation Mode Button
24. Ambient Light Sensor
®
Business
Page 1

Advertisement

loading

Related Manuals for HP Compaq nw8440

Summary of Contents for HP Compaq nw8440

  • Page 1 QuickSpecs HP Compaq nw8440 Mobile Workstation Overview HP recommends ® Windows Vista Business Volume Mute Button with LED 13. Pointstick Buttons Volume Down Button 14. Touchpad with scroll zone Volume Up Button 15. Touchpad Buttons Serial Port 16. Hard Drive Activity LED Stereo Speakers 17.
  • Page 2 QuickSpecs HP Compaq nw8440 Mobile Workstation Overview Kensington Lock Slot PC Card Slot RJ-45 Port (NIC) SD Media Slot RJ-11 Port (Modem) Integrated Smart Card Reader S-Video TV Out 10. PC Card Eject Button IEEE 1394a Port 11. VGA/External Monitor Port USB 2.0 Port...

  • Page 3: Standard Features

    QuickSpecs HP Compaq nw8440 Mobile Workstation Standard Features Processors Intel Core 2 Duo Processor T7600 (2.33-GHz, 667-MHz FSB, 4-MB L2 cache)* Intel Core 2 Duo Processor T7400 (2.16-GHz, 667-MHz FSB, 4-MB L2 cache)* Intel Core 2 Duo Processor T7200 (2.0-GHz, 667-MHz FSB, 4-MB L2 cache)* Intel Core 2 Duo Processor T5600 (1.83-GHz, 667-MHz FSB, 2-MB L2 cache)*...
  • Page 4 Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots. NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
  • Page 5 19-mm x 19-mm key pitch (center-to-center spacing), 2.5-mm stroke, comfort-dished keycaps, and bright key legends for improved visibility in low light conditions. One-Touch Productivity Provide one-touch access to the following features: Wireless On/Off, HP Info, Presentation, Volume down, Volume up, and Volume Mute. Buttons Pointing Device Dual pointing devices –...
  • Page 6 QuickSpecs HP Compaq nw8440 Mobile Workstation Standard Features Storage Hard Drives 60-, 80-, 100-, 120-GB 5400 rpm SMART SATA 80-, 100-GB 7200 rpm SMART SATA NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles. Up to 8 GB is reserved for the system recovery software.
  • Page 7 QuickSpecs HP Compaq nw8440 Mobile Workstation Standard Features Software Preinstalled Software Adobe Acrobat Reader HP Backup and Recovery Manager Microsoft Windows XP HP Help and Support Center HP Mobile Print Driver HP ProtectTools Security Manager: BIOS Configuration for HP ProtectTools...
  • Page 8 Schlumberger/Petrel HP Backup and Recovery Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager can provide data and system file protection for HP business PCs to enable fast recovery if the system becomes Manager corrupted or if important information is accidentally deleted.
  • Page 9 Russia. Optional Features Biometric Fingerprint Sensor For more information on HP security solutions refer to http://www.hp.com/go/security. Power Supply External 90-watt AC adapter, 6-foot (1.8-meter) power cord included. Total length including External AC adapter is 12 feet (3.66 meter).
  • Page 10 ** HP Advanced Docking Station only Service and Support HP Services includes a three-year standard parts and labor on-site warranty and toll-free 7 x 24 hardware technical phone support. Warranty upgrades are also available. NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

