- Page 1 Automatic washing machine WMB91242LC WMB91242LB...
- Page 2 Please read this user manual first! Dear Customer, We hope that you get the best results from the product which has been manufactured in state-of-the-art plants and passed through a strict quality control procedure. Therefore, please read the entire user manual carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Your washing machine Additional programmes ... . 18 Temperature selection ... . . 20 Overview ......4 Spin speed selection . -
Page 4: Your Washing Machine
Your washing machine Overview 1- Power cable 5- Adjustable feet 2- Top panel 6- Loading door 3- Control panel 7- Detergent drawer 4- Filter cap 8- Drain hose... -
Page 5: Technical Specifications
Technical specifications Models WMB91242LC WMB91242LB Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) Net weight (±4 kg.) Electrical input (V/Hz) 230 V / 50Hz 230 V / 50Hz Total current (A) Total power (W) 2200 2200 Spin speed (rpm max.) -
Page 6: Important Safety Instructions
Important safety instructions This section contains safety instructions injury from hot water will occur. that will help protect from risk of personal • Do not force open the locked loading injury or property damage. Failure to follow door. The loading door will be ready these instructions shall void any warranty. - Page 7 let them to tamper with the product. Use child lock to prevent children from intervening with the product. • Do not forget to close the loading door when leaving the room where the product is located. • Store all detergents and additives in a safe place away from the reach of the children.
-
Page 8: Installation
Installation Refer to the nearest Authorised Service Removing packaging Agent for installation of the product. To reinforcement make the product ready for use, review Tilt the machine backwards to remove the information in the user manual and the packaging reinforcement. Remove the make sure that the electricity, tap water packaging reinforcement by pulling the supply and water drainage systems are... -
Page 9: Connecting Water Supply
3. Attach the plastic covers supplied in the User Manual bag into the holes on the rear panel. (P) Keep the transportation safety bolts in a safe place to reuse when the washing Ensure that the cold and hot water machine needs to be moved again in connections are made correctly when the future. -
Page 10: Adjusting The Feet
• In case the hose is elevated after laying it on the floor level or close to the ground (less than 40 cm above the ground), water discharge becomes more difficult and the laundry may come out excessively wet. Therefore, follow the heights described in the figure. -
Page 11: First Use
fuse. Connect the green - yellow or green (earth) wire to the terminal in the plug • The specified voltage must be equal to marked ‘E’ or with the symbol f or your mains voltage. coloured green and yellow or green. •... -
Page 12: Disposing Of Packaging Material
Disposing of the old product anti-limescale into the main wash detergent compartment (compartment nr. Dispose of the old product in an II). If the anti-limescale is in tablet form, environmentally friendly manner. put only one tablet into compartment nr. Refer to your local dealer or solid waste II. -
Page 13: Preparation
Preparation Things to be done for energy saving Following information will help you use the product in an ecological and energy- Wash with sensitive, Washing water efficient manner. .short programmes temperature • Operate the product in the highest capacity allowed by the programme you have selected, but do not overload;... -
Page 14: Correct Load Capacity
and the washing programme desired. The machine automatically adjusts the amount of water according to the weight of the loaded laundry. Follow the information in the “Programme and consumption table”. When overloaded, machine's washing performance will drop. Moreover, noise and vibration problems may occur. Laundry types and their average weights in •... -
Page 15: Using Detergent And Softener
Using detergent and softener • When washing dark coloured clothes and quilts, it is recommended to use Detergent Drawer liquid detergent. The detergent drawer is composed of three • Wash woolens with special detergent compartments: made specifically for woolens. - (I) for prewash Use only detergents manufactured - (II) for main wash specifically for washing machines. - Page 16 detergent between the laundry, close to the lower part of the drum in future washings. Use the tablet or gel detergent without selecting the prewash function. Using starch • Add liquid starch, powder starch or the dyestuff into the softener compartment as instructed on the package.
