- Page 1 Cal. S034 INSTRUCTIONS INSTRUCTIONS (P. 33) INSTRUCCIONES (P. 65) BEDIENUNGSANLEITUNG (S. 95) ISTRUZIONI (P. 128) INSTRUÇÕES (P. 162) (192...
- Page 2 You are now the proud owner of a SEIKO Digital Stopwatch Cal. S034. Before using your SEIKO Digital Stopwatch Cal. S034, please read the instructions in this booklet carefully for its proper use and care. Please keep this manual handy for ready reference.
-
Page 3: Table Of Contents
CONTENTS Page FEATURES ........................TIME/CALENDAR SETTING ..................STOPWATCH ......................ALARM ........................ILLUMINATING LIGHT (ELECTROLUMINESCENT PANEL) ........BATTERY LIFE INDICATOR ..................BATTERY CHANGE ..................... TO PRESERVE THE QUALITY OF YOUR WATCH ............SPECIFICATIONS ...................... -
Page 4: Features
Cal. S034 FEATURES The SEIKO Quartz Stopwatch Cal. S034 is a digital stopwatch featuring a lap time/split time memory function that can store and recall up to 30 sets of lap times and split times. Time/calendar and alarm functions are also provided. In addition, it is equipped with an electroluminescent panel that evenly illuminates the display for easy viewing in the dark. - Page 5 The calendar automatically adjusts for odd and even months including February of leap years from the year 1995 up to the end of 2044. ALARM The alarm can be set to ring on a 24-hour basis. An hourly time signal is also provided. CHANGEOVER BETWEEN 12- AND 24-HOUR INDICATIONS BATTERY LIFE INDICATOR All the digits in the display start flashing when the battery needs to be replaced.
- Page 6 There are five buttons as indicated in the illustration below. [TIME/CALENDAR display] Date Month “AM”/“PM” mark TIME/CALENDAR Alarm mark display indicator Hourly time signal mark...
- Page 7 With each press, the display changes in the following order. TIME/CALENDAR LAP TIME SPLIT TIME ALARM display display display display NOTES Even if the STOPWATCH (LAP TIME or SPLIT TIME) display is changed over to another while a measurement is in progress, the stopwatch continues counting properly and the flashing STOPWATCH display indicator appears in the display.
-
Page 8: Time/Calendar Setting
TIME/CALENDAR SETTING Date Month “AM”/“PM” mark Seconds TIME/CALENDAR display indicator Minutes Hour Press to show the TIME/CALENDAR display. * The YEAR digits appear in Press and hold for 2 seconds to show the TIME/ place of the DAY and the CALENDAR SETTING display. - Page 9 * With each press, the digits to Press repeatedly to select the digits (flashing) be adjusted change in the to be adjusted. following order: SECONDS MINUTES HOUR DATE 12-/24-HOUR INDICATION YEAR MONTH * The digits move quickly if Press to set the flashing digits or reset the Button A is kept pressed.
- Page 10 NOTES If the watch is left untouched in the TIME/CALENDAR SETTING display with the digits flashing, it will automatically return to the TIME/CALENDAR display in 3 minutes. The DAY is automatically set once the YEAR, MONTH and DATE are set. The YEAR digits can be set from 1995 to 2044.
-
Page 11: Stopwatch
STOPWATCH Two stopwatch displays are available for lap time and split time measurement. * If the measurement is started or stopped in one display, the other display also starts or stops accordingly. Therefore, you can switch between the LAP TIME and SPLIT TIME displays during the measurement to check the measured times. - Page 12 “Lap time” is the time that has elapsed from the start of one stage of an activity to that of the next stage. “Split time” is the time that has elapsed from the start of an activity to any given stage. LAP TIME START SPLIT TIME...
- Page 13 1 Standard measurement 1/100 Press to show the LAP TIME or SPLIT TIME display. 1/100 START STOP RESET 2 Accumulated elapsed time measurement Press to show the LAP TIME or SPLIT TIME display. START STOP RESTART STOP RESET * Restart and stop of the stopwatch can be repeated by pressing Button C.
- Page 14 3 Lap time measurement Press to show the LAP TIME display. “LAP” START LAP 2 LAP 1 Lap time mark 1/100 1/100 1/100 1/100 1/100 1/100 Lap No. Accumulated elapsed time Lap time measure- ment can be repeated by RESET FINISH pressing Button A.
- Page 15 4 Split time measurement Press to show the SPLIT TIME display. “SPLIT” Split time START SPLIT 1 SPLIT 2 mark SPLIT 1/100 SPLIT 1/100 SPLIT 1/100 1/100 1/100 1/100 Split No. Accumulated elapsed time Split time measurement can be repeated by RESET FINISH pressing Button A.
