- Page 1 Wi-Fi® Camera with Night Vision NETCAM User Manual F7D7601V2 • 8820ed01175uk Rev. B00...
-
Page 2: Table Of Contents
Troubleshooting, Support, and Warranty . . . . . . . . . . . . . . . . . . . 28 Belkin International, Inc ., Limited 2-Year Product Warranty . . . . . . . . . 30 How to get service . -
Page 3: Getting Started
GeTTiNG STarTed Initial Setup Congratulations on buying a Belkin NetCam. This device will enable you to easily check in on your home and your loved ones when you are away. To get started, you will need: What’s in the Box Your wireless router, its network name (SSID), and password. -
Page 4: Set Up Your Camera Wirelessly Through Your Mobile Devices
GeTTiNG STarTed Set Up Your Camera Wirelessly 2. Switch the NetCam to Setup Mode by flipping up the switch on the back Through Your Mobile Devices of the camera Please make sure the switch is in setup mode and the Wi-Fi light is blinking. 1. - Page 5 GeTTiNG STarTed 3. Download the NetCam App from the App Store or Google Play 4. Set Up on iPhone, iPad, or iPod touch 4.1 Connect your mobile device to NetCam Wi-Fi signal Go to “Settings > Wi-Fi” on your iPhone/iPad/iPod touch and connect to the camera’s Wi-Fi signal.
- Page 6 GeTTiNG STarTed 4.2 Launch the NetCam App 4.3 Camera Setup Click “Continue” to begin setup. Once your device establishes a connection with the camera, launch the NetCam App. You should see a pop-up message like the one below. Click “Yes” to set up your camera.
- Page 7 GeTTiNG STarTed 4.4 Camera Preview 4.5 Connect to Internet The camera will show you a preview after successfully connecting to Choose your Wi-Fi network to connect to the Internet. your device. You may also choose to connect to your network via Ethernet cable Click “Connect Camera to Internet.”...
- Page 8 GeTTiNG STarTed 4.6 Connect to Internet Please wait for the camera to establish connection with the Internet. Enter your Wi-Fi password if you have a security-enabled network.
- Page 9 GeTTiNG STarTed 4.7 Create an Account 4.8 Use Existing Account If this is your first time setting up your camera, you will need to create If you have an existing account, select “Use Existing” and then enter an account. your account information. Click “Sign in.”...
- Page 10 GeTTiNG STarTed 4.9 Set Up Camera Info Click “Continue.” It will take a few seconds to register the camera with the server. Create the camera name and its description.
- Page 11 GeTTiNG STarTed 4.10 Setup Complete Congratulations Please flip the setup switch down on the back of the NetCam. Click “Finish” to complete the setup.
- Page 12 GeTTiNG STarTed 5. Set Up on Android Devices 5.2 Launch NetCam App! 5.1 Connect your device to NetCam Wi-Fi signal Once your device establishes a connection with the camera, launch the NetCam App. You should see a pop-up message like the one below. Go to “Settings >...
- Page 13 GeTTiNG STarTed 5.3 Camera Setup 5.4 Camera Preview Click “Continue” to begin setup. The camera will show you a preview after successfully connecting to your device. Click “Connect camera to Internet.”...
- Page 14 GeTTiNG STarTed 5.5 Connect to the Internet 5.6 Connect to Internet Choose your Wi-Fi network to connect to the Internet. Enter your Wi-Fi password if you have a security-enabled network. You may also choose to connect to your network via Ethernet cable (not included) by clicking “Ethernet.”...
- Page 15 GeTTiNG STarTed Please wait for the camera to establish an Internet connection. 5.7 Create an Account If this is your first time setting up your camera, you will need to create an account.
- Page 16 GeTTiNG STarTed 5.8 Use Existing Accounts 5.9 Set Up Camera Info If you have an existing account, select “Use Existing” and then enter Create the camera name and its description. your account information. Click “Sign in.”...
- Page 17 GeTTiNG STarTed Click “Continue.” It will take a few seconds to register the camera with 5.10 Setup Complete the server. Please flip the setup switch down on the back of the NetCam. Click “Finish” to complete the setup.
- Page 18 GeTTiNG STarTed Congratulations!
- Page 19 GeTTiNG STarTed 1/8 in. or 5.5mm 2.5mm 6. Mounting Your Camera (optional) Attach screws to wall and hang plate onto screws. Unscrew camera post from the base and remove weight.
- Page 20 GeTTiNG STarTed Align base with plate and screw on camera post.