-
Page 17: Operating The Product
Operating the product Control panel Spin Speed Adjustment button Display Temperature Adjustment button Programme Selection knob On / Off button Delayed Start buttons (+ / -) Auxiliary Function buttons Start / Pause / Cancel button Display symbols - Spin Speed indicator - Temperature indicator - Spin symbol - Temperature symbol... -
Page 18: Preparing The Machine
Preparing the machine Your laundry will be washed with vigorous washing action for a longer washing cycle. 1. Make sure that the hoses are • Synthetics connected tightly. Use this programme to wash your synthetic 2. Plug in your machine. clothes (shirts, blouses, synthetic/cotton 3. -
Page 19: Special Programmes
• Xpress Super Short and do not contain any stains or dirt. Use this programme to wash your little • Eco Clean amount of lightly soiled cotton clothes in a Use this programme, which is much short time. more sensitive to environment and natural •... -
Page 20: Temperature Selection
Temperature selection options appear on the display. See "Auxiliary function selection" section for Whenever a new programme is selected, explanations of these options. the maximum temperature for the Rinse Hold option is indicated with “ selected programme appears on the ”... -
Page 21: Programme And Consumption Table
Programme and consumption table Auxiliary functions Selectable Programme (°C) temperature range °C Cottons 2.70 1600 • • • • • • 90-Cold Cottons 1.80 1600 • • • • • • 90-Cold Cottons 1.00 1600 • • • • • •... -
Page 22: Auxiliary Function Selection
Auxiliary function selection F2 appears on the display when you select this function (b). Select the desired auxiliary functions before When you select this function, load starting the programme. Furthermore, you your machine with half of the maximum may also select or cancel auxiliary functions laundry specified in the programme that are suitable to the running programme table. -
Page 23: Starting The Programme
2. Set the desired delayed start time by pressing the Delayed Start + or - buttons. 3. Press Start / Pause / Cancel button. Delayed Start symbol illuminates steadily. Pause symbol disappears. Start symbol appears. Programme time may differ from 4. -
Page 24: Loading Door Lock
Main Wash Changing the speed and temperature Main Wash symbol indicating that the main settings for auxiliary functions wash step has started appears on the Depending on the step the programme has display. reached, you may cancel or activate the Rinse auxiliary functions;... -
Page 25: Canceling The Programme
Lock is enabled. Just press Start / Pause / Cancel button. Pause symbol disappears. Start symbol To deactivate the Child Lock: appears. Programme resumes and Press and hold 2 and 4 Auxiliary discharges the water only. Function buttons for 3 seconds. “COFF” appears on the display. -
Page 26: Maintenance And Cleaning
Maintenance and cleaning inside of the bellow with a clean piece of Service life of the product extends and cloth after the programme has come to an frequently faced problems decrease if end. cleaned at regular intervals. Repeat Drum Cleaning process in every Cleaning the detergent drawer 2 months. -
Page 27: Draining Remaining Water And Cleaning The Pump Filter
the water in the machine cools down. 2. Open the filter cap. If the filter cap is composed of two pieces, press the tab on the filter cap downwards and pull the piece out towards yourself. 1. Close the taps. 2. - Page 28 is emptied, repeat the above procedure to drain the water in the machine completely. c. When draining of water is finished, close the end by the plug again and fix the hose in its place. d. Turn the pump filter to take it out. Discharging the water when the product does not have an emergency draining hose:...
-
Page 29: Troubleshooting
Troubleshooting Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> Press and hold Start / Pause / Cancel button for 3 seconds to reset the machine to factory settings. (See "Canceling the programme") Water in the machine. - Page 30 Loading door cannot be opened. • Door lock is activated because of the water level in the machine. >>> Drain the water by running the Pump or Spin programme. • Machine is heating up the water or it is at the spinning cycle. >>> Wait until the programme completes.
- Page 31 Machine does not switch to spinning step. • There might be an imbalance of laundry in the machine. >>> Automatic unbalanced load detection system might be activated due to the unbalanced distribution of the laundry in the drum. Machine does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the machine and to its surrounding environment.
- Page 32 Washing performance is poor: Clothes smell unpleasantly. • Odours and bacteria layers are formed on the drum as a result of continuous washing at lower temperatures and/or in short programmes. >>> Leave the detergent drawer as well as the loading door of the machine ajar after each washing.
- Page 33 Detergent residue in the detergent drawer. • Detergent is put in wet drawer. >>> Dry the detergent drawer before putting in detergent. • Detergent has gotten damp. >>> Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures. •...
- Page 34 Laundry remains wet at the end of the programme • Excessive foam might have occurred and automatic foam absorption system might have been activated due to too much detergent usage. >>> Use recommended amount of detergent. Machine does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the machine and to its surrounding environment.
-
Page 35: Guarantee
Republic of Ireland. items. • The guarantee is applicable only to • The labour costs of a Beko approved new products and is not transferable if repairer to carry out the repair. the product is resold. • Beko disclaims any liability for What is not covered? incidental or consequential damages. -
Page 36: Service
Should you experience any difficulty in require attention under guarantee. obtaining service please contact the Beko Customer Help-Line. You should also complete the details Tel: 0845 600 4911 below;...