  • Page 11: Warranty

    ADI1981HD High Definition CODEC, Line out/headphone and microphone jacks Communications 56K Fax/Modem, Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC) with HP Smart Power NIC Technology Integrated Wireless Intel Pro/Wireless 802.11 a/b/g Integrated Security TPM 1.2 Embedded Security Chip...
  • Page 12 Audio ADI1981HD High Definition CODEC, Line out/headphone and microphone jacks Communications 56K Fax/Modem, Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC) with HP Smart Power NIC Technology Integrated Wireless Intel Pro/Wireless 802.11 a/b/g Integrated Bluetooth Integrated Security TPM 1.2 Embedded Security Chip...
  • Page 13 ADI1981HD High Definition CODEC, Line out/headphone and microphone jacks Communications 56K Fax/Modem, Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC) with HP Smart Power NIC Technology Integrated Wireless Intel Pro/Wireless 802.11 a/b/g Integrated Security TPM 1.2 Embedded Security Chip...
  • Page 14 Audio ADI1981HD High Definition CODEC, Line out/headphone and microphone jacks Communications 56K Fax/Modem, Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC) with HP Smart Power NIC Technology Integrated Wireless Intel Pro/Wireless 802.11 a/b/g Integrated Bluetooth Integrated Security TPM 1.2 Embedded Security Chip...
  • Page 15 Other Storage 80-GB 5400 rpm Primary SATA Hard Drive ET354AA DVD+/-RW Double Layer Drive with LightScribe Upgrade (Available July 2006) ET353AA HP USB Digital Drive + 256-MB Secure Digital Card DL702AA HP USB Diskette Drive DC361B Communications Intel PRO/Wireless 3945ABG 802.11 a/b/g WLAN option kit...
  • Page 16 QuickSpecs HP Compaq nw8440 Mobile Workstation Options Carrying Cases HP Entry Value Case DL617A HP Top Load Nylon Case DC915A HP Executive Leather case PA847A HP Sport Backpack DG102A Security HP PCMCIA Smart Card Reader DC350B HP/Kensington Cable Lock PC766A...
  • Page 17 NOTE: This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
  • Page 18 QuickSpecs HP Compaq nw8440 Mobile Workstation Storage Removable Media Drive Support Quantity Supported Drive Bay LightScribe DVD+/-RW Drive with Fixed optical drive bay Double Layer DVD+/-RW SuperMulti Drive with Fixed optical drive bay Double Layer Drive DVD/CD-RW Combo Drive Fixed optical drive bay...

  • Page 19: Technical Specifications

    QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications System Unit Dimensions (HxWxD) 1.1 in (at front) x 14.1 in x 10.2 in 28 mm (at front) x 358 mm x 259 mm Weight 5.95 lb (2.7 kg) NOTE: Height varies depending upon where on the notebook the measurement is made. Weight includes 8-cell battery, 60-GB hard drive, 512-MB memory, 802.11 wireless communications module, and TPM...
  • Page 20 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications UKRSERTCOMPUTER HP 90W Smart AC Adapter Dimensions 5.24 x 2.28 x 1.1 in (13.3 x 5.8 x 2.9 cm) Weight 0.86 lb (390 g) Input 100 to 240 VAC Input Efficiency 83% min at 115 VAC...
  • Page 21 System ON 3 to 5 hours (depending on system power consumption) HP Fast Charge Technology Charges the battery up to 90% within 90 minutes when system is OFF Fuel Gauge When pressed, LEDs light indicating level of charge remaining on battery...
  • Page 22 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications 15.4-inch Color TFT Dimensions (W x H) 13.0 x 8.1 in (33.1 x 20.7 cm) WUXGA Wide Viewing Diagonal Size 15.4 in (39.1 cm) Angle Display Surface Treatment Anti-glare Contrast Ratio 300:1 (typical)
  • Page 23 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications 100-GB 7200 rpm SATA Drive Weight 0.25 lb (113 g) Capacity 100 GB Height 0.37 in (9.5 mm) Width 2.75 in (70 mm) Interface ATA-7 / SATA 1.0a Transfer Rate Synchronous (maximum)
  • Page 24 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications 120-GB 5400 rpm SATA Drive Weight 0.25 lb (113 g) Capacity 120 GB Height 0.37 in (9.5 mm) Width 2.75 in (70 mm) Interface ATA-7 / SATA 1.0a Transfer Rate Synchronous (maximum)
  • Page 25 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications 80-GB 5400 rpm SATA Drive Weight 0.22 lb (101 g) Capacity 80 GB Height 0.37 in (9.5 mm) Width 2.75 in (70 mm) Interface ATA-7 / SATA 1.0a Transfer Rate Synchronous (maximum)
  • Page 26 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications DVD/CD-RW Combo Drive Access Times Random <110 ms CD <130 ms DVD Max Data Transfer Rate 24X CD-ROM 3,600 KB/s 8X DVD 10,800 KB/s 24X CD-R 3,600 KB/s 24X CD-RW 3,600 KB/s...
  • Page 27 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications DVD+/-RW SuperMulti Access Times Random <175 ms CD Drive with Double Layer <230 ms DVD Max Data Transfer Rate 24X CD-ROM 3,600 KB/s 8X DVD 10,800 KB/s 24X CD-R 3,600 KB/s 16X CD-RW...
  • Page 28 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications Hardware Implementation ADI1981HD High Definition CODEC Volume Controls Up, down, and mute buttons Full Duplex Sound Blaster Pro compatible Microphone Jack Stereo or mono Headphone/Line Out Jack Stereo Audio Output Quality Frequency Response 20 Hz –...
  • Page 29 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications clause 30)) Comprehensive diagnostic and configuration software suite Cable Analyzer Interface PCI Express x1 NIC Device Driver Name Broadcom NetXtreme Gigabit Ethernet Drivers Available Microsoft Windows XP Microsoft Windows 2000 V.92 56K Data/Fax Modem Form Factor MDC 1.5 Daughtercard...
  • Page 30 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications Data compression: +DS, +DR V.251 Broadcom 4311BG Wireless LAN Standards IEEE 802.11b IEEE 802.11g 802.11b/g WiFi Adapter Interoperability Wi-Fi certified Cisco Compatible Extensions Program compliant (details at www.hp.com/go/notebooks/WLAN) Frequency Band 2.4 GHz Data Rates 802.11b: 1, 2, 5.5, 11 Mbps...
  • Page 31 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications Dimensions 0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm) Operating Voltage 3.3v +/- 10% Temperature Operating 32° to 176° F (0° to 80° C) Non-operating -40° to 176° F (-40° to 80° C)

