Instructions for use
GB
Upright refrigerator-freezer

Advertisement

Table of Contents
loading

Related Manuals for Smeg Fridge-freezer

Summary of Contents for Smeg Fridge-freezer

  • Page 1 Instructions for use Upright refrigerator-freezer...

  • Page 2: Table Of Contents

    Upright refrigerator-freezer Thank you for your confi dence in buying our appliance and congratulations on the excellent choice. We hope it will successfully serve its purpose for many years. Upright refrigerator - freezer (hereinafter: the appliance) consists of two parts: top part is refrigerator and bottom part is upright freezer.

  • Page 3: Before Fi Rst Operation

    Before fi rst operation • The appliance is manufactured in compliance with all relevant safety standards; however, it is recommended that persons with impaired physical, motional, or mental abilities, or persons with inadequate experience and knowledge, do not use the appliance without due supervision. The same recommendation applies to minors using the appliance.

  • Page 4: A Few Tips On How To Save Power With Your Refrigerator-Freezer Combo

    The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of thisproduct.

  • Page 5: Description Of The Appliance

    Description of the appliance Interior equipment of the appliance will typically vary according to the specifi c model. A Refrigerator 1 Fan 2 Interior light 3 Control panel 4 Horizontal bottle rack 5 Adjustable glass shelves 6 Pull-out glass shelf (adjustable height) 7 Removable snack tray 8 Foldable egg rack (closed - 6 eggs, open - 12 eggs)

  • Page 6: Installation And Connections

    Installation and connections Selecting the location Selecting the location • Place the appliance in dry and well aired room. The appliance operates best at temperature ranges indicated in the chart below. Relevant class of the appliance is indicated on the rating plate. Class Ambient temperature SN (subnormal)
  • Page 7 • The appliance is fi tted with spacers to be mounted on the top edge of the condenser. They prevent the rear of the appliance to be pushed too close to the wall. Spacers are fabricated universally regarding the different distance of the condenser from the cabinet, so make sure to position them properly.

  • Page 8: Changing The Direction Of Opening The Door

    Changing the Direction of Opening the Door Freestanding appliance Necessary tools: ring spanner No.8, screwdriver, torque 25 Tilt the appliance so that the bottom hinge can be unscrewed and proceed with disassembling as shown in the Figure 3. Then fi x the assembly parts again in the opposite turn. Use the attached opposite hinge insert piece.

  • Page 9: Control Panel - Appliance With Electronical Regulation

    Control panel - appliance with electronical regulation CONTROL UNIT I CONTROL UNIT II No frost system appliance A Digital temperature display (certain models only) of the refrigerator indicates actual temperatures during the operation from +1°C to +9°C. B ON/OFF and temperature setting button C Orange LED: illuminated during fan operation (knob D).
  • Page 10 Refrigerator temperature Refrigerator temperature • Temperature of the appliance is set by turning the button (B) to setting setting the position between the Min and Max span. • Recommended setting of the thermostat knob is to ECO position. • If the temperature in the room where the appliance is installed is lower than 16°C or if there is less than 10 kg of food in the refrigerator, we recommend setting the thermostat dial to Max.
  • Page 11 Fast freezing function Fast freezing function Fast freezing function is activated by turning the button (B) arrow (triangle) to the position SF/SC. If the function is not switched off manually it stops automatically (after approximately two days of operation). • After the automatic stop of the fast freeze function the appliance switches to regular operation mode at Max.
  • Page 12 CONTROL UNIT III Valve and no frost system appliance A Freezer temperature setting button H Red LED: indicates alarm state B Freezer temperature digital display: I Refrigerator ON/OFF button indicates temperature span between -16°C and J Green LED: indicates refrigerator operation -24°C.
  • Page 13 Refrigerator temperature setting Temperature setting Temperature setting +1°C do +9°C span -16°C to -24°C Freezer temperature setting span + fast freeze • Freezer temperature is set by the button (A), and refrigerator temperature by the button (N). • When you press one of temperature setting buttons, the digital display starts fl...
  • Page 14 Intermittent sound signal – power failure alarm If the refrigerator or freezer temperature increases excessively due to power failure, this is signaled by the sound alarm (intermittent beep), red light is on, and the display indicates fl ashing maximum temperatur digit (max. 9°C for the refrigerator). Fast cooling of the refrigerator The function of fast cooling of the refrigerator interior is activated by pressing the button (K) –...