-
Page 21: Getting To Know Your Wi-Fi Camera
GETTING TO KNOW YOUR WI-FI CAMERA Front Panel A: Brightness sensor B: Camera sensor C: IR LED D: Microphone... -
Page 22: Back Panel
GETTING TO KNOW YOUR Wi-Fi CAMERA B: Network Green: Connected to server Amber: Connected to local area network only Flashing Amber: Not connected to any network Flashing Green: Connected to network, ready to set up C: Power Green: Power On D: RJ45 port: Can be used for wired setup and for a wired connection with the router while using the NetCam. -
Page 23: Technical Details
Technical DeTails Software Features and Specifications Web App • Live camera viewing • L ive audio on selected PC web browsers (Internet Explorer®, Firefox®, and Google Chrome™) App on iOS or Android • Camera settings - Camera setup • Camera firmware upgrade - Live camera viewing • Delete camera - Save snapshot and video from the live stream • Invite friends to view your camera - Live one-way audio • E nable/disable email alert... -
Page 24: Main Window
Technical DeTails Configure Camera Camera Configuration Main Window Name: Name of your camera Share/unshare: Make your camera public to your friends or not. Status: Change camera status to be online, offline, or private. Rotation: Select Normal or Flipped Vertically on the videos. IR: Select “Auto,”... -
Page 25: Camera Viewer
Technical DeTails Take a Record Enable Microphone Snapshot Video Camera Viewer... -
Page 26: Protection
Technical DeTails Web Browser Protection Access this link via Internet Explorer, Netscape, Firefox, To protect your security against a hacker, a pop- or Google Chrome: http://www.belkin.com/netcam up message will alert you if someone else is logged into your account at the same time as you. Then you can view the camera via your PC. -
Page 27: Hardware Features And Specifications
Technical DeTails Hardware Features and Specifications Camera Support VGA and 0.3MP Still Image Capture resolution JPEG still capture Image Sensor VGA 1/4 inch CMOS sensor Adjust image size and quality Video Features Lens Focal length: 3.1mm, F2.6 Flip and mirror image View Angle Horizontal: 64° Audio Vertical: 48° Built-in microphone, -38 dB ± 2 dB Audio In Diagonal: 80° G.711, PCM Audio Compression IR LEDs 8 IR LEDs, 850nm Networking 8-meter illumination distance 10/100Base-TX Fast Ethernet Network Interface IR Mode Always on 802.11b/g/n WLAN Always off... - Page 28 Technical DeTails General Power External AC-to-DC switching power adapter System Processor: RT5350 Input: 100-249V AC, 50/60Hz, Speed: 360MHz Output: 5V DC, 1A DRAM: 64MB Flash: 8MB Button Reset Button - R eset system: Press less than 1 second to reset the system - F actory default: Press and hold 20 seconds to restore the factory default settings Switch Setup mode switch: Turn setup mode on and off LEDs Setup Mode LED - S olid Green: Setup Mode on - A mber: In progress to switch to Setup Mode...
-
Page 29: System Requirements
Technical DeTails System Requirements Resetting the Camera iPhone, iPad, or iPod touch with iOS 4.1 or above or Android The “Reset” button is used in rare cases. In the unlikely event smart devices Version 2.2 or above that your camera functions improperly, please use a pin to reset the camera. The Reset button is where the arrow below PC OS: Windows® XP, Windows Vista®, or Windows 7, or points. Reset the camera when the switch is in “OFF” mode. Mac OS® X v10.6.8 Snow Leopard After the reset, the camera will resume to the default setting. PC browsers: Internet Explorer 8, Google Chrome 16, Firefox - R eset system: Press and hold for 1 second to reset the 11.1, Safari® 5.1 Using the latest Adobe Flash Player system - R eset to factory default: Press and hold for 20 seconds to restore the factory default settings... -
Page 30: Troubleshooting, Support, And Warranty
TroubleshooTing, supporT, and WarranTy if i buy more cameras, could i use the same username to how can i share my cameras with my friends? connect them? Log in to your account. Under the camera configuration, Unlimited cameras can be added under your own account, but find the “Sharing”... - Page 31 TroubleshooTing, supporT, and WarranTy how can i upgrade the firmware? Can i change my username? Access your NetCam’s account from a web browser. Under the camera Your username is what identifies your account information, configuration, a screen will pop up like the one below. Click “Update and once set, it cannot be changed.
-
Page 32: Belkin International, Inc., Limited 2-Year Product Warranty
In the event that Belkin is unable to repair or replace the product (for example, because it has been discontinued), Belkin will offer either a refund or a credit toward the purchase of another product from Belkin. -
Page 33: How To Get Service
Belkin product and how to proceed with your claim. To get service for your Belkin product you must take the following steps: Belkin reserves the right to review the damaged Belkin product. All 1. -
Page 34: How State Law Relates To The Warranty
DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH AS, BUT NOT LIMITED TO, LOST BUSINESS OR PROFITS ARISING OUT OF THE SALE OR USE OF ANY BELKIN PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. This warranty gives you specific legal rights, and you may also have other rights, which may vary from state to state. -
Page 35: Technical Support
You can find technical-support information on our website, You can find technical-support information on our website, SLOVAKIA SLOVAKIA 08000 04614 08000 04614 www.belkin.com/networking/ www.belkin.com/networking/ www.belkin.com, by navigating to the tech-support section. www.belkin.com, by navigating to the tech-support section. SLOVENIA SLOVENIA 0800 80510 0800 80510 www.belkin.com/networking/ www.belkin.com/networking/... -
Page 36: Regulatory Information
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC, the EMC Directive 2004/108/EC, and the low-voltage Directive 2006/95/EC. A copy of the European Union CE marking “Declaration of Conformity” may be obtained at the website: www.belkin.com/doc General Safety Information: •... - Page 37 © 2012 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Windows, Windows Vista, and Internet Explorer are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. iPad, iPhone, iPod touch, Mac OS, and Safari are trademarks of Apple Inc., registered in the U.S.
