  • Page 1 Cooker hood Dir. 89/336/CEE Dunstabzugshaube Hotte Wasemkap Cappa ZH 6022 ZH 9022 Operating instructions Gebruiksaanwijzing Bedienungsanleitung Istruzioni per l'uso Mode d'emploi 4324142 - 01/98...

  • Page 2: Table Of Contents

    CONTENTS DESCRIBING THE COOKER HOOD IDENTIFICATION OF THE APPLIANCE PRODUCT SAFETY WARNINGS DIMENSIONS SETTING UP AND INSTALLATION ELECTRICAL CONNECTION CONTROLS SWITCHING THE APPLIANCE ON AND OFF MAINTENANCE AND CLEANING...

  • Page 3: Describing The

    DESCRIBING THE COOKER HOOD This cooker hood features a through flow retractable visor which allows the hood to be installed inside a wall cabinet with the minimum loss of space while offering a large collection area for contaminated air once extended into its working position.
  • Page 4 RECIRCULATION MODE using charcoal filters to purify the contaminated air. EVACUATION MODE Using ducting to extract the contaminated air to the atmosphere. The grease filters are fitted to absorb grease and dust during cooking. The hood can be supplied with metal or paper filters. The paper filters have saturation indicators and should be located on the...

  • Page 5: Identification Of

    IDENTIFICATION OF THE APPLIANCE The rating plate is situated inside the casing. It gives the model number and serial number which should be quoted in any communication or if After Sales Service is required.

  • Page 6: Product

    PRODUCT This cooker hood has been designed for the purification of contaminated air and to remove odours in the kitchen. ATTENTION: This cooker hood must not be used for the purification of air which could contain harmful gases or poisons or other substances not to be found during normal cooking.

  • Page 7: Safety Warnings

    SAFETY WARNINGS ATTENTION: Before carrying out any kind of maintenance or cleaning disconnect the hood from the mains supply and unplug the cooker hood. Connect the hood to the mains supply via a double pole switch which has 3mm minimum clearance between the contacts.
  • Page 8 Before connecting this appliance to the mains supply, ensure that the mains voltage corresponds to the voltage on the rating plate inside the hood. This appliance must be earthed. ATTENTION: Only use earthed plugs or sockets. ATTENTION: Do not use any adapters or extensions.
  • Page 9 When used in the extraction mode the cooker hood ducting must not be connected to a flue which is used for exhausting fumes from appliances supplied with energy other than electric such as a central heating flue or water heating flue. When installed, the hood must be positioned at least 65cm above a cooking...
  • Page 10 Never leave frying pans unattended during use as overheated fat and oil may catch fire. If the room where the cooker hood is to be used contains a fuel burning appliance such as a central heating boiler then this must be of the room sealed or balanced flue type.
  • Page 11 Always ensure that the flame is kept at the correct intensity to prevent the flame from licking round from the bottom of the pan; this will save energy and will avoid a dangerous concentration of heat. ATTENTION: There could be a possible fire hazard if the grease filters are not cleaned or replaced...
  • Page 12 ATTENTION: Please read the instruction booklet carefully before installing or using this appliance. ATTENTION: Do not insert hands or any other object into the air outlet. Do not use wet clothes or sponges to clean the surfaces of the cooker hood.
  • Page 13 Should your cooker hood fail to function at anytime repairs should be carried out by a qualified electrician or a competent person. When carrying out any kind of maintenance or in the event that your cooker hood stops functioning, switch off the mains supply and disconnect the plug from the socket.

  • Page 14: Dimensions

    DIMENSIONS...

  • Page 15: Setting Up And

    SETTING UP AND INSTALLATION Before unpacking the cooker hood position the carton with arrows pointing upwards as illustrated. Remove the cooker hood and polystyrene side protection complete from the carton. Insert the ducting spigot into the aperture on the top of the cooker hood casing.
  • Page 16 The cooker hood in 90 cm is provided with 4 grease filters which should be removed using the same method as for the 60 cm model. Cut a rectangular hole into the underside of the cabinet in accordance with the table below. MOD.
  • Page 17 Insert the upper casing of the hood through the hole from the underside of the cabinet. If you wish to replace the factory fitted front strip with a personnalized strip remove the three screws. Remove the front strip. Drill the new front strip taking care to align it correctly.
  • Page 18 Fix the new front strip with the screws provided. Fasten the screws of the butterfly quick fixing system. If necessary adjust the lower assembly horizontally by loosening the four screws and closing the visor.
  • Page 19 Move the lower assembly as necessary to align the front with the cabinet door. Hold the hood body steady, open the visor and tighten the fixing screws. Fix the controls support to the underside of the cabinet using a provided screw.
  • Page 20 The cooker hood can be installed in two different ways: RECIRCULATION FITTING: using cleansing charcoal filters to purify the contaminated air from cooking and to recirculate it back into the kitchen. DUCTING FITTING: (without cleansing charcoal filter) to pass contaminated air out through ducting to the atmosphere.
  • Page 21 Connect a suitable length of ducting to the air outlet on the top of the cooker hood inside the cabinet. The ducting should be long enough to project through the hole in the top of the cabinet. Fit the recirculation grille over the ducting and screw the grille to the top of the cabinet using the screws...
  • Page 22 To remove the charcoal filters press on the two charcoal filter catches and remove the filters as illustrated. Replace the metal grease filters or grease filter grilles. It is now possible to install the ducting. Care should be taken when selecting the ducting to ensure it is manufactured from a fire retardant material to...

  • Page 23: Electrical

    ALLACCIAMENTO ELECTRICAL ELETTRICO CONNECTION Verificare che la tensione Before connecting this di rete corrisponda a quella appliance to the mains riportata sulla targhetta supply, ensure that the delle caratteristiche mains voltage corresponds tecniche della cappa. to the voltage on the rating plate inside the hood.

  • Page 24: Controls

    CONTROLS POS. DESCRIPTION Visor Control box Fan speed selector switch Fan motor ON/OFF switch Worktop lighting ON/OFF switch...

  • Page 25: Switching The

    SWITCHING THE APPLIANCE ON AND OFF Switch on the power to the cooker hood at the socket on the wall. Lower the control box as illustrated. To switch on the fan slide the switch marked "M" to position "1".
  • Page 26 To select the fan speed required, slide the switch marked "V". To switch on the worktop lighting slide the switch marked "L" to position "1". At this point all the functions of the cooker hood have been demonstrated. If desired the control box can be closed during cooking.

  • Page 27: Maintenance And

    MAINTENANCE AND CLEANING To ensure the best performance from your cooker hood when used in the recirculation mode charcoal filters should be replaced at least every 3 months. Metal filters should be cleaned at least every two months. The filters may be washed by hand in hot water using mild detergent or liquid soap or they can...
  • Page 28 To replace the paper filters, remove the grille panels and the metal retaining clips. Place the new filter on the grille with the coloured dots facing downwards. To replace the fluorescent strip light or the two lamps (60cm and 90cm cooker hoods) proceed as follows: Disconnect the hood from the mains supply.
  • Page 29 Move the glass strip until the opposite end is free. Pull the glass strip slightly down. Move the glass strip towards one side and remove. Replace the fluorescent strip light or the two lamps. To replace the starter remove the internal cover as follows: Remove the metal filters or the metal grilles.
  • Page 30 ATTENTION: Do not use hose pipes, pressure washers or cloths with a heavy concentration of water. Wipe the cooker hood over with a soft cloth wrung out in hot water and dry with a soft clean cloth.