  • Page 15: Control Panel Overview

    Control panel - Appliance with mechanical regulation ON/OFF button ON/OFF button The appliance is switched on/off by turning the temperature selector (see Fig.) to any position from 0 to 7. The appliance operation is controlled by turning the thermostat (temperature selecting button) located within the refrigerator cabinet from the position STOP (0) to the position 7 and back.

  • Page 16: Refrigerator Accessories

    Refrigerator accessories (Equipment depends on the model) Shelf Shelf • Shelves can be optionally placed on the guides inside the appliance. To remove the shelf, fi rst slide it out as far as the guide allows it, then slightly lift it up and pull it out. Quickly perishable food should be stored on the back i.e.
  • Page 17 • Fan fi xed under the ceiling or hidden behind the rear refrigerator panel or within the freezer compartment improves even distribution of temperature and decreases dew upon storage racks. Removable snack tray Removable snack tray The tray is especially handy for cold cuts, cheese, etc ... The drawer is pulled out by lifting the front part slightly and then pulling out.

  • Page 18: Storage Of Food In The Refrigerator

    Storage of food in the refrigerator Important precautions Important precautions • Proper use of the appliance, adequately packed food, correct and hints and hints temperature and hygienic precautions produce substantial impact on the quality of stored food. • Always respect the best before date, printed on the packaging. •...

  • Page 19: Storage Of Food In The Fresh Zone

    Storage of food in the FRESH ZONE The FRESH ZONE drawer provides storage of wide selection of fresh food longer than in the traditional refrigerator. Food remains fresh for long time and it preserves its taste and nutritive ingredients. It reduces decay and loss of mass, so fruit and vegetables are more fresh and natural.

  • Page 20: Freezing And Storage Of Frozen Food

    Freezing and storage of frozen food Storage procedure Storage procedure • Activate the fast freeze function by pressing the button (C) for continuous operation 24 hours prior intended freezing. - control unit I and II: with knob B, position SF/SC; - control unit III: with key C;...

  • Page 21: Defrosting The Appliance

    Storage of industrially Storage of industrially The storage time and recommended temperature for storing frozen food frozen food commercially frozen foods is indicated on the packaging. Always follow manufacturer’s instructions for storage and use of frozen food. When shopping be careful to choose only food which is adequately packed and provided with complete data and stored in freezers where the temperature never rises above -18°C.Do not buy packages of food wrapped with frost.

  • Page 22: Cleaning The Appliance

    Defrosting classical Defrosting classical • Clean the freezer when the frost layer in the freezer reaches freezer freezer thickness of around 3-5 mm. • 24 hours before defrosting activate the fast freeze function (see relevant control chapter depending upon the model of the appliance –...

  • Page 23: Troubleshooting Guide

    • Groove and drain outlet located underneath the cooling panel at the rear wall collect the drained water, so they must not be clogged (with food particles, for example). Make sure you inspect them periodically and clean if necessary (use plastic straw to free the outlet hole).
  • Page 24 Fault: Cause/Remedy Water dripping from the • Drain outlet is clogged, drain water drips past the collection appliance: groove. • Clean the clogged outlet using plastic straw. • Thaw thick ice deposits manually (see chapter Defrosting). Red signal light fl ashing (only •Frequent opening of the door, door open too long.

  • Page 25: Noise Level

    Noise level The refrigerator – freezer appliances are cooled by the refrigeration system with a compressor (assisted by fan in certain models) whose operation may produce certain noise. The level of such noise depends upon the location, correct use and age of the appliance. •...
  • Page 28 COMBI 54 181300/en (11-10)
