Page 1: Parts Manual
Parts Manual RZ4216 / 966455801 Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. - Page 2 When you need spare parts or support in service questions, warranty issues, etc., please consult the following professional: This Parts Manual belongs to the machine with the Engine Transmission manufacturing number: Manufacturing Number The machine’s manufacturing number can be found on the printed plate affixed to the engine compartment.
-
Page 3: Table Of Contents
CONTENTS CHASSIS / FRAME ..........4 WHEELS / TIRES ........... 14 ENGINE PLATE ............6 BRAKE / DECK LIFT ..........16 STEERING ............... 8 MOWER DECK / CUTTING DECK ......18 IGNITION ..............10 SEAT ..............20 HYDRAULIC PUMP / MOTOR ....... 12 DECALS .............. -
Page 4: Chassis / Frame
FRAME... - Page 5 FRAME ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 525 454702 ..1 ..FRAME TUBE, LH 21.. 574 356002 ..1 ..FOOT REST 525 454902 ..1 ..FRAME TUBE, RH 22.. 539 102587 ..8 ..GROMMET, BUMPER 574 356402 ..1 ..SEAT SUPPORT, REAR 23..
-
Page 6: Engine Plate
ENGINE PLATE Torque to 55-75 ft-lbs... - Page 7 ENGINE PLATE ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 532 120616 ..3 ..HHFS -16 x 1 THD FRM 11.. 539 115270 ..1 ..BUSHING, METAL 539 112899 ..2 ..NUT -18 FLANGE NYLOC 12.. 574 355802 ..1 ..PLATE, ENGINE 539 976937 ..1 ..
-
Page 8: Steering
STEERING... - Page 9 STEERING ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 539 120899 ..2 ..GRIP 14.. 539 990209 ..2 ..HCS -18 x 1 539 120160 ..2 ..LEVER, UPPER 15.. 539 990316 ..2 ..RHSNB -18 x ¾ 539 117949 ..1 ..
-
Page 10: Ignition
IGNITION 23 26... - Page 11 IGNITION ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 525 594701 ..1 ..FENDER, RH 21.. 539 121486 ..1 ..HOSE, ¼ x 2 525 594702 ..1 ..FENDER, LH 22.. 539 990580 ..2 ..HCS ¼-20 x ¾ 539 101080 ..4 ..
-
Page 12: Hydraulic Pump / Motor
HYDRAULIC PUMP / MOTOR... - Page 13 HYDRAULIC PUMP / MOTOR ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 539 112899 .. 10 ..NUT -18 FLANGE NYLOC 11.. 539 116689 ..2 ..ROD END COUPLER 539 120152 ..1 ..HYDRO, RH 12.. 539 991073 ..
-
Page 14: Wheels / Tires
WHEELS / TIRES 17 18... - Page 15 WHEELS / TIRES ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 539 110333 ..2 ..CASTER TIRE ASSY 13.. 539 112660 ..2 ..BEARING, FLANGED 539 103300 ..2 ..ZERK 14.. 539 115566 ..2 ..HHB -18 x 1 NYLOC 539 102484 ..4 ..
-
Page 16: Brake / Deck Lift
BRAKE / DECK LIFT 10 11... - Page 17 BRAKE / DECK LIFT ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 525 580402 ..1 ..HANDLE, LIFT 15.. 539 101224 ..2 ..SPRING 574 356802 ..1 ..SHAFT, LIFT 16.. 539 990188 ..6 ..WASHER SAE FLAT 525 580201 ..2 ..
-
Page 18: Mower Deck / Cutting Deck
MOWER DECK / CUTTING DECK... - Page 19 MOWER DECK / CUTTING DECK ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 575 699801 ..1 ..DECK w/ SAFETY DECALS 26.. 539 416405 ..1 ..QUICK CONNECT 532 195185 ..2 ..SUSPENSION ARM, REAR 27.. 532 199092 ..2 ..SPACER RETAINER 532 193003 ..2 ..
-
Page 20: Seat
SEAT... - Page 21 SEAT ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 539 112899 ..2 ..NUT -18 FLANGE NYLOC 532 197661 ..1 ..HANDLE, SEAT SLIDE 574 356302 ..1 ..PLATE, SEAT 532 198200 ..1 ..SPRING, SEAT SLIDE 539 132140 ..1 ..SWITCH, SEAT N/C 532 424068 ..1 ..
-
Page 22: Decals
DECALS... - Page 23 DESCRIPTION 510 240201 ..1 ..DECAL, BELT ROUTING 12.. 574 754301 ..1 ..DECAL, CONTROL PANEL 532 422012 ..2 ..DECAL, HUSQVARNA 13.. 525 814201 ..1 ..DECAL, DECK HEIGHT 539 109908 ..1 ..DECAL, SAFETY WARNING 14.. 525 814301 ..1 ..
- Page 24 P/N 115 161026 R1 11/16/09...