- Page 16 NOTE Even while the stopwatch is counting, you can switch from the STOPWATCH display to another by pressing Button D. It continues counting properly up to 10 hours, and the STOPWATCH display indicator flashes to indicate that the stopwatch is counting. HOW TO USE THE MEMORY FUNCTION •...
- Page 17 * The oldest measure- Press in the LAP TIME or SPLIT TIME display to m e n t s t o r e d activate the memory recall function. m e m o r y w i l l b e displayed first.
- Page 18 * The newest measure- Press in the LAP TIME or SPLIT TIME display to m e n t s t o r e d activate the memory recall function. m e m o r y w i l l b e displayed first.
-
Page 19: Alarm
ALARM The alarm can be set to ring on a 24-hour basis. Current time “AM”/“PM” mark Alarm mark Hourly time signal mark “on”/“- -” Alarm time (Alarm engagement/ (hour and minutes) disengagement mark) ALARM display indicator... - Page 20 ALARM TIME SETTING Press to show the ALARM display. * The HOUR digits (and “AM”/ Press and hold for 2 seconds to show the “PM” mark if the time is set in ALARM SETTING display. the 12-hour indication) start flashing. Press repeatedly to select the digits (flashing) to be adjusted.
- Page 21 When setting the hour digits in the 12-hour indication, check that “AM”/“PM” mark is correctly set. If the watch is left untouched in the ALARM SETTING display with the digits flashing, it will automatically return to the ALARM display in 3 minutes. ALARM ENGAGEMENT/DISENGAGEMENT * The alarm rings at the With each press in the ALARM display, the...
- Page 22 Alarm test Press and hold simultaneously in the TIME/CALENDAR display. ENGAGEMENT/DISENGAGEMENT OF HOURLY TIME SIGNAL & TUNING ON/OFF OF SOUND FOR BUTTON OPERATION CONFIRMATION * The hourly time signal will With each press in the TIME/CALENDAR not ring while the alarm is display, the hourly time signal and sound for ringing.
-
Page 23: Illuminating Light (Electroluminescent Panel)
ILLUMINATING LIGHT (ELECTROLUMINESCENT PANEL) Certain materials emit light when voltage passes through them. This phenomenon, known as “electroluminescence”, is used to illuminate the display. * The display is illuminated for Press and release in any mode. 3 seconds. * It remains illuminated if Button E is kept pressed. -
Page 24: Battery Life Indicator
Otherwise, the display will become blank and the watch will stop operating in 2 to 3 days. We suggest that you have the battery replaced by a SEIKO DEALER. * Even though the display is flashing, time accuracy is not affected. -
Page 25: Battery Change
For battery replacement, we recommend that you contact an AUTHORIZED SEIKO DEALER and request SEIKO CR2032 battery. * If the alarm is used for more than 20 seconds a day, the... -
Page 26: To Preserve The Quality Of Your Watch
10 bar/15 bar/20 bar and is suitable for or rain, but it is not designed for swimming or taking a bath and shallow diving, but not for diving. scuba diving. We recommend that you wear a SEIKO Diver’s watch for scuba diving. - Page 27 * Do not operate the buttons when the watch TEMPERATURES is wet or in water. If used in sea water, rinse the watch in fresh water and dry it Your watch works with +60°C completely. stable accuracy between a * When taking a shower with a water temperature range of 5 C -10°C resistance 5 bar watch, or taking a bath with...
- Page 28 CHEMICALS SHOCKS & VIBRATION Light activities will not affect Be careful not to expose the your watch, but be careful not watch to solvents (e.g., alcohol to drop your watch or hit it and gasoline), mercury (i.e., against hard surfaces, as this from a broken thermometer), may cause damage.
- Page 29 Years 7 Years checked by an AUTHORIZED that it may decrease in contrast, SEIKO DEALER or SERVICE CENTER to becoming difficult to read. Please contact ensure that the case, buttons, gasket and your AUTHORIZED SEIKO DEALER or SER- crystal seal remain intact.
-
Page 30: Specifications
SPECIFICATIONS Frequency of crystal oscillator ..... 32,768 Hz (Hz = Hertz … Cycles per second) Accuracy ........... 0.0012% at normal temperature range (5˚C ~ 35˚C) (41˚F ~ 95˚F) Operational temperature range ....-10˚C ~ 60˚C (14˚F ~ 140˚F) Desirable temperature range of use .... 0 C ~ 50 C (32 F ~ 122 F) Display system STOPWATCH display ...... - Page 31 “A”/“P” in the 12-hour indication) Alarm display indicator Display medium .......... Nematic Liquid Crystal, FEM (Field Effect Mode) Battery ............SEIKO CR2032, 1 piece Battery life indicator ........All the digits in the display start flashing when the battery life nears its end.
- Page 32 8 IC (Integrated Circuit) ........C-MOS-LSI, 1 piece * The specifications are subject to change without prior notice, for product improvement.
