- Page 1 User Informations information pour l’utilisateur Built-in oven Four encastrable ZOU 361...
- Page 2 Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances. Please read this user manual carefully and keep it throughout the product life cycle as a reference document.
-
Page 3: Table Of Contents
Contents Warnings and Important Safety Information ..................4 Description of the appliance ......................6 Controls ............................7 Before using the oven for the first time ..................10 Using the Oven ........................... 11 Baking and Roasting Tables ....................... 15 Cleaning and Maintenance ......................17 If something is wrong ........................ -
Page 4: Warnings And Important Safety Information
English Warnings and Important Safety Information Always keep these user instructions with the appliance. Should the appliance be passed on to third persons or sold, or if you leave this appliance behind when you move house, it is very important that the new user has access to these user instructions and the accompanying information. -
Page 5: Child Safety
Child Safety • This appliance is intended for use by adults. It is dangerous to allow children to use it or play with it. • Children should be kept away while the oven is working. Also, after you have switched the oven off, it remains hot for a long time. -
Page 6: Description Of The Appliance
Description of the appliance 2 2 2 2 2 3 3 3 3 3 6 6 6 6 6 5 5 5 5 5 4 4 4 4 4 7 7 7 7 7 1 1 1 1 1 8 8 8 8 8 9 9 9 9 9 11 11 11 11 11 12 12 12 12 12... -
Page 7: Controls
Controls Oven Function Control Knob The oven is off Bottom heating element - The heat comes from the bottom of the oven only Pizza - The bottom heating element,and the inner grill are on and the fan ensures air is circulated tocook the pizza toppings or pie fillings. -
Page 8: End Of Cooking Programmer
End of cooking programmer This device allows you to make the oven switch off automatically once the preset time is over. An acousitic signal will be heard when the cooking is completed.The cooking duration can be set up to 90 minutes maximum. Place food in the oven and turn the oven function control knob and the thermostat control knob on the required settings. -
Page 9: Hotplate Control Knobs
Hotplate control knobs The Control Knobs for the hotplates (Fig. 4) can be found on the oven control panel. The energy regulator of the hotplates can be set by means of a 7-position control knob: 0 = Off 1 = Minimum 3 = Maximum The intermediate positions give an increasing heating power. -
Page 10: Before Using The Oven For The First Time
Before using the oven for the first time Remove all packaging, both inside and outside the oven, before using the oven. Before using for the first time, the oven should be heated up without food. During this time, an unpleasant odour may be emitted. -
Page 11: Using The Oven
Using the oven The oven is supplied with an exclusive system which produces a natural circulation of air and the constant recycling of steam. This system makes it possible to cook in a steamy environment and keep the dishes soft inside and crusty outside. -
Page 12: Fan Cooking
fish lightly with a little oil or melted butter to Fan cooking keep them moist during cooking. The food is cooked by means of preheated air Accompaniments such as tomatoes and force blown evenly round the inside of the mushrooms may be placed underneath the oven by a fan set on the rear wall of the oven grid when grilling meats itself. - Page 13 Stand dishes on suitably sized baking trays to On baking: prevent spillage onto the base of the oven Cakes and pastries usually require a medium and make cleaning easier. temperature (150°C-200°C) and therefore it is Do not place dishes, tins or baking trays necessary to preheat the oven for about 10 directly on the oven base as it becomes very minutes.
-
Page 14: Cooking Times
Leave the joint to stand for at least 15 minutes, so that the meat juices do not run out. To reduce the build up of smoke in the oven, it is recommended to pour a little water in the roasting pan. -
Page 15: Baking And Roasting Tables
Baking and Roasting Table Conventional Cooking Timings do not include pre-heating. The empty oven should always be pre-heated for 10 minutes. Conventional Cooking Fan Cooking Cooking times TYPE OF DISH in minutes NOTES temp temp °C ° C CAKES Whisked recipies 2 (1and3)* 160 45-60 In cake mould... -
Page 16: Pizza Function
Grilling Timings do not include pre-heating. The empty oven should always be pre-heated for 10 minutes. Cooking time in Quantity Grilling TYPE OF DISH minutes 1st side Pieces temp.°C 2nd side Fillet steaks 12~15 12~14 Beef-steaks 10~12 Sausages 12~15 10~12 Pork chops 12~16 12~14... -
Page 17: Cleaning And Maintenance
Cleaning and Maintenance Before cleaning switch the oven off External cleaning and let it cool down. Regularly wipe over the control panel, oven door The appliance must not be cleaned and door seal using a soft cloth well wrung out in with a superheated steam cleaner or warm water to which a little liquid detergent has a steam jet cleaner. -
Page 18: Oven Shelves And Shelf Supports
Oven Shelves and Shelf Supports To clean the oven shelves, soak in warm soapy water and remove stubborn marks with a well wetted soap impregnated pad. Rinse well and dry with a soft cloth. The shelf supports can be removed for easy cleaning. Proceed as follows: 1. -
Page 19: Cleaning The Oven Door
Cleaning the Oven Door Before cleaning the oven door, we recommend you to remove it from the oven. Proceed as follows: 1. open the oven door completely; 2. find the hinges linking the door to the oven (Fig. A); 3. unlock and turn the small levers located on the Fig. -
Page 20: Replacing The Oven Light
Replacing The Oven Light Disconnect the appliance If the oven bulb needs replacing, it must comply with the following specifications: Electric power: 15 W/25 W, Electric rate: 230 V (50 Hz), Resistant to temperatures of 300°C, Connection type: E14. These bulbs are available from your local Service Force Centre. -
Page 21: If Something Is Wrong
If something is wrong If the appliance is not working correctly, please check the following before contacting the Electrolux Service Centre: SOLUTION PROBLEM The oven is not switching on. Check that both a cookingfunction and temperature have been selected Check whether the appliance is correctly connected and the socket switch or the mains supply to the oven is ON. -
Page 22: Technical Data
Technical Data Heating element ratings This appliance can be connected to variuos cast iron or ceramic hobs: Bottom heating element 1000 W Pizza function 2650 W Traditional Hobs Type: ZME 2002 V Full oven (Top+Bottom) 1800 W Maximum powerabsorbed 5,5 kW Full Grill 2450 W Power supply voltage (50Hz) -
Page 23: Instructions For The Installer
Instructions for the installer The instructions given below are designed any given point a temperature 50°C higher than specifically for a qualified installer and the ambient temperature. should aid him or her to perform all Suitable power supply cables are the following installation, adjustment, and maintenance types, considering the respective necessary operations with absolute precision and in... -
Page 24: Instructions For Building In
Instructions for Building In For problem-free functioning of the built-in appliance, the kitchen unit or the recess into which the appliance is built must have suitable dimensions. In accordance with the regulations in force, all parts which ensure the shock protection of live and insulated parts must be fastened in such a way that they cannot be undone without tools. -
Page 25: Declaration Of Guarantee Terms
Declaration of guarantee terms Our appliances are produced with the greatest of care. However, a defect may still occur. Our consumer services department will repair this upon request, either during or after the guarantee period. The service life of the appliance will not, however, be reduced as a result. This declaration of guarantee terms is based on European Union Directive 99/44/EC and the provisions of the Civil Code. - Page 26 13. A repair under guarantee does not mean that the normal guarantee period will be extended nor that a new guarantee period begins. 14. We give a twelve month guarantee for repairs, limited to the same defect. 15. Except in the event where liability is legally imposed, this declaration of guarantee terms excludes any compensation for damage outside the appliance for which the consumer wishes to assert his rights.
-
Page 27: European Guarantee
European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qualifications: •...