  • Page 32: Configuration Utility

    QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications Roaming IEEE 802.11 compliant roaming between access points Output Power (for CKK) 17.5 dBm Output Power (for OFDM; 15 dBm power varies by data rate) Power Consumption Transmit: 2.0 W (max) Receive: 1.5 W (max)
  • Page 33 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications IEEE 802.11b 3945ABG 802.11a/b/g IEEE 802.11g Network Connection Interoperability Wi-Fi certified Cisco Compatible Extensions Program compliant (details at www.hp.com/go/notebooks/WLAN) Frequency Band 2.4 GHz and 5 GHz Data Rates 802.11b: 1, 2, 5.5, 11 Mbps 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps...
  • Page 34 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications Temperature Operating 32° to 176° F (0° to 80° C) Non-operating -40° to 176° F (-40° to 80° C) Humidity Operating 10% to 90% (non-condensing) Non-operating 5% to 95% (non-condensing) Altitude Operating...
  • Page 35 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications Security Full support of Bluetooth Security Provisions Power Management Microsoft Windows ACPI, and USB Bus Support Self configurable to optimize power conservation in all operating modes, including Standby, Hold, Park, and Sniff...
  • Page 36 QuickSpecs HP Compaq nw8440 Mobile Workstation Technical Specifications Environmental Data Eco-Label Certifications This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks: US Energy Star...

  • Page 37: Additional Information

    This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive – 2002/95/EC. This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive – 2002/96/EC. Keyboard complies with ISO standard: ISO 9995, EN 29241-4, and ISO/IEC 15412 Input devices of this product comply with ISO 9241, part 9.
  • Page 38 Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards. Material Usage This product does not contain any of the following substances in excess of regulatory limits (for reference of these limits please refer to the HP General Specification of the Environment http://www.hp.com/hpinfo/globalcitizenship/environment/ supplychain/gen_specifications.html):...
  • Page 39 HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
