Crown I-Tech HD Quick Start Manual

Important Safety Instructions

1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat
reg isters, stoves, or other apparatus (including amplifi ers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or
the third prong is provided for your safety. If the provided
plug does not fi t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched,
par ticularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specifi ed by the manufac-
turer.
12. Use only with a cart, stand, tripod, bracket, or table specifi ed
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualifi ed service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate nor mally, or has been dropped.
15. Use the mains plug to disconnect the apparatus from the
mains.
16. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE.
17. DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR
SPLASHING AND ENSURE THAT NO OBJECTS FILLED
WITH LIQUIDS, SUCH AS VASES, ARE PLACED ON THE
EQUIPMENT.
18. THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL
REMAIN READILY OPERABLE.
Ensure Proper Cooling
When using an equipment rack, mount units directly on top of
each other. Close any open spaces in rack with blank panels.
DO NOT block front or rear air vents. The side walls of the rack
should be a minimum of two inches (5.1 cm) away from the
amplifi er sides, and the back of the rack should be a minimum
of four inches (10.2 cm) from the amplifi er back panel.
The fi gure to the right illustrates standard amplifi er airfl ow.
PRELIMINARY
I-Tech HD™ Quick-Start Guide
Welcome! Operating your I-Tech amplifi er
can be as simple or advanced as you wish.
Right out of the box, it works like any other
amplifi er with stereo loudspeaker loads.
•Dual and bridge-mono operating instructions are on the
opposite side of this sheet.
• When using an equipment rack, mount units directly on top
of each other. Close any open spaces in rack with blank
panels. DO NOT block front or rear air vents. The side walls of
the rack should be a minimum of two inches (5.1 cm) away
from the amplifi er sides, and the back of the rack should be a
minimum of four inches (10.2 cm) from the amplifi er back
panel.
• If you want to control and monitor the amplifi er with
Harman's System Architect , please follow the information
®
included with System Architect. If you want to load DSP
presets or perform diagnostics using the amplifi er's LCD
control screen, see Section 4.2 in the operation manual.
Please read this before you start:
TO PREVENT ELECTRIC SHOCK DO NOT REMOVE TOP OR
BOTTOM COVERS. NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
À PRÉVENIR LE CHOC ÉLECTRIQUE N'ENLEVEZ PAS LES
COUVERCLES. IL N'Y A PAS DES PARTIES SERVICEABLE
À L'INTÉRIEUR. TOUS REPARATIONS DOIT ETRE FAIRE PAR
PERSONNEL QUALIFIÉ SEULMENT.
PARA PREVENIR UN CHOQUE ELÉCTRICO, NO RETIRE LAS
CUBIERTAS SUPERIOR O INFERIOR. NO EXISTEN PARTES QUE
PUEDAN SER REPARADAS POR EL USUARIO AL INTE RIOR.
REMITA EL SERVICICO AL PERSONAL TÉCHNICAL CALIFI-
CADO.
TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE
AC MAINS, DISCONNECT THE POWER SUPPLY CORD PLUG
FROM THE AC RECEPTACLE. THE MAINS PLUG OF THE POWER
SUPPLY CORD SHALL REMAIN READILY OPERABLE.
POUR DÉMONTER COMPLÈTEMENT L'ÉQUIPEMENT DE
L'ALIMENTATION GÉNÉRALE, DÉMONTER LE CÂBLE D'ALI-
MENTATION DE SON RÉCEPTACLE. LA PRISE D'ALIMEN TATION
RESTERA AISÉMENT FONCTIONNELLE.
PARA DESCONECTAR COMPLETAMENTE EL EQUIPO DEL
SUMINSTRO ELECTRICO, DESCONECTE EL CABLE DE ALI-
MENTACION DE LA TOMA DE CA. LAS PATAS DEL CONEC TOR
DEL CABLE DE ALIMENTACIÓN DEBERAN MANTENERSE EN
BUEN ESTADO.
WATCH FOR THESE SYMBOLS:
The lightning bolt triangle is used to alert the user to the risk of
electric shock.
The exclamation point triangle is used to alert the user to
important operating or maintenance instructions.
The I-Tech Series amplifi ers are certifi ed only
at 120V in Canada.
Crown Factory Service
1718 W. Mishawaka Rd.,
Elkhart, Indiana 46517 U.S.A.
Telephone:
574.294.8200
800.342.6939 (North America,
Puerto Rico, and Virgin Islands only)
Facsimile:
574.294.8301 (Technical Support)
574.294.8124 (Factory Service)
Internet:
http://www.crownaudio.com
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
CAUTION: Changes or modifi cations not expressly approved by the party responsible for
complicance could void the user's authority to operate the euqipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equip-
ment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: The third prong of the AC power connector
(ground) is an important safety feature. Do not attempt
to disable this ground connection by using an adapter or
other methods.
(over)
IMPORTANT
I-Tech Series amplifi ers require Class 2 output wiring.
Les amplifi cateurs de série de I-Tech exigent des câbles de sortie de
classe 2.
I-Tech-Reihe-Verstärker verlangen Klasse die 2 Produktionsverdrah-
tung.
Los amplifi cadores de la Serie I-Tech requieren de un cableado de
sal ida Clase 2.
MAGNETIC FIELD
CAUTION! Do not locate sensitive high-gain equipment such as pre-
amplifi ers directly above or below the unit. Because this amplifi er has a
high power density, it has a strong magnetic fi eld which can induce hum
into unshielded devices that are located nearby. The fi eld is strongest
just above and below the unit.
If an equipment rack is used, we recommend locating the amplifi ers)
in the bottom of the rack and the preamplifi er or other sensitive equip-
ment at the top.
