Studio Monitors
BEHRITONE
C50A/C5A
C50A — Active 30-Watt Full-Range
Reference Studio Monitor
High-resolution, 30-Watt active
nearfield monitor
Frequency response from 90 Hz to
17 kHz with zero crossover
phase distortion
6 1/2" cube cabinet with
multiple coats of high-gloss
piano lacquer finish
C5A — Vintage-Style 30-Watt Active
Full-Range Reference Studio Monitor
Vintage-style studio monitor
modeled after a famous model
from the 70's
6 1/2" cube cabinet with detachable
acoustic foam and attractive
wood laminate
Common features:
High-end 30-Watt Class-D amplifier
built-in to perfectly match the
speaker's performance
Full-range 5 1/4" speaker with
special diaphragm and
deformation-resistant chassis
Homogeneous dispersion pattern
due to singular small-diaphragm
full-range driver configuration
Magnetic shielding allows placement
near computer monitors
Precision-milled, high-rigidity
MDF cabinet and baffle for
minimal resonance
5/8" microphone stand mount built
into the cabinet base
BEHRITONE C5A and C50A full-range
reference studio monitors let you hear
what your mixes will sound like on
real-world systems such as car stereos,
computers, televisions, iPod stations
and other bass-challenged systems.
Each 6.5" cube contains its own dedicated
30-Watt Class-D power amp and a
specially designed 5-1/4" full-range speaker
for crystal-clear audio reproduction.
Both models accept balanced XLR and
1/4" TRS, as well as unbalanced RCA
connections, and are magnetically
shielded so they won't disrupt your
computer video monitors.
Beauty is More Than Just Skin-Deep
BEHRITONE loudspeakers are our
homage to a now-defunct company
and their legendary 5C loudspeakers,
which literally shook up the recording
industry in the 1970s and '80s.
The original versions were passive little
vinyl-clad, particle-board cubes that
recording engineers soon came to love.
The C50A features a high-gloss piano
lacquer finish, while the C5A sports a
classic wood-grain laminate, allowing
either model to fit into virtually any
studio décor. Both are constructed of
precision- milled, high-rigidity MDF for
extremely low- resonance performance.
A neoprene pad is included for superior
acoustic isolation when the speakers are
placed on a desktop, or the enclosures
can be mounted on mic stands via the
built-in 5/8" adapters.
Discover what world-class studio and
mastering engineers have known for
decades—the only way to get the TRUTH
about your mix is to hear it through these
pint-sized beauties. BEHRITONE C5A
or C50A active studio monitors are the
perfect complement to your current
monitoring system.

Advertisement

loading

Summary of Contents for Behringer Behritone C50A

  • Page 1 Studio Monitors BEHRITONE C50A/C5A C50A — Active 30-Watt Full-Range Reference Studio Monitor High-resolution, 30-Watt active nearfield monitor Frequency response from 90 Hz to BEHRITONE C5A and C50A full-range vinyl-clad, particle-board cubes that 17 kHz with zero crossover reference studio monitors let you hear recording engineers soon came to love.
  • Page 2 High-quality components and exceptionally rugged construction ensure long life C50A Front View Conceived and designed by BEHRINGER Germany Precision-milled, high-rigidity MDF enclosure Full-range 5 1/4" speaker * 5/8" microphone stand Power LED...
  • Page 3: Computer Setup

    Page 3 of 4 BEHRITONE C50A/C5A C50A Recording Setup B3031A C50A BEHRITONE BEHRITONE USB In/Out Left Control Room Out Right Laptop XM8500 V-AMP PRO X2222USB Computer Setup BEHRITONE BEHRITONE Laptop UCA222 USB Audio Interface...
  • Page 4: Specifications

    Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER is part of the MUSIC Group (music-group.com). All trademarks are the property of their respective owners. MUSIC Group accepts no liability for any loss...
