PECIFICATIONS
Standards: IEEE802.3ab 1000BASE-TX
IEEE802.3z 1000BASE-SX/LX
Data Transfer
1488000pps for 1000Mbps
Rate:
Duplex Mode: Full Duplex Mode
LED indicators: PWR, LNK/ACT
Cable 1000BASE-T --
4 pair Cat. 5, EIA/TIA-568 100-ohm
screened twisted-pair (STP), up to 100m
1000BASE-SX --
62.5/125μ m multi-mode fiber optic cable,
up to 220m
50/125μ m multi-mode fiber optic cable, up
to 550m
1000BASE-LX --
9/125 μ m single-mode fiber optic cable,
DMC-810SC up to 10km
DMC-880SC up to 80km
Dimensions L120 × W88 × H25 mm
Weight 305 g
Power External power adaptor 7.5V 1.5A
Media Interface: RJ-45, SC
EMI Compatiblity: FCC Class B
CE Certification, Class B
VCCI Class B
Temperture:
Storage: -10°C ~ 70°C
Operating: 0°C ~ 40°C
Humidity: 10% ~90% non-condensing
Power 5.5 Watts (maximum)
Consumption:
