- Page 1 GAS HOBS ZGG 642 ZGG 6420 INSTRUCTION BOOKLET Please read this instruction booklet before using the appliance...
-
Page 2: Important Safety Information
Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 727727 Installation Service This hob should only be repaired or serviced by an • This appliance must be installed and serviced by a authorised Service Engineer and only genuine competent person as stated in the Gas Safety... -
Page 3: Table Of Contents
Contents For the User Keep this instruction book for future reference Important Safety Information and ensure it is passed on to any new owner. Description of the Hob Operation Maintenance and Cleaning Guide to Use the instructions Something Not Working? Service and Spare Parts The following symbols will be found in the text to guide you throughout the Instructions:... -
Page 4: Operation
If the control knobs become difficult to turn, please contact your local Zanussi Service Centre. Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. -
Page 5: Something Not Working
For Customer Service in the Republic of Ireland please contact us at the address below: Zanussi-Electrolux Electrolux Group (Irl) Ltd Long Mile Road Dublin 12 Republic of Ireland Tel: +353 (0) 1 4090 751 Email: service.eid@electrolux.ie... -
Page 6: Guarantee Conditions
Zanussi guarantee conditions * Appliances found to be in use within a commercial We, Zanussi, undertake that if, within 12 months of the or similar environment, plus those which are the date of the purchase, this Zanussi appliance or any subject to rental agreements. -
Page 7: Engineers Technical Data
Instructions for the Installer Engineers technical data Semi-rapid Burner OVERALL DIMENSIONS Heat Input 1.9 kW (6483 BTU/HR) Width: 580 mm. Rapid Burner Depth: 510 mm. Heat Input 2.9 kW Natural Gas (9895 BTU/HR) 2.7 kW L.P.G. (9212 BTU/HR) CUT OUT DIMENSIONS Width: 550 mm. -
Page 8: Important Safety Requirements
Important safety requirements This hob must be installed in accordance with the Gas For appliances installed in the Republic of Ireland Safety (Installation and Use) Regulations (Current please refer to the NSAI- Domestic Gas Installation I.S. Edition) and the IEE Wiring Regulations (Current 813 Current Editions Table Four. -
Page 9: Installation
Installation IMPORTANT This hob must be installed by a competent and qualified person only. The manufacturer will not accept liability, should the above instructions or any of the other safety instructions incorporated in this book be ignored. Gas Connection Connection to the gas supply should be with either rigid or semi-rigid pipe, i.e. -
Page 10: Building In
Building In Building over a kitchen unit with Building over a cupboard or door drawer Proper arrangements must be taken in designing the If the hob is to be installed above a cupboard or drawer furniture unit, in order to avoid any contact with the it will be necessary to fit a heat resistant board below bottom of the hob which can be heated when it is the base of the hob on the underside of the work surface. -
Page 11: Electrical Connections
Electrical connections Permanent Connection Any electrical work required to install this hob should be carried out by a qualified electrician or In the case of a permanent connection, it is necessary competent person, in accordance with the current that you install a double pole switch between the hob regulations. -
Page 12: Wiring Diagram
Wiring Diagram 220/240 A. IGNITOR SWITCH Brown B. IGNITOR UNIT Fault Finding Preliminary Electrical Systems SOCKET PLUG (with cover (face view) removed) Check Earth Wire Green/Yellow Blue Green START Yellow Isolate appliance and carry out: A: Earth Continuity Neutral Wire Blue check. - Page 13 Ignition System / Gas Ignition Check gas supply at Ignitor does not spark burner Check plug top fuse Light burner manually and replace if necessary Check polarity and Check by pass simmer earth continuity of adjusted supply point Check position of the Check earth continuity electrode of appliance...
-
Page 14: Commissioning
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. Turn the gas tap to the MAX position and ignite. Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times. -
Page 16: Customer Care
CUSTOMER CARE Zanussi-Electrolux Cornwall House 55-77 High Street Slough Berkshire SL1 1DZ 08705 727727 (*) © Electrolux plc 2004 From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
